HP Smart Array controller technology
- Introduction Technology brief, 4th edition
- Smart Array performance factors
- Smart Array processing engine
- Hardware tuning..............................................................................................................................
- Cache module performance benefits...................................................................................................
- RAID performance enhancements...........................................................................................................
- Background RAID creation
- RAID 5 and RAID 6 read-modify-write.................................................................................................
- Striping across arrays
- RAID 1 load balancing
- Data availability
- Adjusting strip size with the Array Configuration Utility (ACU)
- RAID migration with ACU..................................................................................................................
- Drive roaming..................................................................................................................................
- Mirror splitting and recombining with the ACU
- Online drive flash.............................................................................................................................
- Recovery ROM
- Pre-Failure Warranty using S.M.A.R.T technology
- Automatic data recovery with rapid rebuild technology
- Online spare
- Dynamic sector repair.......................................................................................................................
- ECC protection
- Write caches
- Software RAID
- Zero Memory RAID
- Smart Array Advanced Pack
- RAID 6..........................................................................................................................................
- RAID 60........................................................................................................................................
- Advanced Capacity Expansion (ACE)...............................................................................................
- Mirror splitting and recombining
- Drive erase....................................................................................................................................
- Storage pathway redundancy..........................................................................................................
- Video on Demand (VOD)
- Storage management
- Array Configuration Utility...............................................................................................................
- Option ROM Configuration for Arrays
- CPQONLIN...................................................................................................................................
- HP Systems Insight Manager............................................................................................................
- Array Diagnostics Utility..................................................................................................................
- Summary
- For more information..........................................................................................................................
- Call to action
Introduction
In 1989, HP (then Compaq) was the first company to introduce RAID subsystems in the network server marketplace. Today, RAID is an industry-standard technology used for most online network data storage. Our Smart Array controllers support RAID levels 0, 1, 1+0, 5, 6, 50, and 60.
HP engineers continue to enhance Smart Array performance, expansion, migration, and data availability capabilities. We provide administrators with tools for Smart Array configuration, storage management, and diagnostics. These tools make it easy to use Smart Array products as well as making interfaces and feature sets consistent between product generations. Consistent features sets ensure that you can move data between servers and external storage enclosures, and between models of Smart Array controllers.
This paper discusses the Smart Array processor engine, RAID level selection, data availability, fault tolerance, and recovery mechanisms. These capabilities allow Smart Array controllers to sustain high I/O throughput in a reliable, predictable way.
References made in this technology brief to the “present generation” of Smart Array controllers refer to the P410i, P410, P411, P212, P712, and P812. We began releasing these SAS-based, PCIe 2.0-compliant Smart Array controllers in 2009.
Smart Array performance factors
HP Smart Array hardware performance depends on multiple, interdependent factors.
We’ve enhanced Smart Array hardware performance with:
Multi-core multi-processing engine
Hardware tuning that includes customized connection settings
Advanced caching capabilities
Standard technologies that contribute to Smart Array performance include:
PCIe bus
Serial Attached SCSI (SAS) and its interoperability with Serial Advanced Technology Attachment (SATA) devices
SAS-2 enhancements to cabling and connectors
SAS topologies and zoning
Smart Array processing engine
The Smart Array multi-core multi-processing engine manages the RAID system. It transforms high-level read or write requests from an application into the individual instructions required for the RAID array. The current generation Smart Array controllers use an embedded RAID-on-Chip (RoC) processor running at 600 MHz. While it is not a direct measure of overall RAID performance, the new processor is capable of supporting up to 60,000 4 KiB random IOPS compared to 35,000 for the previous generation engines.
NOTE: KiB, MiB, and GiB are measurement units established by the International Electrotechnical Commission (IEC) and accepted by all major standards organizations. They replace the use of KB, MB, and GB. You may see both acronym types, along with other acronym replacements, as we update our tools, user interfaces, and documentation.
The controller disables read-ahead when it detects non-sequential read activity. HP Smart Array controller adaptive read-ahead caching eliminates issues with fixed read-ahead schemes that increase sequential read performance but degrade random read performance.
Write-back caching
HP Smart Array controllers use a write-back caching scheme that lets host applications continue without waiting for write operations to complete to the disk. A controller without a write-back cache returns completion status to the OS after it writes the data to the drives. A controller with write-back caching can “post” write data to high-speed cache memory and immediately return “back” completion status to the OS. The write operation completes in microseconds rather than milliseconds. The controller writes data from the controller’s write cache to disk later, at an optimal time for the controller.
Once the controller locates write data in the cache, subsequent reads to the same disk location come from the cache. Subsequent writes to the same disk location will replace the data held in cache. This is a “read cache hit.” It improves bandwidth and latency for applications that frequently write and read the same area of the disk.
The write cache will typically fill up and remain full most of the time in high-workload environments. The controller uses this opportunity to analyze the pending write commands to improve their efficiency. The controller can use write coalescing that combines small writes to adjacent logical blocks into a single larger write for quicker execution. The controller can also perform command reordering, rearranging the execution order of the writes in the cache to reduce the overall disk latency. With larger amounts of write cache memory, the Smart Array controller can store and analyze a larger number of pending write commands, increasing the opportunities for write coalescing and command reordering while delivering better overall performance.
Logical drives in RAID 5 and RAID 6 configurations gain higher write performance by combining adjacent write requests to form a full stripe of data (“full-stripe write”). Write operation for RAID 5 and RAID 6 normally requires extra disk reads to compute the parity data. But if all the data required for a full stripe is available in the cache, the controller does not require the extra disk reads. This improves write bandwidth for sequential writes to a logical drive in a RAID 5 or RAID 6 configuration.
Error checking and correcting (ECC) DRAM technology protects the data while it is in cache. Smart Array battery-backed or flash-backed cache backup mechanisms protect the cache data against a server crash and power loss. The controller disables caching when battery-backed or flash-backed cache is an option but the battery-backed or flash-backed cache is not installed. You can override this behavior but doing so opens a window for possible data loss. Disk drives provide an option to enable write caching that is not battery backed. We advise against enabling disk drive write cache because a power failure could result in data loss.
Cache width
Present generation Smart Array controllers support 256 MiB, 512 MiB, and 1 GiB cache modules. The 512 MiB and 1 GiB modules use a 72-bit wide (64 bits data + 8 bits parity) cache instead of the 40-bit wide (32 bits data + 8 bits parity) cache used in the 256 MiB modules. This doubles the bandwidth for moving cache data to and from the storage system, further increasing overall array performance.
For more information on Smart Array cache modules, see the “Data Availability” section later in this paper.
RAID performance enhancements
Smart Array controllers use several enhancements to increase RAID performance.
Background RAID creation
When you create a RAID 1, RAID 5, or RAID 6 logical drive, the Smart Array controller must build the logical drive within the array and initialize the parity before enabling certain advanced performance techniques. Parity initialization takes several hours to complete. The time it takes depends on the size of the logical drive and the load on the controller. The Smart Array controller creates the logical drive, initializing the parity whenever the controller is not busy. While the controller creates the logical drive, you can access the storage volume which has full fault tolerance.
RAID 5 and RAID 6 read-modify-write
After parity initialization is complete, writes to a RAID 5 or RAID 6 logical drive are typically faster because the controller does not read the entire stripe to update the parity data. Since the controller knows that the parity data is consistent with all the member drives in the stripe, the controller needs to read from only two disk drives during a RAID 5 write or three disk drives for a RAID 6 write to compute the parity data, regardless of array size.
Striping across arrays
RAID 50 and 60 methods stripe the data across multiple RAID/JBOD sets with different levels of parity. These nested RAID types let you configure arrays across HP Modular Smart Arrays (MSAs).
RAID 50 (RAID 5+0) uses RAID 0 block-level striping across RAID 5 arrays with distributed parity. RAID 50 will tolerate one drive failure in each spanned array without loss of data. RAID 50 configurations require a minimum of six drives and require less rebuild time than single RAID 5 arrays.
RAID 60 (RAID 6+0) uses RAID 0 block-level striping across multiple RAID 6 arrays with dual distributed parity. With dual parity, RAID 60 will tolerate the failure of two disks in each spanned array without data loss. RAID 60 configurations require a minimum of eight drives.
RAID 60 is available as an option with the Smart Array Advanced Pack (see section later in this paper) and is not supported on all HP Smart Array controllers.
RAID 1 load balancing
RAID 1 logical drives contain two copies of the data. During reads to RAID 1 logical drives, the Smart Array controller issues read requests to either drive in the mirrored set. The Smart Array controller uses RAID 1 load balancing to balance the number of requests between the two disk drives during a heavy read load to achieve higher read bandwidth.
Data availability
Smart Array controllers support online array expansion, logical drive extension, strip^2 size migration, and RAID migration. These technologies protect data and let you modify the array without interrupting data access. Smart Array controllers can monitor I/O activity, track key parameters, predict potential problems,
(^2) When a Smart Array controller makes an array, the unit of data that it manipulates is defined as a “strip” (ranging in size from 64 KiB to 256 KiB). These strips are distributed across the physical drives in the array. A "stripe" is one set of strips. Our Smart Array controllers actually configure strips not stripes. You can calculate the stripe size from the strip size, the number of physical drives in the logical drive, and the RAID level.
You can also recombine a split-mirrored array with the ACU. When you recombine a split-mirrored array, you lose access to all data on the second array.
The Smart Array Advanced Pack (SAAP) may be required to use the mirror splitting and recombining functions. For support information regarding mirror splitting on specific controllers, see the controller QuickSpecs.
NOTE: You must split or re-mirror arrays when the server is offline and operating in the standard configuration mode of ACU.
Online drive flash
The present generation Smart Array controllers support online drive flashing, which saves time when updating disk drive firmware. Instead of taking the hard disk drive (HDD) offline before loading a new firmware image, you can download an updated HDD firmware image to the Smart Array controller and update all of the HDDs the next time you reboot the server.
Recovery ROM
HP Smart Array controllers store a redundant copy of the controller firmware image to protect against data corruption. If the active firmware image becomes corrupt, Smart Array controllers use the redundant firmware image and continue operating. The recovery ROM provides protection against power outages during firmware flashing.
Pre-Failure Warranty using S.M.A.R.T technology
We pioneered failure-prediction technology for disk drives by developing monitoring tests run by Smart Array controllers. Called Monitoring and Performance (M&P) or Drive Parameter Tracking, Smart Array controllers externally monitor disk drive attributes such as seek times, spin-up times, and media defects to detect changes that could indicate potential failure.
We worked with the disk drive industry to help develop a diagnostic and failure prediction capability known as Self-Monitoring Analysis and Reporting Technology (S.M.A.R.T.). As S.M.A.R.T. matured, we used both M&P and S.M.A.R.T. to predict disk drive failures.
S.M.A.R.T. has matured to the point that we rely exclusively on this technology to predict disk drive failure to support Pre-Failure Warranty. Since 1997, all HP SCSI, SAS, and SATA server-class disk drives have incorporated S.M.A.R.T. technology. S.M.A.R.T. disk drives inform the host when a disk drive is experiencing abnormal operation likely to lead to drive failure.
S.M.A.R.T. places the monitoring capabilities within the disk drive itself. These monitoring routines are more accurate than the original M&P tests because they have direct access to internal performance, calibration, and error measurements for a specific drive type.
HP Smart Array controllers scan the disk drive media during idle time and rep air, or report, any media defects detected. The controllers recognize S.M.A.R.T. error codes and notify HP Systems Insight Manager (SIM) of a potential problem. HP SIM notifies administrators of drive failures.
Automatic data recovery with rapid rebuild technology
When you replace a disk drive in an array, Smart Array controllers use the fault-tolerance information on the remaining drives in the array to reconstruct the missing data and write it to the replacement drive. If a drive fails during the rebuild, the reconstruction fails and the data is likely to be permanently lost.
The present generation of Smart Array controllers includes rapid rebuild technology for accelerating the rebuild process. Faster rebuild time helps restore logical drives to full fault tolerance before a subsequent drive failure can occur, reducing the risk of data lass.
Generally, a rebuild operation requires approximately 15 to 30 seconds per gigabyte for RAID 5 or RAID
- Actual rebuild time depends on several factors, including the amount of I/O activity occurring during the rebuild operation, the number of disk drives in the logical drive, the rebuild priority setting, and the disk drive performance. ACU lets you view the rebuild progress and set the priority for the rebuild operation.
Online spare
Smart Array controllers let you designate an unlimited number of drives as online spares. Multiple arrays can have the same spare drive as a global spare. Smart Array configuration utilities ensure that SAS disk drives are only spares for SAS arrays and likewise SATA disk drives for SATA arrays. During system operation, these spare drives remain up and running but perform no I/O operations. They are available in case one of the active drives in the array fails. Then an online spare drive may replace the failed drive.
If an active drive fails during system operation, the controller automatically begins rebuilding each fault- tolerant logical drive onto the online spare; no administrator action is required. Once the rebuild operation is complete, the system is fully fault-tolerant once again. You can replace the failed drive at a convenient time. Once you install a replacement drive, the controller will restore data automatically from the failed drive to the new drive. At that point, the original online global spare will return to standby mode.
Dynamic sector repair
Disk drive media can develop defects caused by variances in the drive mechanisms under normal operating conditions. To protect data from media defects, HP built a dynamic sector repair feature into Smart Array controllers.
Smart Array controllers perform a background surface analysis during inactive periods, continually scanning all drives for media defects. Smart Array controllers can also detect media defects when accessing a bad sector during busy periods. If a Smart Array controller finds a recoverable media defect, the controller automatically remaps the bad sector to a reserve area on the disk drive. If the controller finds an unrecoverable media defect and you have configured a fault-tolerant logical drive, the controller automatically regenerates the data and writes it to the remapped reserved area on the disk drive.
ECC protection
HP Smart Array cache modules use ECC technology to protect cache data. The ECC scheme generates 8 bits of check data for every 32 or 64 bits of regular data transferred. The cache module uses this information to detect and correct data errors originating inside the DRAM chip or across the memory bus.
Write caches
Using either the Flash-backed write cache (FBWC) or the battery-backed write cache (BBWC), Smart Array controllers can acknowledge a data transfer as “complete” before the data is physically stored in the disk drive. To improve disk write performance, data is temporarily stored in the write cache, which uses DRAM and is substantially quicker when compared to the disk drive.
Back-up power (FBWC or BBWC) is required for RAID controllers to perform operations such as write-back cache, array expansion, logical drive extension, strip size migration, and RAID migration.
Recovering data from battery-backed cache
If an unexpected server shutdown occurs while data is in the BBWC, Smart Array controllers automatically signal the memory chips to enter a self-refresh state and the controller moves to battery power or system
If it is not possible or desirable to replace the batteries, you have three options to disable write-back cache and avoid losing critical data:
Use the ACU to adjust the read-and-write cache ratio to 100 percent read cache.
Use the ACU to disable the array accelerator for each logical drive, which disables both read-ahead and write-back cache.
Replace an existing RAID controller with a newer Smart Array controller model.
NOTE: If the write cache is off, some write performance degradation may occur.
Flash-backed write cache
HP introduced the flash-backed write-cache (FBWC) system in the fourth quarter of 2009. The FBWC uses flash devices to retain cache data and super-capacitors (Super-caps) instead of batteries to provide power during a power loss. A BBWC must provide power during the entire power loss, while a FBWC only needs to provide power during the time to backup from DRAM to flash. The FBWC offers significant advantages over the HP Battery-backed write-cache (BBWC) system. Since the FBWC writes the contents of memory to flash devices, there is no longer a 48-hour battery life limitation, and the data posts to the disk drive on the next power up.
FBWC architecture
The FBWC DDR2 mini-DIMM cache module is designed for the current generation of PCIe2.0, SAS-based Smart Array controllers based on the PMC PM8011 max SAS SRC 8x6G RAID on a chip (RoC). The primary FBWC components consist of the cache module, Super-caps with integrated charger, and a RoC located on the system board, shown in Figure 1.
Figure 1. FBWC block diagram
FPGA
RoC
NAND Flash NAND Flash
PROM DRAM 8X
DRAM 8X
DRAM 8X
System board
Cache module
System board
Cache module
133 MHZ DDR IF
Register
TWI**
Reg reset N
Reset N
Cache dirty N*
Command & address
Data
400 MHZ DDR IF
Side band control signals
Super-cap
In off-module pack connecting to cache module
4b 33MHz4b 33MHz^ 4b 33MHz4b 33MHz
- Cache tracks written over are “dirty." ** Two-wire interface (TWI)
The FBWC cache module contains a field programmable gate array (FPGA), DDR2 DRAMs, and NAND flash devices that can support up to 1 GB of DDR2 memory and up to 72 data bits (64 data bits plus 8 ECC bits). The FBWC can support up to 800 Mb/s data rate when the Smart Array controller is driving the DDR2 bus. When the FPGA is driving the bus during data recovery, the data rate is 266 Mb/s. The FBWC module connects to the Smart Array controller through a 244-pin mini-DIMM connector.
Super-capacitor
The Super-cap sub-assembly consists of two 35-Farad 2.7V capacitors, configured in series, providing 17 Farads at up to 5.4V. The charger maintains the Super-cap at 4.8V, providing the required amount of power to complete backup operations while extending the life of the Super-cap. The charger monitors Super-cap health and activates LED indicators on the FBWC module to warn of impending failure. The Super-Cap module uses the same form factor and housing as the HP 650 mAh P-Series battery used in the HP BBWC.
Recovering data from the FBWC
When system power is present, the FPGA on FBWC is in its idle state. In the idle state, the FPGA simply monitors the voltage statuses, the resets, and the control signals managed by the Smart Array controller. The FPGA’s DDR2 I/O pins are in “tri-state,” equivalent to a disabled mode, to avoid bus contention. When system power is lost, the FPGA waits for the Smart Array controller’s clock enable signal to transition to low, signaling that the controller has stopped driving the DDR2 bus. The FPGA then assumes control of the bus and begins moving data from the DRAMs to the non-volatile flash memory. Upon the next power up, the FPGA then restores the cache by moving data from the flash memory to the DRAMs.
RAID 6
RAID 6 protects against failure of any two drives. It requires a minimum of four drives, but only two are available for data. RAID 6 can tolerate multiple simultaneous drive failures without downtime or data loss. It is ideal for applications requiring large logical volumes, because it can safely protect a single volume of up to 56 disk drives. RAID 6 also offers lower implementation costs and greater usable capacity per U than RAID 1.
RAID 60
RAID 60 (RAID 6+0) is a nested RAID method that uses RAID 0 block-level striping across multiple RAID 6 arrays with dual distributed parity. RAID 60 lets you split RAID storage across multiple external boxes. It requires a minimum of eight drives, but only four are available for data.
Advanced Capacity Expansion (ACE)
Advanced Capacity Expansion complements the conventional capacity expansion feature of Smart Array controllers by letting you perform two new operations to either shrink or move existing arrays.
The Shrink Array operation allows customers to remove drives from an existing array. The Move Array operation allows you to transfer the contents of a disk array from one set of physical drives to a second set of physical drives.
Mirror splitting and recombining
There are two methods for safely breaking a RAID 1+0 mirror and rebuilding drives. The first method uses the ACU. The ACU splits an array that consists of one or more RAID 1+0 logical drives into two identical new arrays consisting of RAID 0 logical drives. The other option is a manual method, in which the volumes remain in their original RAID 1 or RAID 1+0 configurations after the split. Using the ACU does not require splitting other arrays attached to the controller at the same time. This functionality is useful when replicating a configuration or building a backup before performing a risky operation.
The Array Configuration Utility will show the Split Mirror task as an available option only under all of the following conditions:
The version of ACU and the selected controller support the action
The server is offline
Any applicable SAAP keys have been installed
Drive erase
Securely sanitizing disk drives involves completely overwriting the drive data at the lowest level, below the OS file system and partition tables. With SAS and SATA drives, this means overwriting all of the logical blocks on the drive. HP Smart Array controllers with SAAP include an integrated Erase Drive feature that can erase data without installing additional software. The Smart Array Erase Drive function is available through the ACU for any logical or physical drive in an array.
The Erase Drive function operates by writing zeroes to every logical block on the logical or physical drive. This overwrites all file contents as well as the metadata, including all RAID controller, partition, and file system metadata. At a simplified level, erasing a drive is a serial write process, because the average sequential write throughput of the drive governs the speed. As a result, a drive erase can take several hours to complete on a moderate size drive such as a 500 GB midline SATA drive.
Storage pathway redundancy
Dual Domain support for SAS creates redundant pathways from servers to storage devices. These redundant paths reduce or eliminate single points of failure within the storage network and increase data availability. Dual Domain SAS implementations can tolerate HBA failure, external cable failure, expander failure, or failure in a spanned disk (JBOD).
SAAP-enabled Dual Domain is available on the P411 and P812 Smart Array controllers (SAAP license key required) when used with the HP StorageWorks D2600 or D2700 Disk Enclosures.
Other controllers do not support SAAP, but do support Dual Domain (no license key required). For example, the P700m Smart Array controller attached to either the HP StorageWorks 600 MDS or the HP StorageWorks 2000sa MSA storage enclosure supports Dual Domain. For these configurations you must install two HP 3G SAS BL Switch modules in a c7000 or c3000 blade enclosure.
Dual Domain support is available for the 3 Gb/s HP Smart Array P800 when attached to an HP StorageWorks MSA60/70 with the HP Dual Domain I/O Module Option. Dual Domain support requires HP Smart Array firmware v5.10 or higher and dual-port SAS drives.
Video on Demand (VOD)
Servers delivering video streaming services typically require significant amounts of disk storage. The HP Smart Array engineering teams have made significant strides in using HP technology to optimize Smart Array-based storage for VOD applications or any latency-dependent data flow. These improvements include optimizing for large block random I/O and decreased maximum latency.
Optimizing for large block random I/O improves the application server's ability to grab enough video data on each pass to maintain all the video streams in a rotating data retrieval scheme where a large number of simultaneous video streams exist. VOD performance improvement during this operation is a result of tuning the drive array, the file system, and the VOD application server so that each block request is stripe-aligned.
Decreasing the maximum latency of block requests to the Smart Array is one of the key goals for VOD. Physical Drive Elevator Sorting lets the controller re-order block requests to the physical drives to minimize the drive seek time. While this improves total performance, it can increase the maximum latency. The controller may schedule the execution of an earlier block request behind subsequent requests and execute the requests outside the VOD server’s required time window. Turning off Physical Drive Elevator Sorting decreases the latency variability, which is what the VOD software wants. In a related manner, disabling Monitor and Performance and extending the Background Surface Scan Interval help eliminate spikes in latency that might occur during these background tasks.
Other improvements include changing the cache ratio to be 0 % read and 100 % write. Since VOD operations are 99% random, any read-ahead operation would penalize performance. You want to post the writes so that they have the least impact on the reads. We also found that in a multi-stream environment like VOD, the queuing mechanism in SAS drives delivers significantly better performance than SATA drives.
Another important way to optimize VOD performance in Smart Array-based storage is to enable Degraded Mode Performance (DPO). This decreases changes in latency between normal and degraded modes of operation. We added DPO specifically for VOD.
Storage management
HP Smart Array controllers include built-in intelligence to improve data storage management. This makes it easier for administrators to configure, modify, and manage storage. HP provides six utilities for managing an array on a Smart Array controller:
The Array Configuration Utility is the main configuration tool for HP Smart Array controllers. It exists in three interface formats—the ACU GUI, the ACU CLI, and ACU Scripting. All three formats have separate
The ACU also contains a command line interface (ACU-CLI), offering a quicker way to deploy multiple servers by automating creation of arrays and logical drives.
Option ROM Configuration for Arrays
ORCA is an alternative method of viewing, creating, and deleting multiple arrays and logical drives during system power up. Although ORCA performs all array configuration tasks, it works best with simpler configurations. We recommend the ACU for more advanced array configurations.
CPQONLIN
CPQONLIN is a configuration utility that runs online on Novell NetWare. It functions like the ACU in this environment. Refer to the HP Smart Array controller documentation for more information about using CPQONLIN.
HP Systems Insight Manager
HP Systems Insight Manager is a client/server tool for integrated server environment management. Based on SNMP, it is capable of monitoring more than 1,200 system-wide parameters for performance and other operational characteristics of Smart Array controller storage. The program displays:
Configuration information
Device driver versions
Controller firmware versions
Pre-Failure Warranty information
Operating statistics
HP SIM lets you look at low-level performance characteristics of Smart Array controllers. It monitors three basic Smart Array controller performance parameters:
I/O commands per second
Average command latency
Local processor utilization
Analyzing these key parameters can help you fine-tune your configurations. HP SIM can chart performance over time for each of these parameters. A background task monitoring these parameters notifies HP SIM if a drive fails to meet certain factory-preset criteria. HP SIM alerts the administrator to the potential problem.
Array Diagnostics Utility
ADU is an in-depth diagnostic and reporting utility for all Smart Array controllers. The ADU quickly identifies problems such as incorrect versions of firmware, improperly installed drives, inappropriate error rates, and failed batteries on the array accelerator board.
The ADU displays a detailed analysis of the system configuration. If the cause is not apparent, the ADU can generate a full report for administrators to fax or e-mail to HP customer service for phone support.
Summary
HP Smart Array controllers are powerful I/O solutions for today’s most demanding storage requirements. Our controllers provide solutions for all four primary data storage requirements:
Capacity growth
High performance
Data availability
Manageability
HP is the only server provider with a seamless storage solution set that spans the range from embedded Smart Array controllers in servers to plug-in PCI Smart Array controllers to SAN-attached Modular Smart Arrays storage. The tools used for managing and configuring storage are the same in all of those environments. Data sets are compatible across all of those environments. Smart Array controllers and HP universal drives allow easy migration of data from DAS to SAN.
