16.1 Keyboard
Keyboard is an external device in computer. Keyboard is used to input data in computer system. An application receives keyboard input in the form of messages posted to its windows.
16.1.1 Keyboard Input Model
The system provides device-independent keyboard support for applications by installing a keyboard device driver appropriate for the current keyboard. The system provides language-independent keyboard support by using the language-specific keyboard layout currently selected by the user or the application. The keyboard device driver receives scan codes from the keyboard, which are sent to the keyboard layout where they are translated into messages and posted to the appropriate windows in your application.
Assigned to each key on a keyboard is a unique value called a scan code ; it is a device- dependent identifier for the key on the keyboard. A keyboard generates two scan codes when the user types a key—one when the user presses the key and another when the user releases the key.
The keyboard device driver interprets a scan code and translates (maps) it to a virtual-key code; virtual-key code is a device-independent value defined by the system that identifies the purpose of a key. After translating a scan code, the keyboard layout creates a message that includes the scan code, the virtual-key code, and other information about the keystroke, and then places the message in the system message queue. The system removes the message from the system message queue and posts it to the message queue of the appropriate thread. Eventually, the thread's message loop removes the message and passes it to the appropriate window procedure for processing. The following figure illustrates the keyboard input model.
Figure 1
number of WM_KEYDOWN or WM_SYSKEYDOWN messages in a row. It then generates a single WM_KEYUP or WM_SYSKEYUP message when the user releases the key.
16.1.3.1 System and non system keystrokes
The system makes a distinction between system keystrokes and nonsystem keystrokes. System keystrokes produce system keystroke messages, WM_SYSKEYDOWN and WM_SYSKEYUP. Nonsystem keystrokes produce nonsystem keystroke messages, WM_KEYDOWN and WM_KEYUP.
If your window procedure must process a system keystroke message, make sure that after processing the message, the procedure passes it to the DefWindowProc function. Otherwise, all system operations involving the ALT key will be disabled whenever the window has the keyboard focus, that is, the user won't be able to access the window's menus or System menu, or use the ALT+ESC or ALT+TAB key combination to activate a different window.
System keystroke messages are primarily used by the system rather than by an application. The system uses them to provide its built-in keyboard interface to menus and to allow the user to control which window is active. System keystroke messages are generated when the user types a key in combination with the ALT key, or when the user types and no window has the keyboard focus (for example, when the active application is minimized). In this case, the messages are posted to the message queue attached to the active window.
Nonsystem keystroke messages are used by application windows; the DefWindowProc function does nothing with them. A window procedure can discard any nonsystem keystroke messages that it does not need.
16.1.3.2 Virtual key codes Described
The wParam parameter of a keystroke message contains the virtual-key code of the key that was pressed or released. A window procedure processes or ignores a keystroke message, depending on the value of the virtual-key code.
A typical window procedure processes only a small subset of the keystroke messages that it receives and ignores the rest. For example, a window procedure might process only WM_KEYDOWN keystroke messages, and only those that contain virtual-key codes for the cursor movement keys, shift keys (also called control keys), and function keys. A typical window procedure does not process keystroke messages from character keys. Instead, it uses the TranslateMessage function to convert the message into character messages.
16.1.3.3 Keystroke Message Flags
The lParam parameter of a keystroke message contains additional information about the keystroke that generated the message. This information includes the repeat count, the scan code, the extended-key flag, the context code, the previous key-state flag, and the transition-state flag. The following illustration shows the locations of these flags and values in the lParam parameter.
Figure 2
An application can use the following values to manipulate the keystroke flags.
KF_ALTDOWN Manipulates the ALT key flag, which indicated if the ALT key is pressed.
KF_DLGMODE Manipulates the dialog mode flag, which indicates whether a dialog box is active.
KF_EXTENDED Manipulates the extended key flag.
KF_MENUMODE Manipulates the menu mode flag, which indicates whether a menu is active.
KF_REPEAT Manipulates the repeat count.
KF_UP Manipulates the transition state flag.
Repeat Count
You can check the repeat count to determine whether a keystroke message represents more than one keystroke. The system increments the count when the keyboard generates WM_KEYDOWN or WM_SYSKEYDOWN messages faster than an application can process them. This often occurs when the user holds down a key long enough to start the keyboard's automatic repeat feature. Instead of filling the system message queue with the resulting key-down messages, the system combines the messages into a single key down message and increments the repeat count. Releasing a key cannot start the automatic repeat feature, so the repeat count for WM_KEYUP and WM_SYSKEYUP messages is always set to 1.
and CAPS LOCK keys). It then generates a character message that includes the character code and places the message at the top of the message queue. The next iteration of the message loop removes the character message from the queue and dispatches the message to the appropriate window procedure.
16.1.4.1 Non-system Character Messages
A window procedure can receive the following character messages: WM_CHAR, WM_DEADCHAR, WM_SYSCHAR, WM_SYSDEADCHAR, and WM_UNICHAR. The TranslateMessage function generates a WM_CHAR or WM_DEADCHAR message when it processes a WM_KEYDOWN message. Similarly, it generates a WM_SYSCHAR or WM_SYSDEADCHAR message when it processes a WM_SYSKEYDOWN message.
An application that processes keyboard input typically ignores all but the WM_CHAR and WM_UNICHAR messages, passing any other messages to the DefWindowProc function. Note that WM_CHAR uses 16-bit Unicode transformation format (UTF) while WM_UNICHAR uses UTF-32. The system uses the WM_SYSCHAR and WM_SYSDEADCHAR messages to implement menu mnemonics.
The wParam parameter of all character messages contains the character code of the character key that was pressed. The value of the character code depends on the window class of the window receiving the message. If the Unicode version of the RegisterClass function was used to register the window class, the system provides Unicode characters to all windows of that class. Otherwise, the system provides ASCII character codes. For more information, see Unicode and Character Sets.
The contents of the lParam parameter of a character message are identical to the contents of the lParam parameter of the key-down message that was translated to produce the character message.
16.1.4.2 Dead-Character Messages
Some non-English keyboards contain character keys that are not expected to produce characters by them. Instead, they are used to add a diacritic to the character produced by the subsequent keystroke. These keys are called dead keys. The circumflex key on a German keyboard is an example of a dead key. To enter the character consisting of an "o" with a circumflex, a German user would type the circumflex key followed by the "o" key. The window with the keyboard focus would receive the following sequence of messages:
9 WM_KEYDOWN 9 WM_DEADCHAR 9 WM_KEYUP 9 WM_KEYDOWN 9 WM_CHAR 9 WM_KEYUP
TranslateMessage generates the WM_DEADCHAR message when it processes the WM_KEYDOWN message from a dead key. Although the wParam parameter of the WM_DEADCHAR message contains the character code of the diacritic for the dead key, an application typically ignores the message. Instead, it processes the WM_CHAR message generated by the subsequent keystroke. The WM_CHAR parameter of the WM_CHAR message contains the character code of the letter with the diacritic. If the subsequent keystroke generates a character that cannot be combined with a diacritic, the system generates two WM_CHAR messages. The wParam parameter of the first contains the character code of the diacritic; the wParam parameter of the second contains the character code of the subsequent character key.
The TranslateMessage function generates the WM_SYSDEADCHAR message when it processes the WM_SYSKEYDOWN message from a system dead key (a dead key that is pressed in combination with the ALT key). An application typically ignores the WM_SYSDEADCHAR message.
16.1.5 Key Status
While processing a keyboard message, an application may need to determine the status of another key besides the one that generated the current message. For example, a word- processing application that allows the user to press SHIFT+END to select a block of text must check the status of the SHIFT key whenever it receives a keystroke message from the END key. The application can use the GetKeyState function to determine the status of a virtual key at the time the current message was generated; it can use the GetAsyncKeyState function to retrieve the current status of a virtual key.
The keyboard layout maintains a list of names. The name of a key that produces a single character is the same as the character produced by the key. The name of a noncharacter key such as TAB and ENTER is stored as a character string. An application can retrieve the name of any key from the device driver by calling the GetKeyNameText function.
16.1.6 Key Stroke and Character Translations
The system includes several special purpose functions that translate scan codes, character codes, and virtual-key codes provided by various keystroke messages. These functions include MapVirtualKey , ToAscii , ToUnicode , and VkKeyScan.
16.1.7 Hot-key Support
A hot key is a key combination that generates a WM_HOTKEY message, a message the system places at the top of a thread's message queue, bypassing any existing messages in the queue. Applications use hot keys to obtain high-priority keyboard input from the user. For example, by defining a hot key consisting of the CTRL+C key combination, an application can allow the user to cancel a lengthy operation.
To define a hot key, an application calls the RegisterHotKey function, specifying the combination of keys that generates the WM_HOTKEY message, the handle to the
the LoadKeyboardLayout function with the language to get a layout based on that language.
The ActivateKeyboardLayout function sets the input language for the current task. The hkl parameter can be either the handle to the keyboard layout or a zero-extended language identifier. Keyboard layout handles can be obtained from the LoadKeyboardLayout or GetKeyboardLayoutList function. The HKL_NEXT and HKL_PREV values can also be used to select the next or previous keyboard.
The GetKeyboardLayoutName function retrieves the name of the active keyboard layout for the calling thread. If an application creates the active layout using the LoadKeyboardLayout function, GetKeyboardLayoutName retrieves the same string used to create the layout. Otherwise, the string is the primary language identifier corresponding to the locale of the active layout. This means the function may not necessarily differentiate among different layouts with the same primary language so, it cannot return specific information about the input language. The GetKeyboardLayout function, however, can be used to determine the input language.
The LoadKeyboardLayout function loads a keyboard layout and makes the layout available to the user. Applications can make the layout immediately active for the current thread by using the KLF_ACTIVATE value. An application can use the KLF_REORDER value to reorder the layouts without also specifying the KLF_ACTIVATE value. Applications should always use the KLF_SUBSTITUTE_OK value when loading keyboard layouts to ensure that the user's preference, if any, is selected.
For multilingual support, the LoadKeyboardLayout function provides the KLF_REPLACELANG and KLF_NOTELLSHELL flags. The KLF_REPLACELANG flag directs the function to replace an existing keyboard layout without changing the language. Attempting to replace an existing layout using the same language identifier but without specifying KLF_REPLACELANG is an error. The KLF_NOTELLSHELL flag prevents the function from notifying the shell when a keyboard layout is added or replaced. This is useful for applications that add multiple layouts in a consecutive series of calls. This flag should be used in all but the last call.
The UnloadKeyboardLayout function is restricted in that it cannot unload the system default input language. This ensures that the user always has one layout available for enter text using the same character set as used by the shell and file system.
16.1.9 Keyboard Messages ( brief )
The following are some of the keyboard messages.
WM_KEYDOWN: when the key down WM_KEYUP: when the key up WM_SYSKEYDOWN: when the system key down, e.g. ALT key
WM_SYSKEYUP: when the system key up
When user press Ctrl + key then two messages of WM_KEYDOWN and two messages WM_KEYUP are sent to the Application Message Queue.
16.1.10 Key down message format
The WM_KEYDOWN message is posted to the window with the keyboard focus when a nonsystem key is pressed. A nonsystem key is a key that is pressed when the ALT key is not pressed.
WM_KEYDOWN
WPARAM wParam //wParam of the key down
LPARAM lParam; /*lParam of the key down
messages*/
wParam: Specifies the virtual-key code of the nonsystem key.
lParam: Specifies the repeat count, scan code, extended-key flag, context code, previous key-state flag, and transition-state flag, as shown in the following table.
0-15: Specifies the repeat count for the current message. The value is the number of times the keystroke is autorepeated as a result of the user holding down the key. If the keystroke is held long enough, multiple messages are sent. However, the repeat count is not cumulative. 16-23: Specifies the scan code. The value depends on the OEM. 24: Specifies whether the key is an extended key, such as the right-hand ALT and CTRL keys that appear on an enhanced 101- or 102-key keyboard. The value is 1 if it is an extended key; otherwise, it is 0. 25-28: Reserved; do not use. 29: Specifies the context code. The value is always 0 for a WM_KEYDOWN message. 30: Specifies the previous key state. The value is 1 if the key is down before the message is sent, or it is zero if the key is up. 31: Specifies the transition state. The value is always zero for a WM_KEYDOWN message.
16.1.11 Character message format
The WM_CHAR message is posted to the window with the keyboard focus when a WM_KEYDOWN message is translated by the TranslateMessage function. The WM_CHAR message contains the character code of the key that was pressed.
16.1.13 Character Message Processing
Figure 3
16.2 Caret
A caret is a blinking line, block, or bitmap in the client area of a window. The caret typically indicates the place at which text or graphics will be inserted.
The system provides one caret per message queue. A window should create a caret only when it has the keyboard focus or is active. The window should destroy the caret before losing the keyboard focus or becoming inactive.
Use the CreateCaret function to specify the parameters for a caret. The system forms a caret by inverting the pixel color within the rectangle specified by the caret's position, width, and height. The width and height are specified in logical units; therefore, the appearance of a caret is subject to the window's mapping mode.
Enter Key Pressed
WM_CHAR Message Generated wParam contains ‘\n’ OR 0x0A OR 10
WM_KEYDOWN Message generated
TranslateMessage() is called
16.2.1 Caret Visibility
After the caret is defined, use the ShowCaret function to make the caret visible. When the caret appears, it automatically begins flashing. To display a solid caret, the system inverts every pixel in the rectangle; to display a gray caret, the system inverts every other pixel; to display a bitmap caret, the system inverts only the white bits of the bitmap.
16.2.2 Caret Blink Time
The elapsed time, in milliseconds, required to invert the caret is called the blink time. The caret will blink as long as the thread that owns the message queue has a message pump processing the messages.
The user can set the blink time of the caret using the Control Panel and applications should respect the settings that the user has chosen. An application can determine the caret's blink time by using the GetCaretBlinkTime function. If you are writing an application that allows the user to adjust the blink time, such as a Control Panel applet, use the SetCaretBlinkTime function to set the rate of the blink time to a specified number of milliseconds.
The flash time is the elapsed time, in milliseconds, required to display, invert, and restore the caret's display. The flash time of a caret is twice as much as the blink time.
16.2.3 Caret Position
You can determine the position of the caret using the GetCaretPos function. The position, in client coordinates, is copied to a structure specified by a parameter in GetCaretPos. An application can move a caret in a window by using the SetCaretPos function. A window can move a caret only if it already owns the caret. SetCaretPos can move the caret whether it is visible or not.
16.2.4 Removing a Caret
You can temporarily remove a caret by hiding it, or you can permanently remove the caret by destroying it. To hide the caret, use the HideCaret function. This is useful when your application must redraw the screen while processing a message, but must keep the caret out of the way. When the application finishes drawing, it can display the caret again by using the ShowCaret function. Hiding the caret does not destroy its shape or invalidate the insertion point. Hiding the caret is cumulative, that is, if the application calls HideCaret five times, it must also call ShowCaret five times before the caret will reappear.
To remove the caret from the screen and destroy its shape, use using the DestroyCaret function. DestroyCaret destroys the caret only if the window involved in the current task owns the caret.
When the mouse captures changes, the system sends a WM_CAPTURECHANGED message to the window that is losing the mouse capture. The lParam parameter of the message specifies a handle to the window that is gaining the mouse capture.
Only the foreground window can capture mouse input. When a background window attempts to capture mouse input, it receives messages only for mouse events that occur when the cursor hot spot is within the visible portion of the window.
Capturing mouse input is useful if a window must receive all mouse input, even when the cursor moves outside the window. For example, an application typically tracks the cursor position after a mouse button down event, following the cursor until a mouse button up event occurs. If an application has not captured mouse input and the user releases the mouse button outside the window, the window does not receive the button-up message.
A thread can use the GetCapture function to determine whether one of its windows has captured the mouse. If one of the thread's windows has captured the mouse, GetCapture retrieves a handle to the window.
16.3.3 Mouse Configuration
Although the mouse is an important input device for applications, not every user necessarily has a mouse.
An application can determine whether the system includes a mouse by passing the SM_MOUSEPRESENT value to the GetSystemMetrics function.
Windows supports a mouse having up to three buttons. On a three-button mouse, the buttons are designated as the left, middle, and right buttons. Messages and named constants related to the mouse buttons use the letters L, M, and R to identify the buttons. The button on a single-button mouse is considered to be the left button. Although Windows supports a mouse with multiple buttons, most applications use the left button primarily and the others minimally, if at all.
An application can determine the number of buttons on the mouse by passing the SM_CMOUSEBUTTONS value to the GetSystemMetrics function.
To configure the mouse for a left-handed user, the application can use the SwapMouseButton function to reverse the meaning of the left and right mouse buttons. Passing the SPI_SETMOUSEBUTTONSWAP value to the SystemParametersInfo function is another way to reverse the meaning of the buttons. Note, however, that the mouse is a shared resource, so reversing the meaning of the buttons affects all applications
16.3.4 Mouse Messages
The mouse generates an input event when the user moves the mouse, or presses or releases a mouse button. The system converts mouse input events into messages and
posts them to the appropriate thread's message queue. When mouse messages are posted faster than a thread can process them, the system discards all but the most recent mouse message.
A window receives a mouse message when a mouse event occurs while the cursor is within the borders of the window, or when the window has captured the mouse. Mouse messages are divided into two groups: client area messages and nonclient area messages. Typically, an application processes client area messages and ignores nonclient area messages.
16.3.4.1 Client Area Mouse Messages
A window receives a client area mouse message when a mouse event occurs within the window's client area. The system posts the WM_MOUSEMOVE message to the window when the user moves the cursor within the client area. It posts one of the following messages when the user presses or releases a mouse button while the cursor is within the client area.
Message Meaning
WM_LBUTTONDBLCLK The left mouse button was double-clicked.
WM_LBUTTONDOWN The left mouse button was pressed.
WM_LBUTTONUP The left mouse button was released.
WM_MBUTTONDBLCLK The middle mouse button was double-clicked.
WM_MBUTTONDOWN The middle mouse button was pressed.
WM_MBUTTONUP The middle mouse button was released.
WM_RBUTTONDBLCLK The right mouse button was double-clicked.
WM_RBUTTONDOWN The right mouse button was pressed.
WM_RBUTTONUP The right mouse button was released.
In addition, an application can call the TrackMouseEvent function to have the system send two other messages. It posts the WM_MOUSEHOVER message when the cursor hovers over the client area for a certain time period. It posts the WM_MOUSELEAVE message when the cursor leaves the client area.
Message Parameters
The lParam parameter of a client area mouse message indicates the position of the cursor hot spot. The low-order word indicates the x-coordinate of the hot spot, and the high- order word indicates the y-coordinate. The coordinates are specified in client coordinates. In the client coordinate system, all points on the screen are specified relative to the coordinates (0, 0) of the upper-left corner of the client area.
¾ WM_LBUTTONDOWN
¾ WM_LBUTTONUP
¾ WM_LBUTTONDBLCLK
¾ WM_LBUTTONUP
Because a window always receives a button-down message before receiving a double- click message, an application typically uses a double-click message to extend a task it began during a button-down message. For example, when the user clicks a color in the color palette of Microsoft Paint, Paint displays the selected color next to the palette. When the user double-clicks a color, Paint displays the color and opens the Edit Colors dialog box.
16.3.4.2 Non Client Area Mouse Messages
A window receives a nonclient area mouse message when a mouse event occurs in any part of a window except the client area. A window's nonclient area consists of its border, menu bar, title bar, scroll bar, window menu, minimize button, and maximize button.
The system generates nonclient area messages primarily for its own use. For example, the system uses nonclient area messages to change the cursor to a two-headed arrow when the cursor hot spot moves into a window's border. A window must pass nonclient area mouse messages to the DefWindowProc function to take advantage of the built-in mouse interface.
There is a corresponding nonclient area mouse message for each client area mouse message. The names of these messages are similar except that the named constants for the nonclient area messages include the letters NC. For example, moving the cursor in the nonclient area generates a WM_NCMOUSEMOVE message, and pressing the left mouse button while the cursor is in the nonclient area generates a WM_NCLBUTTONDOWN message.
The lParam parameter of a nonclient area mouse message is a structure that contains the x- and y-coordinates of the cursor hot spot. Unlike coordinates of client area mouse messages, the coordinates are specified in screen coordinates rather than client coordinates. In the screen coordinate system, all points on the screen are relative to the coordinates (0,0) of the upper-left corner of the screen.
The wParam parameter contains a hit-test value, a value that indicates where in the nonclient area the mouse event occurred.
16.3.4.3 The WM_NCHITTEST Message
Whenever a mouse event occurs, the system sends a WM_NCHITTEST message to either the window that contains the cursor hot spot or the window that has captured the mouse. The system uses this message to determine whether to send a client area or nonclient area mouse message. An application that must receive mouse movement and
mouse button messages must pass the WM_NCHITTEST message to the DefWindowProc function.
The lParam parameter of the WM_NCHITTEST message contains the screen coordinates of the cursor hot spot. The DefWindowProc function examines the coordinates and returns a hit-test value that indicates the location of the hot spot. The hit- test value can be one of the following values.
Value Location of hot spot
HTBORDER In the border of a window that does not have a sizing border.
HTBOTTOM In the lower-horizontal border of a window.
HTBOTTOMLEFT In the lower-left corner of a window border.
HTBOTTOMRIGHT In the lower-right corner of a window border.
HTCAPTION In a title bar.
HTCLIENT In a client area.
HTCLOSE In a Close button.
HTERROR
On the screen background or on a dividing line between windows (same as HTNOWHERE, except that the DefWindowProc function produces a system beep to indicate an error).
HTGROWBOX In a size box (same as HTSIZE).
HTHELP In a Help button.
HTHSCROLL In a horizontal scroll bar.
HTLEFT In the left border of a window.
HTMENU In a menu.
HTMAXBUTTON In a Maximize button.
HTMINBUTTON In a Minimize button.
HTNOWHERE On the screen background or on a dividing line between windows.
HTREDUCE In a Minimize button.
HTRIGHT In the right border of a window.
HTSIZE In a size box (same as HTGROWBOX).
HTSYSMENU In a System menu or in a Close button in a child window.
HTTOP In the upper-horizontal border of a window.
HTTOPLEFT In the upper-left corner of a window border.
HTTOPRIGHT In the upper-right corner of a window border.
HTTRANSPARENT In a window currently covered by another window in the same thread.
HTVSCROLL In the vertical scroll bar.
HTZOOM In a Maximize button.
If the cursor is in the client area of a window, DefWindowProc returns the HTCLIENT hit-test value to the window procedure. When the window procedure returns this code to
