Configuration
Management
with Puppet
Introduction
What is Puppet
● is a configuration management system
● is a programming language
● offers a Client/Server architecture
● has a huge community
● widely used in the IT industry
● commercial support available if needed
Puppet process - Step 1
registration
Example: foreman, satellite, spacewalk ... Creates: Kickstart File and Puppet Node definition
Puppet process - Step 2
provisioning
Tool: Redhat anaconda, Ubuntu Fai, cobbler, preseed Input: anaconda configured by kickstart file preseed config file … Result: Installing minimal linux and puppet, and start Puppet after reboot
Contents
● Resources
● Manifests
● Ordering
● Variables, Conditionals, and Facts
● Classes
● Module
Resources
All elements of a node will be described as
resources
● Files
● User
● Services
● ... (about 50)
Example Resource
user { 'dave':
ensure => present,
uid => '507',
gid => 'admin',
shell => '/bin/zsh',
home => '/home/dave',
managehome => true,
Ressource shell
You can interact with the RAL directly.
● puppet resource user root
● puppet resource user dave \
ensure=present shell="/bin/zsh" \
home="/home/dave" managehome=true
Resource basic
● file vs. augeas
● yumrepo stages
● package ensure latest?
● exec only if needed
Manifests
● manifests are puppet programs
● puppet programs
○ declare resources
○ define conditions
○ group resources
○ generate text
○ link other manifests
○ define ordering
Manifests Run
actual status defined status
Puppet Action
/etc/service.conf
/etc/init.d/service: not running /etc/init.d/service: running
write file
start service
no file /etc/service.conf /etc/service.conf
start service
Manifests example!
file {'/tmp/test1': ensure => present, content => "Hi.", }
file {'/tmp/test2': ensure => directory, mode => 0644, }
file {'/tmp/test3': ensure => link, target => '/tmp/test1', }
notify {"I'm notifying you.":} notify {"So am I!":}
Facts example!
host {'self': ensure => present, name => $fqdn, host_aliases => [ 'puppet', $hostname ] , ip => $ipaddress, }
file {'motd': ensure => file, path => '/etc/motd', mode => 0644, content => "Welcome to ${hostname},\na ${operatingsystem} island in the sea of ${domain}.\n", }
Conditionals a first example!
if $is_virtual == 'true' { service {'ntpd': ensure => stopped, enable => false , } } else { service { 'ntpd': name => 'ntpd', ensure => running, enable => true , hasrestart => true , require => Package [ 'ntp' ] , } }
