The Human
Course: Human Computer Interaction
the human
- (^) Information i/o …
- (^) visual, auditory, haptic, movement
- (^) Information stored in memory
- (^) sensory, short-term, long-term
- (^) Information processed and applied
- (^) reasoning, problem solving, skill, error
- (^) Emotion influences human capabilities
- (^) Each person is different
The Eye - physical reception
- (^) mechanism for receiving light and
transforming it into electrical energy
- (^) light reflects from objects
- (^) images are focused upside-down on
retina
- (^) retina contains rods for low light vision
and cones for colour vision
- (^) ganglion cells (brain!) detect pattern
and movement
Interpreting the signal
- (^) Size and depth
- (^) visual angle indicates how much of view
object occupies
(relates to size and distance from eye)
- (^) visual acuity is ability to perceive detail (limited)
- (^) familiar objects perceived as constant size (in spite of changes in visual angle when far away)
- (^) cues like overlapping help perception of
size and depth
Interpreting the signal (cont)
- (^) The visual system compensates for:
- (^) movement
- (^) changes in luminance.
- (^) Context is used to resolve ambiguity
- (^) Optical illusions sometimes occur due to
over compensation
Optical Illusions
the Ponzo illusion the Muller Lyer illusion
Hearing
- (^) Provides information about environment: distances, directions, objects etc.
- (^) Physical apparatus:
- (^) outer ear – protects inner and amplifies sound
- (^) middle ear – transmits sound waves as vibrations to inner ear
- (^) inner ear – chemical transmitters are released and cause impulses in auditory nerve
- (^) Sound
- (^) pitch – sound frequency
- (^) loudness – amplitude
- timbre – type or quality
Hearing (cont)
- (^) Humans can hear frequencies from 20Hz to
15kHz
- (^) less accurate distinguishing high frequencies than low.
- (^) Auditory system filters sounds
- (^) can attend to sounds over background noise.
- (^) for example, the cocktail party phenomenon.
Movement
- (^) Time taken to respond to stimulus:
reaction time + movement time
- (^) Movement time dependent on age, fitness etc.
- (^) Reaction time - dependent on stimulus type:
- (^) visual ~ 200ms
- (^) auditory ~ 150 ms
- (^) pain ~ 700ms
- (^) Increasing reaction time decreases accuracy in
the unskilled operator but not in the skilled
operator.
Movement (cont)
- Fitts' Law describes the time taken to hit a
screen target:
Mt = a + b log
2
(D/S + 1)
where: a and b are empirically determined constants Mt is movement time D is Distance S is Size of target
targets as large as possible
distances as small as possible
sensory memory
- (^) Buffers for stimuli received through
senses
- (^) iconic memory: visual stimuli
- (^) echoic memory: aural stimuli
- (^) haptic memory: tactile stimuli
- (^) Examples
- (^) “sparkler” trail
- (^) stereo sound
- (^) Continuously overwritten
Short-term memory (STM)
- (^) Scratch-pad for temporary recall
- (^) rapid access ~ 70ms
- (^) rapid decay ~ 200ms
- (^) limited capacity - 7± 2 chunks
Long-term memory (LTM)
- (^) Repository for all our knowledge
- (^) slow access ~ 1/10 second
- (^) slow decay, if any
- (^) huge or unlimited capacity
- (^) Two types
- (^) episodic – serial memory of events
- (^) semantic – structured memory of facts,concepts, skills semantic LTM derived from episodic LTM
Long-term memory (cont.)
- (^) Semantic memory structure
- (^) provides access to information
- (^) represents relationships between bits of information
- (^) supports inference
- (^) Model: semantic network
- (^) inheritance – child nodes inherit properties of parent nodes
- (^) relationships between bits of information explicit
- (^) supports inference through inheritance
