Magnetic
Levitation
System
Group Members
- (^) 211952 M Sufyan Tariq
- (^) 212097 Ahmad Mehmood
- (^) 210171 Ahmed Raza
Key Parameters and
Adjustments
- (^) Parameters Considered:
- Mass of the object (0.0185 kg), resistance (18.2 ฮฉ), inductance (58.1 mH), gravitational constant, and magnetic force constant.
- (^) PID Tuning:
- Initial PID values (Kp = 995.5, Ki = 2825.5, Kd = 183.9) caused system instability.
- (^) Adjustments: Gains reduced by a factor of 1000 to stabilize the system.
Simulink Model
- (^) Values set in PID controller are ๐ = 995.5, ๐ผ = 2825.5 and ๐ท = 183. Ts= 2.5s
Simulation Result
- (^) If there are big oscillations before settling, the system may become unstable in practice because the oscillations can Overload the Hardware.
- (^) For this reason, we reduced PID values by a factor of 1000.
- (^) P = 0.9955,I = 2.8255 and D = 0.
Conclusion
- (^) The project aimed to apply Proportional-Integral- Derivative (PID) control theory and program it into a functional, real-world prototype.
- (^) After reducing the PID gains by 1000, the system achieved significant stabilization, resulting in the final gains of ๐พ๐ = 0.9955, ๐พ๐ = 2.8255, and ๐พ๐ = 0.1839.
- (^) However, minor oscillations were observed in the system due to external factors like the electromagnet overheating over time. Further finetuning of the PID gains may be necessary to minimize these oscillations.
