Numerical Methods by Norhayati Rosli
Numerical Methods
Ordinary Differential Equations:
Boundary Value Problems (BVP)
by
Norhayati Rosli
Faculty of Industrial Sciences & Technology
[email protected]
Numerical Methods by Norhayati Rosli
Description
Students should be able to solve boundary value problems using shooting method and finite difference method.
AIMS
EXPECTED OUTCOMES
- Norhayati Rosli, Nadirah Mohd Nasir, Mohd Zuki Salleh, Rozieana Khairuddin, Nurfatihah Mohamad Hanafi, Noraziah Adzhar. Numerical Methods, Second Edition, UMP, 2017 (Internal use)
- Chapra, C. S. & Canale, R. P. Numerical Methods for Engineers , Sixth Edition, McGraw– Hill, 2010.
REFERENCES
This chapter is aimed to solve boundary value problems of second order ODEs by using two different types of methods involving shooting method and finite difference method.
Numerical Methods by Norhayati Rosli
INTRODUCTION
In initial value problem, the condition is specified at the same value of the independent variable. However, for boundary value problem (BVP), the conditions are specified at different values of the independent variables. In a nutshell, a BVP is a problem, typically ODE which has values assigned on the physical boundary of the domain.
2
2 ( ,^ ,^ '),^ [ ,^ ]
( ) , ( )
d y f x y y x a b dx
y a y b
General Form of ODEs (BVP)
Numerical Methods by Norhayati Rosli
Numerical Methods for Solving ODEs (IVP)
INTRODUCTION (Cont.)
Two Types
of Methods
Finite Difference Method Shooting Method
Most of ODEs (BVP) cannot be solved analytically. Its due to the complexity form of the equations. Numerical methods offer a viable option to solve ODEs (BVP).
Numerical Methods by Norhayati Rosli
Shooting Method Procedures
Step 1
Reduce the second order ODE (BVP) of equation to a system of first order ODE (IVP). The second order ODE is transformed into a system of two first order ODEs as
SHOOTING METHOD (Cont.)
Step 2
Determine the initial value. The boundary value at the first point of the domain is known and is used as one initial value of the system. The additional initial value that required for solving the system is guessed.
1 0 0 2 2 2 0 0
( , , ) , ( ) or ( )
( , , ) , ( )
dy f x y z z y x y y a dx dz d y f x y z z x z dx dx
Numerical Methods by Norhayati Rosli
Shooting Method Procedures (Cont.)
SHOOTING METHOD (Cont.)
Step 3
The equivalent system of initial value problem is then solved via Euler’s method, RK2 method or RK4 method. However, in this course only Euler’s method shall be considered.
Step 4
The solution obtained at the end point of the domain is compared with the boundary condition. If the numerical solution is differ from the boundary condition, the guess initial value is changed, and the system is solved again.
Numerical Methods by Norhayati Rosli
SHOOTING METHOD (Cont.)
Example 1
Use the Shooting method to approximate the solution of the boundary value problem
Let the first guess, 𝑧 0 = −1.5 and the second guess, 𝑧 0 = −1.
Solution
Step 1 Reduce the second order ODE (BVP) to a system of first order ODE (IVP).
y ''( )x 2 ( )y x 0, y (0) 1.2, y (1.0) 0.9, h0.
1
2
( , , )
( , , ) 2
f x y z dy z dx dz f x y z y dx
Numerical Methods by Norhayati Rosli
SHOOTING METHOD (Cont.)
Solution (Cont.)
Given 𝑥 0 = 0 , 𝑦 0 = 1. 2 , 𝑧 0 , approximate the system of first order ODE via Step 2 Euler method.
Numerical Methods by Norhayati Rosli
SHOOTING METHOD (Cont.)
Solution (Cont.)
Step 4
𝑦(1.0) ≈ 0.9938 ≠ 0.9. Extrapolate the initial value using linear extrapolate formula
1.0 ( 1.5) (0) 1.5 (0.9 0.4312) 0.9938 0.
z
Numerical Methods by Norhayati Rosli
SHOOTING METHOD (Cont.)
Solution (Cont.)
The equivalent system of initial value problem is then solved via Euler’s method
Step 5
Since, 𝑦 4 = 𝑦( 1. 0 ) = 0. 9 (same with boundary condition), the solutions that were obtained in Step 5 is acceptable.
Therefore, 𝑦( 0 ) = 1. 2 ; 𝑦( 0. 25 ) ≈ 0. 9292 ; 𝑦( 0. 5 ) ≈ 0. 8083 ; 𝑦( 0. 75 ) ≈ 0. 8036 and 𝑦( 1. 0 ) = 0. 9.
Numerical Methods by Norhayati Rosli
FINITE DIFFERENCE METHOD
(Cont.)
Boundary values 𝑦 0 and 𝑦𝑛 are known. The approximate values of 𝑦𝑖 for 𝑖 = 1 , 2 , … , 𝑛 − 1 is computed. In finite difference method, a general form of second order ODE at the interior mesh points 𝑥 = 𝑥𝑖 for 𝑖 = 1 , 2 , … , 𝑛 − 1.
or
i i i i i i
i i i i i i
y x p x y x q x y x r x
y p y q y r
General Form Second Order ODEs
Numerical Methods by Norhayati Rosli
FINITE DIFFERENCE METHOD
(Cont.)
By using central difference formulas for first and second derivatives:
Substituting the first and second derivatives in general form of second order ODEs (BVP)
2 1 1 2 2
1 1
2
2
i i i
i i
d y^ y^ y^ y dx x dy y y dx x
1 1 1 1 2
2 . 2
i i i i i i i i i
y y y y y p q y r x x
^ ^ (^)
Finite Difference Method: Formula
Numerical Methods by Norhayati Rosli
FINITE DIFFERENCE METHOD
(Cont.)
Finite Difference Method: Tridiagonal System
Transforming the simultaneous algebraic equations into Tridiagonal system
where 𝑑𝑖, 𝑒𝑖 and 𝑐𝑖 for 𝑖 = 1 , 2 , … , 𝑛 − 1 are the coefficients of 𝑦 1 , … , 𝑦𝑛− 1.
1 1 1 1
2 2 2 2 2
1 1 1 1
0 0
0
(^0 0)
(^) n^ n^ n^ n
d e y b
c d e y b
c d y b
Numerical Methods by Norhayati Rosli
FINITE DIFFERENCE METHOD
(Cont.)
Finite Difference Method: Thomas Algorithm
i di ci i 1 1 d 1
i
i i
e
i
i i i i
b c w
w
^1
1
1 1
b
w
yi wi (^) i yi 1 yn (^) 1 wn 1
Thomas Algorithm Formula
Applying Direct Methods of solving linear algebraic equations or Thomas Algorithm
