Addressing modes are an aspect of the instruction set architecture in most central processing unit (CPU) designs. The various addressing modes that are defined in a given instruction set architecture define how machine language instructions in that architecture identify the operand(s) of each instruction. An addressing mode specifies how to calculate the effective memory address of an operand by using
information held in registers and/or constants contained within a machine instruction or elsewhere.
In computer programming, addressing modes are primarily of interest to compiler writers and to those who write in assembly languages.
Note that there is no generally accepted way of naming the various addressing modes. In particular, different authors and computer manufacturers may give different names to the same addressing mode, or the same names to different
the instruction. Thus, the latter machines have three distinct instruction codes for copying one register to another, copying a literal constant into a register, and copying the contents of a memory location into a register, while the VAX has only a single "MOV" instruction.
The term "addressing mode" is itself subject to different interpretations: either "memory address calculation mode" or "operand accessing mode". Under the first interpretation, instructions that do not read from memory or write to memory (such as "add literal to register") are considered not to have an "addressing mode". The second
interpretation allows for machines such as VAX which use operand mode bits to allow for a register or for a literal operand. Only the first interpretation applies to instructions such as "load effective address".
The addressing modes listed below are divided into code addressing and data addressing. Most computer architectures maintain this distinction, but there are, or have been, some architectures which allow (almost) all addressing modes to be used in any context.
proven[3][4][5]^ much easier to design pipelined CPUs if the only addressing modes available are simple ones.
Most RISC architectures have only about five simple addressing modes, while CISC architectures such as the DEC VAX have over a dozen addressing modes, some of which are quite complicated. The IBM System/360 architecture had only three addressing modes; a few more have been added for the System/390.
When there are only a few addressing modes, the particular addressing mode required is usually encoded within the
instruction code (e.g. IBM System/360 and successors, most RISC). But when there are lots of addressing modes, a specific field is often set aside in the instruction to specify the addressing mode. The DEC VAX allowed multiple memory operands for almost all instructions, and so reserved the first few bits of each operand specifier to indicate the addressing mode for that particular operand. Keeping the addressing mode specifier bits separate from the opcode operation bits produces an orthogonal instruction set.
Even on a computer with many addressing modes, measurements of actual
of the effective operand address, but instead of acting on that memory location, it loads the address that would have been accessed into a register. This can be useful when passing the address of an array element to a subroutine. It may also be a slightly sneaky way of doing more calculations than normal in one instruction; for example, using such an instruction with the addressing mode "base+index+offset" (detailed below) allows one to add two registers and a constant together in one instruction.
|jump| address | +----+------------------- -----------+
(Effective PC address = address)
The effective address for an absolute instruction address is the address parameter itself with no modifications.
The effective address for a PC-relative instruction address is the offset parameter added to the address of the next instruction. This offset is usually signed to allow reference to code both before and after the instruction.
This is particularly useful in connection with jumps, because typical jumps are to nearby instructions (in a high-level language most if or while statements are reasonably short). Measurements of actual programs suggest that an 8 or 10 bit offset is large enough for some 90% of conditional jumps (roughly ±128 or ± bytes).[10]
Another advantage of PC-relative addressing is that the code may be position-independent, i.e. it can be loaded anywhere in memory without the need to adjust any addresses.
Some versions of this addressing mode may be conditional referring to two registers ("jump if reg1=reg2"), one register ("jump unless reg1=0") or no registers, implicitly referring to some previously-set bit in the status register. See also conditional execution below.
Many RISC machines, as well as the CISC IBM System/360 and successors, have subroutine call instructions that place the return address in an address register—the register-indirect addressing mode is used to return from that subroutine call.
| nop | execute the following instruction +------+
(Effective PC address = next instruction address)
The CPU, after executing a sequential instruction, immediately executes the following instruction.
Sequential execution is not considered to be an addressing mode on some computers.
Most instructions on most CPU architectures are sequential instructions. Because most instructions are sequential instructions, CPU designers often add features that deliberately sacrifice
the same final results, even though that's not exactly what happens internally.
Each "basic block" of such sequential instructions exhibits both temporal and spatial locality of reference.
CPUs that do not use sequential execution
CPUs that do not use sequential execution with a program counter are extremely rare. In some CPUs, each instruction always specifies the address of next instruction. Such CPUs have an instruction pointer that holds that specified address; it is not a program counter because there is no
provision for incrementing it. Such CPUs include some drum memory computers such as the IBM 650, the SECD machine, and the RTX 32P.[11]
Other computing architectures go much further, attempting to bypass the von Neumann bottleneck using a variety of alternatives to the program counter.
Some computer architectures have conditional instructions (such as ARM, but no longer for all instructions in 64-bit mode) or conditional load instructions
