An instruction set architecture ( ISA ) is an abstract model of a computer. It is also referred to as architecture or computer architecture. A realization of an ISA is called an implementation. An ISA permits multiple implementations that may vary in performance, physical size, and monetary cost (among other things); because the
ISA serves as the interface between software and hardware. Software that has been written for an ISA can run on different implementations of the same ISA. This has enabled binary compatibility between different generations of computers to be easily achieved, and the development of computer families. Both of these developments have helped to lower the cost of computers and to increase their applicability. For these reasons, the ISA is one of the most important abstractions in computing today.
An ISA defines everything a machine language programmer needs to know in
techniques used, in a particular processor, to implement the instruction set. Processors with different microarchitectures can share a common instruction set. For example, the Intel Pentium and the Advanced Micro Devices Athlon implement nearly identical versions of the x86 instruction set, but have radically different internal designs.
The concept of an architecture , distinct from the design of a specific machine, was developed by Fred Brooks at IBM during the design phase of System/360.
machines execute less frequently used code paths by interpretation (see: Just-in- time compilation). Transmeta implemented the x86 instruction set atop VLIW processors in this fashion.
An ISA may be classified in a number of different ways. A common classification is by architectural complexity. A complex instruction set computer (CISC) has many specialized instructions, some of which may only be rarely used in practical programs. A reduced instruction set computer (RISC) simplifies the processor
by efficiently implementing only the instructions that are frequently used in programs, while the less common operations are implemented as subroutines, having their resulting additional processor execution time offset by infrequent use.[2]
Other types include very long instruction word (VLIW) architectures, and the closely related long instruction word (LIW) and explicitly parallel instruction computing (EPIC) architectures. These architectures seek to exploit instruction-level parallelism with less hardware than RISC and CISC by
particular registers for arithmetic, addressing, or control functions particular memory locations or offsets particular addressing modes used to interpret the operands
More complex operations are built up by combining these simple instructions, which are executed sequentially, or as otherwise directed by control flow instructions.
Examples of operations common to many instruction sets include:
Data handling and memory operations
Set a register to a fixed constant value. Copy data from a memory location to a register, or vice versa (a machine instruction is often called move ; however, the term is misleading). Used to store the contents of a register, result of a computation, or to retrieve stored data to perform a computation on it later. Often called load and store operations. Read and write data from hardware devices.
Arithmetic and logic operations
are equal). Floating-point instructions for arithmetic on floating-point numbers.
Control flow operations
Branch to another location in the program and execute instructions there. Conditionally branch to another location if a certain condition holds. Indirectly branch to another location. Call another block of code, while saving the location of the next instruction as a point to return to.
Coprocessor instructions
Load/store data to and from a coprocessor, or exchanging with CPU registers. Perform coprocessor operations.
Processors may include "complex" instructions in their instruction set. A single "complex" instruction does something that may take many instructions on other computers. Such instructions are typified by instructions that take multiple steps, control multiple functional units, or otherwise appear on a larger scale than the bulk of simple
performing an atomic test-and-set instruction or other read-modify-write atomic instruction instructions that perform ALU operations with an operand from memory rather than a register
Complex instructions are more common in CISC instruction sets than in RISC instruction sets, but RISC instruction sets may include them as well. RISC instruction sets generally do not include ALU operations with memory operands, or instructions to move large blocks of memory, but most RISC instruction sets include SIMD or vector instructions that
perform the same arithmetic operation on multiple pieces of data at the same time. SIMD instructions have the ability of manipulating large vectors and matrices in minimal time. SIMD instructions allow easy parallelization of algorithms commonly involved in sound, image, and video processing. Various SIMD implementations have been brought to market under trade names such as MMX, 3DNow!, and AltiVec.
addressing modes determining their meaning or may be in fixed fields. In very long instruction word (VLIW) architectures, which include many microcode architectures, multiple simultaneous opcodes and operands are specified in a single instruction.
Some exotic instruction sets do not have an opcode field, such as transport triggered architectures (TTA), only operand(s).
The Forth virtual machine and other "0- operand" instruction sets lack any operand
specifier fields, such as some stack machines including NOSC.[3]
Conditional instructions often have a predicate field—a few bits that encode the specific condition to cause the operation to be performed rather than not performed. For example, a conditional branch instruction will be executed, and the branch taken, if the condition is true, so that execution proceeds to a different part of the program, and not executed, and the branch not taken, if the condition is false, so that execution continues sequentially. Some instruction sets also have conditional moves, so that the move
