Lecture No. 14
Combinational Functional Devices
Recap
Odd-Prime Number Detector Circuit
Using Quine-McCluskey Method
Combinational Logic
Implemented in SOP and POS form
Design and Implementation Steps
Timing Diagram
Active High/Low inputs/outputs
SOP Expression SImplification
D 3 D 2
D 1 D 0 00 01 11 10
00 1 0 1 0
01 0 1 0 1
11 1 0 1 0
10 0 1 0 1
Simplifying Expression
AB CD+ ABCD+ ABCD+ABCD+ABCD+ABCD+ABCD+ABC D
= AB ( CD+CD)+ AB(CD+CD)+ AB(CD+CD)+ AB(CD+CD )
= AB ( CD+CD)+ AB(CD+CD)+ AB(CD+CD)+ AB(CD+CD )
= ( CD +CD)(AB+ AB)+ (CD+CD)(AB+ AB )
= ( C ⊕D)(A⊕B)+(C⊕D)(A⊕B ) ( = X Y + XY = X⊕Y)
= ( A ⊕B)⊕(C⊕D )
Operation of Odd-Parity circuit
A
B
C
D
P
t0 t1 t2 t3 t4 t5 t6 t7 t
XOR & XNOR Gates
XOR function
XNOR function
AB + A B
AB + AB
XNOR Gate
A
B
F
Combinational Functional
Devices
Comparators
BCD to 7-Segment
Parity Generator Circuit
Half & Full Adders
A
B
Input Bits C out Output Bits
Half-Adder
A
B
Input BitsC in C out Output Bits
Full-Adder
Half-Adder
Function Table
Expression
Logic Circuit
Half-Adder Circuit
A
B
C out
Sum = AB+ AB = A ⊕ B CarryOut^ = AB
Full-Adder
Function Table
Expression
Logic Circuit
Sum Expression
Sum = ABC + ABC+ ABC + ABC
Sum = A(B C+BC) + A(BC+BC )
Sum = A(B ⊕C) + A(B⊕ C )
Sum = A ⊕B ⊕ C
Carry Out Expression
CarryOut = ABC + ABC + ABC + ABC
CarryOut = C( AB + AB) + AB(C+C )
CarryOut = C(A ⊕B) + AB
