 Introduction

 Snubber Development

 Types of Snubber

 Principle of operation of Mechanical Snubber

 Modification of the Test Rig

 Pro E Model of Snubber test Rig

 Designing of the main components

 Summary and Conclusions

 Future Work

2

Presentation Layout

docsity.com

 Snubbers traces its history back to 1955-1960 when focus were given to the fact that to utilize the huge amount of energy with in fissile elements for peaceful purposes

 There is a tremendous amount of heat with in the core of nuclear reactor

 To remove this heat and make possible the safe operation of the plant pumps having 96000 gallons per minute discharge are used

4

Snubber Development

docsity.com

Snubber Development (Contd..)

 Due to this high discharge vibration are produced in the primary loop

 Shock loads are also induced as a result of earth quack

 So in order to protect the equipments from these tremendous amount disturbing forces snubber were developed

docsity.com 5

 Snubber has the following types

7

Types of Snubber

Mechanical

Hydraulic

Mechanical Snubber having Pallets

Adjustable Hydraulic Snubber

Rotary Type Snubber

docsity.com

Tabular Member Gears

Snubber Casing

Sliding Way

Pallet Member

End Attached^ Rack to Pipe

Mechanical Snubber

docsity.com 8

10

Exploded View of Mechanical Snubber

Rack

Pallet

Shaft

Escapement Wheel

Bolts

docsity.com

11

Lever Arm

Housing

Fixed External Structure

Pipe

Clamp

Connecting Link

Bearing Shaft

Gear

Pallet

Escapement Wheel

Pinion

Rotary Snubber

docsity.com

 Due to certain limitation of this type of design the test rig is now changed

 This crank type of machine can not be used in the high load application

 Misalignment of the snubber can also take place

 Controlling the speed of the motor to the desired limits is also a problem

14

Modification

docsity.com

• docsity.com
• docsity.com
• docsity.com
• docsity.com

17

Working Mechanism of Test Rig

docsity.com

Available Data

 Outer diameter =0.089 m  Wall thickness=0.015 m  Inner diameter=0.058 m  Area of the cylinder =2.68 ×10-3^ m^2  Force to be transmitted=735.75 N as  Pressure= Force /Area  Pressure =274.62 KN/m^2

 t ≥ d/  0 .015 m ≥ 0.003 m

docsity.com 19

Stress in the Cylinder

20

pi = internal pressure in the tube or cylinder (KPa) po = external pressure in the tube or cylinder (KPa) ri = internal radius of tube or cylinder (m) ro = external radius of tube or cylinder (m)

Stress are lees than the yield Stress so design is safe

docsity.com
