Introduction to Software

Testing

( 2nd edition )

Chapter 5

Criteria-Based Test Design

Paul Ammann & Jeff Offutt

http://www.cs.gmu.edu/~offutt/softwaretest/ 20 September 2015

Changing Notions of Testing

Old view focused on testing at each software development phase as being very different from other phases

• Unit, module, integration, system … New view is in terms of structures and criteria
• input space, graphs, logical expressions, syntax Test design is largely the same at each phase
• Creating the model is different
• Choosing values and automating the tests is different

New : Test Coverage Criteria

Test Requirements : A specific element of a software artifact that a test case must satisfy or cover Coverage Criterion : A rule or collection of rules that impose test requirements on a test set A tester’s job is simple : Define a model of the software, then find ways to cover it

Source of Structures

These structures can be extracted from lots of software artifacts

• Graphs can be extracted from UML use cases, finite state machines, source code, …
• Logical expressions can be extracted from decisions in program source, guards on transitions, conditionals in use cases, …

Example : Jelly Bean Coverage

Flavors :

1. Lemon
2. Pistachio
3. Cantaloupe
4. Pear
5. Tangerine
6. Apricot Colors : 1. Yellow (Lemon, Apricot) 2. Green (Pistachio) 3. Orange (Cantaloupe, Tangerine) 4. White (Pear) Possible coverage criteria :
7. Taste one jelly bean of each flavor (How many test requirements are there?)
8. Taste one jelly bean of each color (How many test requirements are there?)

Criteria 1:

• Cover all colors
• How many test requirements?
  • 4 TR Criteria 2:
• Cover all flavours
• How many test requirements?
• 6 TR Omar created Test Suite 1: {Orange(Cantalatope), Green (Pistachio), Orange (Tangarine), White (pear)} Calculate coverage % for Omar’s test suite against Criteria 1: ¾ = 0. Calculate coverage % for Omar’s test suite against Criteria 2: 4/6 = 0.

if (x > y) { cout<<“Say Hello”; if (y > x) { cout<<“Say Good Bye”;//DEAD code } }

More Jelly Beans

Does test set T1 satisfy the flavor criterion? Does T1 suffer from redundancy? ( Minimal test sets ) Can T1 be minimal? T1 = { three Lemons, one Pistachio, two Cantaloupes, one Pear, one Tangerine, four Apricots } Does test set T2 satisfy the flavor criterion? T2 = { One Lemon, two Pistachios, one Pear, three Tangerines } Does test set T2 satisfy the color criterion?

Comparing Criteria with

Subsumption (5.2)

Criteria Subsumption : A test criterion C1 subsumes C2 if and only if every set of test cases that satisfies criterion C1 also satisfies C Must be true for every set of test cases Examples :

• The flavor criterion on jelly beans subsumes the color criterion … if we taste every flavor we taste one of every color
• If a test set has covered every branch in a program (satisfied the branch criterion), then the test set is guaranteed to also have covered every statement

Criteria Summary

• Many companies still use “monkey testing”
  • A human sits at the keyboard, wiggles the mouse and bangs the keyboard
  • No automation
  • Minimal training required
• Some companies automate human-designed tests
• But companies that use both automation and criteria- based testing Save money Find more faults Build better software

Required Reading

Chapter 5 from the course’s textbook: “Introduction to Software Testing”, Cambridge University Press. P. Amman and J. Offutt, Second Edition, 2017.
