High Performance Computing

Lecture 24

2

Solving Data Hazards

1. Interlocks & stalling dependent instructions

2. Forwarding or Bypassing

3. Load delay slot

4. Instruction Scheduling

 Reorder the instructions of the program so that

dependent instructions are far enough apart

 This could be done either

 by the compiler, before the program runs: Static

Instruction Scheduling

 by the hardware, when the program is running:

Dynamic Instruction Scheduling

4

Static Instruction Scheduling

 Reorder the instructions of the program to

eliminate data hazards …

 or in general to reduce the execution time of the

program

 Reordering must be safe

 should not change the meaning of the program

 Two instructions can be exchanged if they

are independent of each other

5

Example: Static Instruction Scheduling

Program fragment:

LW R3, 0(R1)

ADDI R5, R3, 1

ADD R2, R2, R

LW R13, 0(R11)

ADD R12, R13, R

Scheduling:

1 stall

1 stall

2 stalls

0 stalls

LW R3, 0(R1)

ADDI R5, R3, 1

ADD R2, R2, R

LW R13, 0(R11)

ADD R12, R13, R

7

Kinds of Data Dependence

 True dependence

ADD R1, R2, R

SUB R4, R1, R

 Anti-dependence

ADD R1, R2, R

SUB R2, R4, R

 Output dependence

ADD R1, R2, R

SUB R1, R4, R

8

Dynamic Instruction Scheduling

IF ID^ EX^

MEM WB

IF EX

WB

ID

Instruction Window

Instruction Queue

Functional Units

Floating point Adder

Floating point Multiplier

Integer ALU

Integer Multiplier

Memory Unit

With dynamic instruction scheduling …

10

Problem: Pipeline Hazards

A situation where an instruction cannot

proceed through the pipeline as it should

1. Structural hazard: When 2 or more

instructions in the pipeline need to use the

same resource at the same time

2. Data hazard: When an instruction depends

on the data result of a prior instruction that

is still in the pipeline

3. Control hazard: A hazard that arises due to

control transfer instructions

11

Recall: Execution of Branch Instruction

Mem

PC

Reg

File

Sign

extend

IF ID

4

ALU

Zero?

Mem

EX

MEM WB

13

Control Hazards

 Observation: Since the branch is resolved

only in the EX stage, there must be 2 stall

cycles after every conditional branch

instruction

14

Reducing Impact of Branch Stall

 The execution of a conditional branch

instruction involves 2 activities

1. evaluating the branch condition (determine

whether it is to be taken or not-taken)

2. computing the branch target address

 To reduce branch stall effect we could

 evaluate the condition earlier (in ID stage)

 compute the target address earlier (in ID stage)

 The number of stall cycles would then be

reduced to 1 cycle

16

Prediction and Correctness

 Prediction: guessing what is going to happen

 What if the guess is incorrect?

 The pipelined processor hardware must be built to

detect the misprediction and take appropriate

corrective action

17

Control Hazard Solutions

1. Static Branch Prediction

Example: Static Not-Taken policy

 The hardware is built to fetch next from PC + 4

 After ID stage, if it is found that the branch

condition is false (i.e., not taken), continue with

the fetched instruction (from PC + 4)

 Else, squash the fetched instruction and re-fetch

from the branch target address

 squash: cancel, annul the processing of that instruction

19

IF

Static Not-Taken Branch Prediction

BEQZ R3, out

Fetch inst i +

IF ID

IF ID EX MEM WB

Suppose that the

condition evaluates

to TRUE

ID EX MEM

IF ID EX

Fetch inst from

branch target address

etc

SQUASH inst i+

i.e., ONE BRANCH STALL CYCLE

20

Control Hazard Solutions

1. Static Branch Prediction

Example: Static Not-Taken policy

 The hardware is built to fetch next from PC + 4

 After ID stage, if it is found that the branch

condition is false (i.e., not taken), continue with

the fetched instruction (from PC + 4)

 Else, squash the fetched instruction and re-fetch

from the branch target address

 Thus, average branch penalty < 1 cycle

0 stall cycles

1 stall cycle
