- Engr/Math/Physics
- Chp
- Statistics-
Learning Goals
- Use MATLAB to solve Problems in
- Statistics
- Probability
- Use Monte Carlo (random) Methods to
Simulate Random processes
- Properly Apply Interpolation or
Extrapolation to Estimate values between
or outside of know data points
HistoGram ≡ Frequency Chart
- A HistoGram shows how OFTEN some event
Occurs
- Histograms are
often constructed
using Frequency
Tables
Histograms In MATLAB
- MATLAB has 6 Forms
of the Histogram Cmd
- The Simplest
Hist(y)
The Plot Statement
- Generates a
Histogram with
10 bins
Example: Max Temp
at Oakland AirPort in
Jul-Aug
TmaxOAK = [70, 75, 63, 64, 65, 66, 65, 65, 67, 78, 75, 73, 79, 71, 72, 67, 69, 69, 70, 74, 71, 72, 71, 74, 77, 77, 86, 90, 90, 70, 71, 66, 66, 72, 68, 73, 72, 82, 91, 82, 76, 75, 72, 72, 69, 70, 68, 65, 67, 65, 63, 64, 72, 70, 68, 71, 77, 65, 63, 69, 69, 67]
hist(TmaxOAK), ylabel('No. Days'), xlabel('Max. Temp (°F)'), title('Oakland Airport - Jul-Aug08')
Histograms In MATLAB
- Next Example: Max
Temp at Stockton
AirPort in Jul-Aug
Hist(y)
The Plot Statement
- Generates a
Histogram with
10 bins
TmaxSTK = [94, 98, 93, 94, 91, 96, 93, 87, 89, 94, 100, 99, 103, 103, 103, 97, 91, 83, 84, 90, 89, 95, 94, 99, 97, 94, 102, 103, 107, 98, 86, 89, 95, 91, 84, 93, 98, 104, 105, 107, 103, 91, 90, 96, 93, 86, 92, 93, 95, 95, 86, 81, 93, 97, 96, 97, 101, 92, 89, 92, 93, 94]
hist(TmaxSTK), ylabel('No. Days'), xlabel('Max. Temp (°F)'), title(‘Stockton Airport - Jul-Aug08')
hist Result for Stockton
It was HOT
in Summer
Bin Width =
= 2.6 °F
(^080 85 90 95 100 105 )
2
4
6
8
10
12
14
16 Stockton Airport - Jul-Aug
No. Days
Max. Temp (°F)
hist Plots 17 Bins
hist(TmaxSTK,17),
ylabel('No. Days'), xlabel('Max. Temp (°F)'), title('Stockton, CA - Jul- Aug08')>>
hist(TmaxOAK,17), ylabel('No. Days'), xlabel('Max. Temp (°F)'), title('Oakland, CA - Jul- Aug08')
(^080 85 90 95 100 105 )
1
2
3
4
5
6
7
8
9
10 Stockton, CA - Jul-Aug
No. Days
Max. Temp (°F) 060 65 70 75 80 85 90 95
1
2
3
4
5
6
7
8
9
10 Oakland, CA - Jul-Aug
No. Days
Max. Temp (°F)
hist Plots Same Scale
x = [60:2.5:110]; hist(TmaxSTK,x), ylabel('No. Days'), xlabel('Max. Temp (°F)'), title('Stockton, CA - Jul- Aug08')
x = [60:2.5:110];
hist(TmaxOAK,x), ylabel('No. Days'), xlabel('Max. Temp (°F)'), title('Oakland, CA - Jul- Aug08')
(^060 65 70 75 80 85 90 95 100 105 )
2
4
6
8
10
12
14
16 Oakland, CA - Jul-Aug
No. Days
(^60 65 70 75 80 85 90 95 100 105 110) Max. Temp (°F) 0
2
4
6
8
10
12
14
16 Stockton, CA - Jul-Aug
No. Days
Max. Temp (°F)
hist Numerical Output
- Bin-Count and Bin-Locations (Frequency
Table) for the Oakland Data
[u, v] = hist(TmaxOAK,x) u = 0 3 11 7 15 9 6 4 1 2 1 0 3 0 0 0 0 0 0 0 0 v = 60.0000 62.5000 65.0000 67.5000 70.
72.5000 75.0000 77.5000 80.0000 82. 85.0000 87.5000 90.0000 92.5000 95. 97.5000 100.0000 102.5000 105.0000 107.
Histogram Commands - 1
Command Description
bar(x,y) Creates a bar chart of y versus x.
hist(y)
Aggregates the data in the vector y into
10 bins evenly spaced between the
minimum and maximum values in y.
hist(y,n)
Aggregates the data in the vector y into
n bins evenly spaced between the
minimum and maximum values in y.
hist(y,x)
Aggregates the data in the vector y into
bins whose center locations are
specified by the vector x. The bin widths
are the distances between the centers.
Data Statistics Tool - 1
- Make Line-Plot
of Temp Data
for Stockton,
CA
- Use the Tools
Menu to find
the Data
Statistics Tool
Data Statistics Tool - 2
- Use the Tool
to Add Plot
Lines for
- The Mean
- ±StdDev
Probability
- Probability ≡ The LIKELYHOOD that a
Specified OutCome Will be Realized
- The “Odds” Run from 0% to 100%
- Class Question: What are the
Odds of winning the California MEGA-
MILLIONS Lottery?
175 711 536 ... EXACTLY???!!!
- To Win the MegaMillions Lottery
- Pick five numbers from 1 to 56
- Pick a MEGA number from 1 to 46
- The Odds for the 1 st^ ping-pong Ball
= 5 out of 56
- The Odds for the 2 nd^ ping-pong Ball
= 4 out of 55, and so On
- The Odds for the MEGA are 1 out of 46
