HCS

Microcontrollers

freescale.com

MC9S08GB

MC9S08GB

MC9S08GT

MC9S08GT

MC9S08GT

Data Sheet

MC9S08GB60/D

Rev. 2. 12/

MC9S08GB/GT Data Sheet, Rev. 2.

Revision History

To provide the most up-to-date information, the revision of our documents on the World Wide Web will be the most current. Your printed copy may be an earlier revision. To verify you have the latest information available, refer to:

http://freescale.com

The following revision history table summarizes changes contained in this document.

This product incorporates SuperFlash®^ technology licensed from SST.

Freescale‚ and the Freescale logo are trademarks of Freescale Semiconductor, Inc. © Freescale Semiconductor, Inc., 2004. All rights reserved.

Revision Number

Revision Date Description of Changes 1.0 4/25/2003 Initial release 1.1 Electricals change, appendix A only 1.2 Electricals change, appendix A only 1.3 10/2/2003 Added module version table; clarifications 1.4 10/29/2003 Fixed typos and made corrections and clarifications 1.5 11/12/2003 Added 1-MHz IDD values to Electricals, appendix A

2 2/10/

Changed format of register names to enable reuse of code (from SCIBD to SCI1BD, even when only one instance of a module on a chip) Added new device: MC9S08GT16 to book. Added new 48-pin QFN package to book. BKGDPE description in Section 5 — changed PTD0 to PTG0. Changed typo in CPU section that listed MOV instruction as being 6 cycles instead of 5 (Table 8-2).

2.2 9/2/

Format to Freescale look-and-feel; Clarified RTI clock sources and other changes in Chapter 5; updated ICG initialization examples; expanded descriptions of LOLS and LOCS bits in ICGS1; updated ICG electricals Table A-9 and added a figure

2.3 12/01/

Minor changes to Table 7-4, Table 7-5, Table A-9; Clarifications in Section 11.10.6, “SCI x Control Register 3 (SCIxC3)”, Section 11.7, “Interrupts and Status Flags”, Section 11.8.1, “8- and 9-Bit Data Modes”, PTG availability in 48-pin package (see Table 2-2)

List of Chapters

Introduction

Contents

Appendix A

Appendix B

• Covers: MC9S08GB
  • MC9S08GB
  • MC9S08GT
  • MC9S08GT
  • MC9S08GT
    • MC9S08GB
      • Rev. 2.
        • 12/
  • MC9S08GB/GT Data Sheet, Rev. 2.
• Chapter 1 Introduction..............................................................................
• Chapter 2 Pins and Connections
• Chapter 3 Modes of Operation
• Chapter 4 Memory
• Chapter 5 Resets, Interrupts, and System Configuration
• Chapter 6 Parallel Input/Output
• Chapter 7 Internal Clock Generator (ICG) Module
• Chapter 8 Central Processor Unit (CPU)...............................................
• Chapter 9 Keyboard Interrupt (KBI) Module
• Chapter 10 Timer/PWM (TPM) Module.....................................................
• Chapter 11 Serial Communications Interface (SCI) Module..................
• Chapter 12 Serial Peripheral Interface (SPI) Module..............................
• Chapter 13 Inter-Integrated Circuit (IIC) Module
• Chapter 14 Analog-to-Digital Converter (ATD) Module
• Chapter 15 Development Support
• Appendix A Electrical Characteristics......................................................
• Appendix B Ordering Information and Mechanical Drawings................ - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter
• 1.1 Overview .........................................................................................................................................
• 1.2 Features ...........................................................................................................................................
  • 1.2.1 Standard Features of the HCS08 Family .........................................................................
  • 1.2.2 Features of MC9S08GB/GT Series of MCUs .................................................................
  • 1.2.3 Devices in the MC9S08GB/GT Series ............................................................................
• 1.3 MCU Block Diagrams .....................................................................................................................
• 1.4 System Clock Distribution .............................................................................................................. - Chapter
• 2.1 Introduction ..................................................................................................................................... Pins and Connections
• 2.2 Device Pin Assignment ...................................................................................................................
• 2.3 Recommended System Connections ...............................................................................................
  • 2.3.1 Power ...............................................................................................................................
  • 2.3.2 Oscillator ..........................................................................................................................
  • 2.3.3 Reset ................................................................................................................................
  • 2.3.4 Background / Mode Select (PTG0/BKGD/MS) ..............................................................
  • 2.3.5 General-Purpose I/O and Peripheral Ports .......................................................................
  • 2.3.6 Signal Properties Summary ............................................................................................. - Chapter
• 3.1 Introduction ..................................................................................................................................... Modes of Operation
• 3.2 Features ...........................................................................................................................................
• 3.3 Run Mode ........................................................................................................................................
• 3.4 Active Background Mode ................................................................................................................
• 3.5 Wait Mode .......................................................................................................................................
• 3.6 Stop Modes ......................................................................................................................................
  • 3.6.1 Stop1 Mode ......................................................................................................................
  • 3.6.2 Stop2 Mode ......................................................................................................................
  • 3.6.3 Stop3 Mode ......................................................................................................................
  • 3.6.4 Active BDM Enabled in Stop Mode ................................................................................
  • 3.6.5 LVD Enabled in Stop Mode .............................................................................................
  • 3.6.6 On-Chip Peripheral Modules in Stop Modes ................................................................... - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter Section Number Title Page
• 4.1 MC9S08GB/GT Memory Map ....................................................................................................... Memory
  • 4.1.1 Reset and Interrupt Vector Assignments ..........................................................................
• 4.2 Register Addresses and Bit Assignments ........................................................................................
• 4.3 RAM ................................................................................................................................................
• 4.4 FLASH ............................................................................................................................................
  • 4.4.1 Features ............................................................................................................................
  • 4.4.2 Program and Erase Times ................................................................................................
  • 4.4.3 Program and Erase Command Execution ........................................................................
  • 4.4.4 Burst Program Execution .................................................................................................
  • 4.4.5 Access Errors ...................................................................................................................
  • 4.4.6 FLASH Block Protection .................................................................................................
  • 4.4.7 Vector Redirection ...........................................................................................................
• 4.5 Security ............................................................................................................................................
• 4.6 FLASH Registers and Control Bits .................................................................................................
  • 4.6.1 FLASH Clock Divider Register (FCDIV) .......................................................................
  • 4.6.2 FLASH Options Register (FOPT and NVOPT) ..............................................................
  • 4.6.3 FLASH Configuration Register (FCNFG) .......................................................................
  • 4.6.4 FLASH Protection Register (FPROT and NVPROT) ......................................................
  • 4.6.5 FLASH Status Register (FSTAT) .....................................................................................
  • 4.6.6 FLASH Command Register (FCMD) .............................................................................. - Chapter
• 5.1 Introduction ..................................................................................................................................... Resets, Interrupts, and System Configuration
• 5.2 Features ...........................................................................................................................................
• 5.3 MCU Reset ......................................................................................................................................
• 5.4 Computer Operating Properly (COP) Watchdog .............................................................................
• 5.5 Interrupts .........................................................................................................................................
  • 5.5.1 Interrupt Stack Frame ......................................................................................................
  • 5.5.2 External Interrupt Request (IRQ) Pin ..............................................................................
    • 5.5.2.1 Pin Configuration Options ..............................................................................
    • 5.5.2.2 Edge and Level Sensitivity ..............................................................................
  • 5.5.3 Interrupt Vectors, Sources, and Local Masks ..................................................................
• 5.6 Low-Voltage Detect (LVD) System ................................................................................................
  • 5.6.1 Power-On Reset Operation ..............................................................................................
  • 5.6.2 LVD Reset Operation .......................................................................................................
  • 5.6.3 LVD Interrupt Operation .................................................................................................
  • 5.6.4 Low-Voltage Warning (LVW) ..........................................................................................
• 5.7 Real-Time Interrupt (RTI) ............................................................................................................... - MC9S08GB/GT Data Sheet, Rev. 2.
• 5.8 Reset, Interrupt, and System Control Registers and Control Bits ................................................... Section Number Title Page
  • 5.8.1 Interrupt Pin Request Status and Control Register (IRQSC) ...........................................
  • 5.8.2 System Reset Status Register (SRS) ................................................................................
  • 5.8.3 System Background Debug Force Reset Register (SBDFR) ...........................................
  • 5.8.4 System Options Register (SOPT) ....................................................................................
  • 5.8.5 System Device Identification Register (SDIDH, SDIDL) ...............................................
  • 5.8.6 System Real-Time Interrupt Status and Control Register (SRTISC) ...............................
  • 5.8.7 System Power Management Status and Control 1 Register (SPMSC1) ..........................
  • 5.8.8 System Power Management Status and Control 2 Register (SPMSC2) .......................... - Chapter
• 6.1 Introduction ..................................................................................................................................... Parallel Input/Output
• 6.2 Features ...........................................................................................................................................
• 6.3 Pin Descriptions ..............................................................................................................................
  • 6.3.1 Port A and Keyboard Interrupts .......................................................................................
  • 6.3.2 Port B and Analog to Digital Converter Inputs ...............................................................
  • 6.3.3 Port C and SCI2, IIC, and High-Current Drivers ............................................................
  • 6.3.4 Port D, TPM1 and TPM2 .................................................................................................
  • 6.3.5 Port E, SCI1, and SPI ......................................................................................................
  • 6.3.6 Port F and High-Current Drivers .....................................................................................
  • 6.3.7 Port G, BKGD/MS, and Oscillator ..................................................................................
• 6.4 Parallel I/O Controls ........................................................................................................................
  • 6.4.1 Data Direction Control ....................................................................................................
  • 6.4.2 Internal Pullup Control ....................................................................................................
  • 6.4.3 Slew Rate Control ............................................................................................................
• 6.5 Stop Modes ......................................................................................................................................
• 6.6 Parallel I/O Registers and Control Bits ...........................................................................................
  • 6.6.1 Port A Registers (PTAD, PTAPE, PTASE, and PTADD) ................................................
  • 6.6.2 Port B Registers (PTBD, PTBPE, PTBSE, and PTBDD) ...............................................
  • 6.6.3 Port C Registers (PTCD, PTCPE, PTCSE, and PTCDD) ...............................................
  • 6.6.4 Port D Registers (PTDD, PTDPE, PTDSE, and PTDDD) ..............................................
  • 6.6.5 Port E Registers (PTED, PTEPE, PTESE, and PTEDD) ................................................
  • 6.6.6 Port F Registers (PTFD, PTFPE, PTFSE, and PTFDD) ..................................................
  • 6.6.7 Port G Registers (PTGD, PTGPE, PTGSE, and PTGDD) .............................................. - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter Section Number Title Page
• 7.1 Introduction ..................................................................................................................................... Internal Clock Generator (ICG) Module
  • 7.1.1 Features ..........................................................................................................................
  • 7.1.2 Modes of Operation .......................................................................................................
• 7.2 External Signal Description ..........................................................................................................
  • 7.2.1 Overview ........................................................................................................................
  • 7.2.2 Detailed Signal Descriptions .........................................................................................
    • 7.2.2.1 EXTAL— External Reference Clock / Oscillator Input ...............................
    • 7.2.2.2 XTAL— Oscillator Output ...........................................................................
  • 7.2.3 External Clock Connections ..........................................................................................
  • 7.2.4 External Crystal/Resonator Connections .......................................................................
• 7.3 Functional Description ..................................................................................................................
  • 7.3.1 Off Mode (Off) ..............................................................................................................
    • 7.3.1.1 BDM Active .................................................................................................
    • 7.3.1.2 OSCSTEN Bit Set .........................................................................................
    • 7.3.1.3 Stop/Off Mode Recovery ..............................................................................
  • 7.3.2 Self-Clocked Mode (SCM) ............................................................................................
  • 7.3.3 FLL Engaged, Internal Clock (FEI) Mode ....................................................................
    • 7.3.3.1 FLL Engaged Internal Unlocked ..................................................................
    • 7.3.3.2 FLL Engaged Internal Locked ......................................................................
  • 7.3.4 FLL Bypassed, External Clock (FBE) Mode ................................................................
  • 7.3.5 FLL Engaged, External Clock (FEE) Mode ..................................................................
    • 7.3.5.1 FLL Engaged External Unlocked .................................................................
    • 7.3.5.2 FLL Engaged External Locked .....................................................................
  • 7.3.6 FLL Lock and Loss-of-Lock Detection .........................................................................
  • 7.3.7 FLL Loss-of-Clock Detection ........................................................................................
  • 7.3.8 Clock Mode Requirements ............................................................................................
  • 7.3.9 Fixed Frequency Clock ..................................................................................................
• 7.4 Initialization/Application Information ..........................................................................................
  • 7.4.1 Introduction ....................................................................................................................
  • 7.4.2 Example #1: External Crystal = 32 kHz, Bus Frequency = 4.19 MHz .........................
  • 7.4.3 Example #2: External Crystal = 4 MHz, Bus Frequency = 20 MHz ............................
  • 7.4.4 Example #3: No External Crystal Connection, 5.4 MHz Bus Frequency .....................
  • 7.4.5 Example #4: Internal Clock Generator Trim .................................................................
• 7.5 ICG Registers and Control Bits .....................................................................................................
  • 7.5.1 ICG Control Register 1 (ICGC1) ......................................................................
  • 7.5.2 ICG Control Register 2 (ICGC2) ......................................................................
  • 7.5.3 ICG Status Register 1 (ICGS1) .................................................................................
  • 7.5.4 ICG Status Register 2 (ICGS2) ........................................................................
  • 7.5.5 ICG Filter Registers (ICGFLTU, ICGFLTL) .......................................................
  • 7.5.6 ICG Trim Register (ICGTRM) ........................................................................... - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter Section Number Title Page
• 8.1 Introduction ................................................................................................................................... Central Processor Unit (CPU)
• 8.2 Features .........................................................................................................................................
• 8.3 Programmer’s Model and CPU Registers .....................................................................................
  • 8.3.1 Accumulator (A) ............................................................................................................
  • 8.3.2 Index Register (H:X) .....................................................................................................
  • 8.3.3 Stack Pointer (SP) ..........................................................................................................
  • 8.3.4 Program Counter (PC) ...................................................................................................
  • 8.3.5 Condition Code Register (CCR) ....................................................................................
• 8.4 Addressing Modes .........................................................................................................................
  • 8.4.1 Inherent Addressing Mode (INH) ..................................................................................
  • 8.4.2 Relative Addressing Mode (REL) .................................................................................
  • 8.4.3 Immediate Addressing Mode (IMM) .............................................................................
  • 8.4.4 Direct Addressing Mode (DIR) .....................................................................................
  • 8.4.5 Extended Addressing Mode (EXT) ...............................................................................
  • 8.4.6 Indexed Addressing Mode .............................................................................................
    • 8.4.6.1 Indexed, No Offset (IX) ................................................................................
    • 8.4.6.2 Indexed, No Offset with Post Increment (IX+) .............................................
    • 8.4.6.3 Indexed, 8-Bit Offset (IX1) ...........................................................................
    • 8.4.6.4 Indexed, 8-Bit Offset with Post Increment (IX1+) .......................................
    • 8.4.6.5 Indexed, 16-Bit Offset (IX2) .........................................................................
    • 8.4.6.6 SP-Relative, 8-Bit Offset (SP1) ....................................................................
    • 8.4.6.7 SP-Relative, 16-Bit Offset (SP2) ..................................................................
• 8.5 Special Operations .........................................................................................................................
  • 8.5.1 Reset Sequence ..............................................................................................................
  • 8.5.2 Interrupt Sequence .........................................................................................................
  • 8.5.3 Wait Mode Operation .....................................................................................................
  • 8.5.4 Stop Mode Operation .....................................................................................................
  • 8.5.5 BGND Instruction ..........................................................................................................
• 8.6 HCS08 Instruction Set Summary .................................................................................................. - Chapter
• 9.1 Introduction ................................................................................................................................... Keyboard Interrupt (KBI) Module
  • 9.1.1 Port A and Keyboard Interrupt Pins ..............................................................................
• 9.2 Features .........................................................................................................................................
• 9.3 KBI Block Diagram ......................................................................................................................
• 9.4 Keyboard Interrupt (KBI) Module ................................................................................................
  • 9.4.1 Pin Enables ....................................................................................................................
  • 9.4.2 Edge and Level Sensitivity ............................................................................................
  • 9.4.3 KBI Interrupt Controls ...................................................................................................
• 9.5 KBI Registers and Control Bits .....................................................................................................
  • 9.5.1 KBI Status and Control Register (KBI1SC) ..................................................................
  • 9.5.2 KBI Pin Enable Register (KBI1PE) .............................................................................. - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter Section Number Title Page
• 10.1 Introduction ................................................................................................................................... Timer/PWM (TPM) Module
• 10.2 Features .........................................................................................................................................
• 10.3 TPM Block Diagram .....................................................................................................................
• 10.4 Pin Descriptions ............................................................................................................................
  • 10.4.1 External TPM Clock Sources ........................................................................................
  • 10.4.2 TPMxCHn — TPMx Channel n I/O Pins ......................................................................
• 10.5 Functional Description ..................................................................................................................
  • 10.5.1 Counter ..........................................................................................................................
  • 10.5.2 Channel Mode Selection ................................................................................................
    • 10.5.2.1 Input Capture Mode ......................................................................................
    • 10.5.2.2 Output Compare Mode .................................................................................
    • 10.5.2.3 Edge-Aligned PWM Mode ...........................................................................
  • 10.5.3 Center-Aligned PWM Mode ..........................................................................................
• 10.6 TPM Interrupts ..............................................................................................................................
  • 10.6.1 Clearing Timer Interrupt Flags ......................................................................................
  • 10.6.2 Timer Overflow Interrupt Description ...........................................................................
  • 10.6.3 Channel Event Interrupt Description .............................................................................
  • 10.6.4 PWM End-of-Duty-Cycle Events ..................................................................................
• 10.7 TPM Registers and Control Bits ...................................................................................................
  • 10.7.1 Timer x Status and Control Register (TPMxSC) ...........................................................
  • 10.7.2 Timer x Counter Registers (TPMxCNTH:TPMxCNTL) ..............................................
  • 10.7.3 Timer x Counter Modulo Registers (TPMxMODH:TPMxMODL) ..............................
  • 10.7.4 Timer x Channel n Status and Control Register (TPMxCnSC) .....................................
  • 10.7.5 Timer x Channel Value Registers (TPMxCnVH:TPMxCnVL) ..................................... - Chapter
• 11.1 Introduction ................................................................................................................................... Serial Communications Interface (SCI) Module
• 11.2 Features .........................................................................................................................................
• 11.3 SCI System Description ................................................................................................................
• 11.4 Baud Rate Generation ...................................................................................................................
• 11.5 Transmitter Functional Description ...............................................................................................
  • 11.5.1 Transmitter Block Diagram ...........................................................................................
  • 11.5.2 Send Break and Queued Idle .........................................................................................
• 11.6 Receiver Functional Description ...................................................................................................
  • 11.6.1 Receiver Block Diagram ................................................................................................
  • 11.6.2 Data Sampling Technique ..............................................................................................
  • 11.6.3 Receiver Wakeup Operation ..........................................................................................
    • 11.6.3.1 Idle-Line Wakeup ..........................................................................................
    • 11.6.3.2 Address-Mark Wakeup .................................................................................
• 11.7 Interrupts and Status Flags ............................................................................................................ - MC9S08GB/GT Data Sheet, Rev. 2.
• 11.8 Additional SCI Functions .............................................................................................................. Section Number Title Page
  • 11.8.1 8- and 9-Bit Data Modes ................................................................................................
• 11.9 Stop Mode Operation ....................................................................................................................
  • 11.9.1 Loop Mode .....................................................................................................................
  • 11.9.2 Single-Wire Operation ...................................................................................................
• 11.10 SCI Registers and Control Bits .....................................................................................................
  • 11.10.1 SCI x Baud Rate Registers (SCIxBDH, SCIxBDL) ......................................................
  • 11.10.2 SCI x Control Register 1 (SCIxC1) ...............................................................................
  • 11.10.3 SCI x Control Register 2 (SCIxC2) ...............................................................................
  • 11.10.4 SCI x Status Register 1 (SCIxS1) ..................................................................................
  • 11.10.5 SCI x Status Register 2 (SCIxS2) ..................................................................................
  • 11.10.6 SCI x Control Register 3 (SCIxC3) ...............................................................................
  • 11.10.7 SCI x Data Register (SCIxD) ........................................................................................ - Chapter
• 12.1 Features ......................................................................................................................................... Serial Peripheral Interface (SPI) Module
• 12.2 Block Diagrams .............................................................................................................................
  • 12.2.1 SPI System Block Diagram ...........................................................................................
  • 12.2.2 SPI Module Block Diagram ...........................................................................................
  • 12.2.3 SPI Baud Rate Generation .............................................................................................
• 12.3 Functional Description ..................................................................................................................
  • 12.3.1 SPI Clock Formats .........................................................................................................
  • 12.3.2 SPI Pin Controls ............................................................................................................
    • 12.3.2.1 SPSCK1 — SPI Serial Clock ........................................................................
    • 12.3.2.2 MOSI1 — Master Data Out, Slave Data In ..................................................
    • 12.3.2.3 MISO1 — Master Data In, Slave Data Out ..................................................
    • 12.3.2.4 SS1 — Slave Select .......................................................................................
  • 12.3.3 SPI Interrupts .................................................................................................................
  • 12.3.4 Mode Fault Detection ....................................................................................................
• 12.4 SPI Registers and Control Bits ......................................................................................................
  • 12.4.1 SPI Control Register 1 (SPI1C1) ...................................................................................
  • 12.4.2 SPI Control Register 2 (SPI1C2) ...................................................................................
  • 12.4.3 SPI Baud Rate Register (SPI1BR) .................................................................................
  • 12.4.4 SPI Status Register (SPI1S) ...........................................................................................
  • 12.4.5 SPI Data Register (SPI1D) ............................................................................................ - MC9S08GB/GT Data Sheet, Rev. 2. - Chapter Section Number Title Page
• 13.1 Introduction ................................................................................................................................... Inter-Integrated Circuit (IIC) Module
  • 13.1.1 Features ..........................................................................................................................
  • 13.1.2 Modes of Operation .......................................................................................................
  • 13.1.3 Block Diagram ...............................................................................................................
  • 13.1.4 Detailed Signal Descriptions .........................................................................................
    • 13.1.4.1 SCL1 — Serial Clock Line ...........................................................................
    • 13.1.4.2 SDA1 — Serial Data Line ............................................................................
• 13.2 Functional Description ..................................................................................................................
  • 13.2.1 IIC Protocol ...................................................................................................................
    • 13.2.1.1 START Signal ...............................................................................................
    • 13.2.1.2 Slave Address Transmission .........................................................................
    • 13.2.1.3 Data Transfer .................................................................................................
    • 13.2.1.4 STOP Signal ..................................................................................................
    • 13.2.1.5 Repeated START Signal ...............................................................................
    • 13.2.1.6 Arbitration Procedure ....................................................................................
    • 13.2.1.7 Clock Synchronization ..................................................................................
    • 13.2.1.8 Handshaking .................................................................................................
    • 13.2.1.9 Clock Stretching ............................................................................................
• 13.3 Resets ............................................................................................................................................
• 13.4 Interrupts .......................................................................................................................................
  • 13.4.1 Byte Transfer Interrupt ..................................................................................................
  • 13.4.2 Address Detect Interrupt ................................................................................................
  • 13.4.3 Arbitration Lost Interrupt ..............................................................................................
• 13.5 IIC Registers and Control Bits ......................................................................................................
  • 13.5.1 IIC Address Register (IIC1A) ........................................................................................
  • 13.5.2 IIC Frequency Divider Register (IIC1F) ........................................................................
  • 13.5.3 IIC Control Register (IIC1C) .........................................................................................
  • 13.5.4 IIC Status Register (IIC1S) ............................................................................................
  • 13.5.5 IIC Data I/O Register (IIC1D) ....................................................................................... - Chapter
• 14.1 Introduction ................................................................................................................................... Analog-to-Digital Converter (ATD) Module
  • 14.1.1 Features ..........................................................................................................................
  • 14.1.2 Modes of Operation .......................................................................................................
    • 14.1.2.1 Stop Mode .....................................................................................................
    • 14.1.2.2 Power Down Mode .......................................................................................
  • 14.1.3 Block Diagram ...............................................................................................................
• 14.2 Signal Description .........................................................................................................................
  • 14.2.1 Overview ........................................................................................................................
    • 14.2.1.1 Channel Input Pins — AD1P7–AD1P0 ........................................................
      • MC9S08GB/GT Data Sheet, Rev. 2.
    • 14.2.1.2 ATD Reference Pins — VREFH , V REFL ........................................................ Section Number Title Page
    • 14.2.1.3 ATD Supply Pins — V DDAD , VSSAD ...........................................................
• 14.3 Functional Description ..................................................................................................................
  • 14.3.1 Mode Control .................................................................................................................
  • 14.3.2 Sample and Hold ............................................................................................................
  • 14.3.3 Analog Input Multiplexer ..............................................................................................
  • 14.3.4 ATD Module Accuracy Definitions ...............................................................................
• 14.4 Resets ............................................................................................................................................
• 14.5 Interrupts .......................................................................................................................................
• 14.6 ATD Registers and Control Bits ....................................................................................................
  • 14.6.1 ATD Control (ATDC) ....................................................................................................
  • 14.6.2 ATD Status and Control (ATD1SC) ..............................................................................
  • 14.6.3 ATD Result Data (ATD1RH, ATD1RL) ........................................................................
  • 14.6.4 ATD Pin Enable (ATD1PE) ........................................................................................... - Chapter
• 15.1 Introduction ................................................................................................................................... Development Support
• 15.2 Features .........................................................................................................................................
• 15.3 Background Debug Controller (BDC) ..........................................................................................
  • 15.3.1 BKGD Pin Description ..................................................................................................
  • 15.3.2 Communication Details .................................................................................................
  • 15.3.3 BDC Commands ............................................................................................................
  • 15.3.4 BDC Hardware Breakpoint ............................................................................................
• 15.4 On-Chip Debug System (DBG) ....................................................................................................
  • 15.4.1 Comparators A and B ....................................................................................................
  • 15.4.2 Bus Capture Information and FIFO Operation ..............................................................
  • 15.4.3 Change-of-Flow Information .........................................................................................
  • 15.4.4 Tag vs. Force Breakpoints and Triggers ........................................................................
  • 15.4.5 Trigger Modes ................................................................................................................
  • 15.4.6 Hardware Breakpoints ...................................................................................................
• 15.5 Registers and Control Bits .............................................................................................................
  • 15.5.1 BDC Registers and Control Bits ....................................................................................
    • 15.5.1.1 BDC Status and Control Register (BDCSCR) ..............................................
    • 15.5.1.2 BDC Breakpoint Match Register (BDCBKPT) ............................................
  • 15.5.2 System Background Debug Force Reset Register (SBDFR) .........................................
  • 15.5.3 DBG Registers and Control Bits ....................................................................................
    • 15.5.3.1 Debug Comparator A High Register (DBGCAH) ........................................
    • 15.5.3.2 Debug Comparator A Low Register (DBGCAL) .........................................
    • 15.5.3.3 Debug Comparator B High Register (DBGCBH) .........................................
    • 15.5.3.4 Debug Comparator B Low Register (DBGCBL) ..........................................
      • MC9S08GB/GT Data Sheet, Rev. 2.
    • 15.5.3.5 Debug FIFO High Register (DBGFH) .......................................................... Section Number Title Page
    • 15.5.3.6 Debug FIFO Low Register (DBGFL) ...........................................................
    • 15.5.3.7 Debug Control Register (DBGC) ..................................................................
    • 15.5.3.8 Debug Trigger Register (DBGT) ..................................................................
    • 15.5.3.9 Debug Status Register (DBGS) .....................................................................
• A.1 Introduction ................................................................................................................................... Electrical Characteristics
• A.2 Absolute Maximum Ratings ..........................................................................................................
• A.3 Thermal Characteristics .................................................................................................................
• A.4 Electrostatic Discharge (ESD) Protection Characteristics ............................................................
• A.5 DC Characteristics .........................................................................................................................
• A.6 Supply Current Characteristics ......................................................................................................
• A.7 ATD Characteristics ......................................................................................................................
• A.8 Internal Clock Generation Module Characteristics .......................................................................
  • A.8.1 ICG Frequency Specifications ........................................................................................
• A.9 AC Characteristics .........................................................................................................................
  • A.9.1 Control Timing ...............................................................................................................
  • A.9.2 Timer/PWM (TPM) Module Timing ..............................................................................
  • A.9.3 SPI Timing ......................................................................................................................
• A.10 FLASH Specifications ...................................................................................................................
• B.1 Ordering Information .................................................................................................................... Ordering Information and Mechanical Drawings
• B.2 Mechanical Drawings ....................................................................................................................
• B.3 64-Pin LQFP Package Drawing ....................................................................................................
• B.4 48-Pin QFN Package Drawing ......................................................................................................
• B.5 44-Pin QFP Package Drawing .......................................................................................................
• B.6 42-Pin SDIP Package Drawing .....................................................................................................

MC9S08GB/GT Data Sheet, Rev. 2.

Chapter 1 Introduction

1.1 Overview

The MC9S08GB/GT are members of the low-cost, high-performance HCS08 Family of 8-bit microcontroller units (MCUs). All MCUs in the family use the enhanced HCS08 core and are available with a variety of modules, memory sizes, memory types, and package types.

1.2 Features

Features have been organized to reflect:

• Standard features of the HCS08 Family
• Features of the MC9S08GB/GT MCU

1.2.1 Standard Features of the HCS08 Family

• 40-MHz HCS08 CPU (central processor unit)
• HC08 instruction set with added BGND instruction
• Background debugging system (see also Chapter 15, “Development Support”)
• Breakpoint capability to allow single breakpoint setting during in-circuit debugging (plus two more breakpoints in on-chip debug module)
• Debug module containing two comparators and nine trigger modes. Eight deep FIFO for storing change-of-flow addresses and event-only data. Debug module supports both tag and force breakpoints.
• Support for up to 32 interrupt/reset sources
• Power-saving modes: wait plus three stops
• System protection features: — Optional computer operating properly (COP) reset — Low-voltage detection with reset or interrupt — Illegal opcode detection with reset — Illegal address detection with reset (some devices don’t have illegal addresses)

1.2.2 Features of MC9S08GB/GT Series of MCUs

• On-chip in-circuit programmable FLASH memory with block protection and security options (see Table 1-1 for device specific information)
• On-chip random-access memory (RAM) (see Table 1-1 for device specific information)
• 8-channel, 10-bit analog-to-digital converter (ATD)
• Two serial communications interface modules (SCI)
• Serial peripheral interface module (SPI)

MCU Block Diagrams

MC9S08GB/GT Data Sheet, Rev. 2.

1.3 MCU Block Diagrams

These block diagrams show the structure of the MC9S08GB/GT MCUs.

Figure 1-1. MC9S08GBxx Block Diagram

PTD3/TPM2CH

PTD4/TPM2CH

PTD5/TPM2CH

PTD6/TPM2CH

PTC1/RxD PTC0/TxD

VSS

V (^) DD

PTE3/MISO PTE2/SS

PTA7/KBI1P7–

PTE0/TxD

PTE1/RxD

PTD2/TPM1CH PTD1/TPM1CH PTD0/TPM1CH

PTC PTC PTC PTC PTC3/SCL PTC2/SDA

PORT A

PORT C

PORT D

PORT E

8-BIT KEYBOARD INTERRUPT MODULE (KBI1)

IIC MODULE (IIC1)

SERIAL PERIPHERAL INTERFACE MODULE (SPI1)

USER FLASH

USER RAM (GB60 = 4096 BYTES)

DEBUG MODULE (DBG)

(GB60 = 61,268 BYTES)

HCS08 CORE

NOTES:

1. Port pins are software configurable with pullup device if input port.
2. Pin contains software configurable pullup/pulldown device if IRQ enabled (IRQPE = 1).
3. IRQ does not have a clamp diode to VDD. IRQ should not be driven above VDD.
4. Pin contains integrated pullup device.
5. High current drive
6. Pins PTA[7:4] contain both pullup and pulldown devices. Pulldown available when KBI enabled (KBIPn = 1).

NOTE 1

NOTE 1

3-CHANNEL TIMER/PWM MODULE (TPM1)

PTB7/AD1P7– PORT B

PTE5/SPSCK PTE4/MOSI

PTE

PTE

INTERFACE MODULE (SCI2)

HCS08 SYSTEM CONTROL RESETS AND INTERRUPTS MODES OF OPERATION POWER MANAGEMENT

VOLTAGE REGULATOR

RTI

SERIAL COMMUNICATIONS

COP IRQ LVD

INTERNAL BUS

LOW-POWER OSCILLATOR

INTERNAL CLOCK GENERATOR (ICG)

RESET

VSSAD

V (^) DDAD

V (^) REFH V (^) REFL

ANALOG-TO-DIGITAL CONVERTER (ATD1)

INTERFACE MODULE (SCI1)

SERIAL COMMUNICATIONS

5-CHANNEL TIMER/PWM MODULE (TPM2)

PORT F

PTF7–PTF

NOTE 1

PTD7/TPM2CH

8 PTA0/KBI1P

8 PTB0/AD1P

8

PTG PTG2/EXTAL PTG0/BKGD/MS

PTG1/XTAL

PORT G

PTG

PTG

PTG PTG

NOTE 4

NOTES 1, 5

(GB32 = 32,768 BYTES)

(GB32 = 2048 BYTES)

IRQ NOTES 2, 3

10-BIT

NOTES 1, 6

NOTE 1

NOTES 1, 5

BDC CPU

Chapter 1 Introduction

MC9S08GB/GT Data Sheet, Rev. 2.

Figure 1-2. MC9S08GTxx Block Diagram

PTD3/TPM2CH

PTD4/TPM2CH

PTC1/RxD PTC0/TxD

VSS

V (^) DD

PTE3/MISO PTE2/SS

PTA7/KBI1P7–

PTE0/TxD

PTE1/RxD

PTD1/TPM1CH PTD0/TPM1CH

PTC6 (NOTE 6) PTC5 (NOTE 6) PTC PTC3/SCL PTC2/SDA

PORT A

PORT C

PORT D

PORT E

8-BIT KEYBOARD INTERRUPT MODULE (KBI1)

IIC MODULE (IIC1)

SERIAL PERIPHERAL INTERFACE MODULE (SPI1)

USER FLASH

USER RAM (GT60 = 4096 BYTES)

DEBUG MODULE (DBG)

(GT60 = 61,268 BYTES)

HCS08 CORE

NOTES:

1. Port pins are software configurable with pullup device if input port.
2. Pin contains software configurable pullup/pulldown device if IRQ enabled (IRQPE = 1).
3. IRQ does not have a clamp diode to VDD. IRQ should not be driven above VDD.
4. Pin contains integrated pullup device.
5. High current drive
6. PTC[6:5] are not available on the 42-pin SDIP package.
7. Pins PTA[7:4] contain both pullup and pulldown devices. Pulldown available when KBI enabled (KBIPn = 1).
8. Only two timer channels per TPM are bonded out. All channels are available for use as software compare.

NOTE 1

NOTE 1

3-CHANNEL TIMER/PWM MODULE (TPM1)

PTB7/AD1P7– PORT B

PTE5/SPSCK PTE4/MOSI

INTERFACE MODULE (SCI2)

HCS08 SYSTEM CONTROL RESETS AND INTERRUPTS MODES OF OPERATION POWER MANAGEMENT

VOLTAGE REGULATOR

RTI

SERIAL COMMUNICATIONS

COP IRQ LVD

INTERNAL BUS

LOW-POWER OSCILLATOR

INTERNAL CLOCK GENERATOR (ICG)

RESET

VSSAD

V (^) DDAD

V (^) REFH V (^) REFL

ANALOG-TO-DIGITAL CONVERTER (ATD1)

INTERFACE MODULE (SCI1)

SERIAL COMMUNICATIONS

5-CHANNEL TIMER/PWM MODULE (TPM2)

NOTE 1

8 PTA0/KBI1P

8 PTB0/AD1P

PTG2/EXTAL

PTG0/BKGD/MS

PTG1/XTAL PORT G

NOTE 4

NOTES 1, 5

(GT32 = 32,768 BYTES)

(GT32 = 2048 BYTES)

IRQ NOTES 2, 3

10-BIT

NOTES 1, 7

NOTE 1

(NOTE 8)

(NOTE 8)

BDC CPU

(GT16 = 16,384 BYTES)

(GT16 = 1024 BYTES)
