1
The Internet
Introductory material. An overview lecture that covers Internet related topics, including adefinition of the Internet, an overview of its history and growth, andstandardization and naming.
docsity.com
A Definition^ •
On October 24, 1995, the FNC unanimously passed aresolution defining the term Internet.
- RESOLUTION:
The Federal Networking Council (FNC) agrees that the
following language reflects our definition of the term "Internet"."Internet" refers to the global information system that --
•(i) is logically linked together by a globally unique address spacebased on the Internet Protocol (IP) or i
t^ s subsequent
extensions/follow-ons;•(ii) is able to support communications using the TransmissionControl Protocol/Internet Protocol (TCP/IP) suite or its subsequentextensions/follow-ons, and/or other IP-compatible protocols; and•(iii) provides, uses or makes accessible, either publicly or privately,high level services layered on the communications and relatedinfrastructure described herein.
docsity.com
Applications of the Internet^ •
Traditional core applications:
EmailNewsRemote LoginFile Transfer
•^
The killer application:
World-Wide Web (WWW)
•^
New applications:
VideoconferencingTelephonyP2P applicationsInternet Broadcast
docsity.com
Time Line of the Internet
- Source:
Internet
Society
docsity.com
Internet Infrastructure
local ISP
cam pusnetwork
corporatenetwork
IXP
RegionalNetwork
RegionalNetwork local ISP
local ISP
IXP
IXP
Backbone NetworkBackbone Network
RegionalNetwork
RegionalNetwork
docsity.com
Internet Infrastructure^ •
The infrastructure of the Internet consists of a federation ofconnected networks that are each independently managed(“
autonomous system
- Note: Each “autonomous system may consist of multiple IP
networks
- Autonomous systems have a number (
AS number
•^
Hierarchy of network service providers (NSPs)–
Tier-
: nation or worldwide network (US: less than 20)
Tier-2:
regional networks (in US: less than 100)
Tier-3:
local Internet service provider (in US: several
thousand)
docsity.com
Topology of a Tier-1 NSP
docsity.com
Organization of a single node in a Tier-1 network
Com 3 Com 3 Com 3 Com 3
Bay Networks Bay Networks
M odem Bank
SD SD
Modem Bank Modem Bank^
Modem Bank Modem Bank
docsity.com
Internet Standardization Process^ •
Working groups present their work i of the Internet arepublished as RFC (Request for Comments). RFCs are thebasis for Internet standards.
-^
Not all RFCs become Internet Standards! (There are >3000RFCs and less than 70 Internet standards)
-^
A typical (but not only) way of standardization is:– Internet Drafts– RFC– Proposed Standard– Draft Standard (requires 2 working implementation)– Internet Standard (declared by IAB)
docsity.com
Assigning Identifiers for the Internet^ •
Who gives the university the domain name “virginia.edu”
-^
Who assigns it the network prefix “128.143.0.0/16”?
-^
Who assigns port 80 as the default port for web servers?
-^
The functions associated with the assignment of numbers isreferred to as
Internet Assigned Number Authority
(IANA).
•^
IANA used to be managed by Jon Postel at ISI
-^
Since the 1990s, IP addresses and domain name allocationare delegated to independent organizations. Differentorganizations are responsible for allocating domain namesand IP addresses
docsity.com
Regional Internet Registries (RIRs)^ •^
Registration and management of IP address is done by
Regional Internet
Registries (RIRs)
-^
Where do RIRs get their addresses from: IANA maintains a high-levelregistry that distributes large blocks to RIRs
-^
RIR are administer allocation of:– IPv4 address blocks– IPv6 address blocks– Autonomous system (AS) numbers
-^
There are currently 4 RIRs worldwide:–
APNIC
(Asia/Pacific Region),
-^
ARIN
(North America and Sub-Sahara Africa),
-^
LACNIC
(Latin America and some Caribbean Islands)
-^
RIPE
NCC (Europe, the Middle East, Central Asia, and African
countries located north of the equator).
-^
A fifth regional registry (AfriNIC) is in formation for Africa.
docsity.com
Transitioning of Domain Name Registration^ •^
Until 1992:
Domain name registration done as part of IANA
-^
1992:
InterNIC was created in a partnership between US government and
companies to organize and maintain the growing DNS registry andservices. The company Network Solutions ran the administration ofInterNIC. Until 1998, Network Solutions had a monopoly for domainnames.
-^
1995:
InterNIC started harging for domain names ($100 for 2 years)
-^
1997:
President Clinton directs the Secretary of Commerce to privatize
the management of the domain name system (DNS) in a manner thatincreases competition and facilitates international participation in itsmanagement.
-^
1998:
ICANN was created in response to a policy statement issued by the
US Department of Commerce that called for the formation of a privatesector not-for-profit Internet stakeholder to administer policy for theInternet name and address system. ICANN operates under a renewable 3-year contract with the US Department of the Commerce.– ICANN accredits domain-name registrar for .com, .org., .net (and other
domain)
docsity.com
