3x00 XY-Stage

Transit/Settling Time

Engr/Math/Physics 25

Executive Summary

  • Test Procedure
    • Attach Accelerometer to 3xxx Stage
    • Move Stage in Short, Medium, Long Runs
    • Record Accelerometer OutPut With Oscope
  • Estimated SETTLING TIME: <15ms
  • Olympus Stage Transit-Time Model
    • d ≡ Travel Distance in mm
    • T (^) t ≡ Transit Time in mS

T = [ 4. 37 mS mm] ⋅ d + 46. 5 mS

t

Test Design

  • Attach Accelerometer to XY-Stage
  • Measure Accelerometer Output w/ Oscope
  • Program System for Die Jumps on 200mm wafer

with KLARRF Map Die Patterns

  • X-Pitch = 7.8408280000e+03 μm (7.8408 mm)
  • Y-Pitch = 1.4138693000e+04 μm (14.1387 mm)
  • Die Jumps: L↔R, T↔B, UL↔LR, UR↔LL
  • Full Cross-Wafer (long) Moves
  • 4-Die Moves
  • Single-Die Moves

Stage-Move Profiles – 200mm Wafer

LEGEND

LONG MOVE

4-DIE MOVE

SINGLE-DIE MOVE

174.4 mm

12.7mm

50.9 mm

AVG. DISTANCE

Results & Analysis

cont.

  • Max Z-Acceleration = 5.92g
  • Y-Axis “Rattles” about 4-TIMES More than the

X-Axis

OTA-3220 Stage Transit-Time Test • Oct

t = 4.3725d + 46. R^2 = 0.

0

100

200

300

400

500

600

700

800

900

0 20 40 60 80 100 120 140 160 180

Stage Travel Distance (mm)
Stage Travel Time (mS)
Travel-Time (mS)

file = OTA3200_Stage-Settling_Time_0210.XLS

Velocity/Slope = 229 mm/S

OTA-3220 Stage Settling • Single-Die UR-Diag Move

0

50

100

150

200

250

300

350

400

-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.

Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc)
Vhi (Vdc)

file = OTA3200_Stage-Settling_Time_0210.XLS

OTA-3220 Stage Settling • Single-Die +y Move

0

50

100

150

200

250

-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.

Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc)
Vhi (Vdc)
Lt Boundary
Rt boundary

file = OTA3200_Stage-Settling_Time_0210.XLS

Settling time = ~12.8ms
OTA-3220 Stage Settling • Single-Die DIAG-LR Move

0

50

100

150

200

250

-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0.

Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc)
Vhi (Vdc)
Lt Boundary
Rt boundary

file = OTA3200_Stage-Settling_Time_0210.XLS

Settling time = ~14.4ms
OTA-3220 Stage Settling • Single-Die DIAG-LR Move

0

20

40

60

80

0.110 0.115 0.120 0.125 0.130 0.135 0.

Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc)
Vhi (Vdc)
Lt Boundary
Rt boundary

file = OTA3200_Stage-Settling_Time_0210.XLS

Settling time = ~14.

AcceleroMeter Specifications

KLARFF Map Details

FileVersion 1 1;
FileTimestamp 08-22-02 13:33:54;
InspectionStationID "NONE" "BITMAP" "ORB102";
SampleType WAFER;
ResultTimestamp 08-22-02 10:14:55;
LotID "QT96B2815340_3";
SampleSize 1 200;
SetupID "T96B_UP" 05-08-02 07:02:28;
StepID "RTP_ANNEAL_2";
SampleOrientationMarkType NOTCH;
OrientationMarkLocation UP;
DiePitch 7.8408280000e+03 1.4138693000e+04;
DieOrigin 0.0000000000e+00 0.0000000000e+00;
WaferID "01";
Slot 1;
SampleCenterLocation 4.3974690000e+03 7.8404710000e+03;
