3x00 XY-Stage
Transit/Settling Time
Effecting Planer Motion
An XY
Stage
Goals & Logistics
- Goals → For 3xxx XY-Stage Determine
- Typical AntiVibration-Table Settling Time
- Model: Transit-Time vs. Transit-Distance
- Logistics
- Test Date = 15-Oct-
- Experimenters = B. Mayer, CEE
- Test System = YYY-3xxx
- Hi-Accuracy XY-Stage
- Mechanical (i.e., spring-based)
AntiVibration Table
Test Design
- Attach Accelerometer to XY-Stage
- Measure Accelerometer Output w/ Oscope
- Program System for Die Jumps on 200mm wafer
with KLARRF Map Die Patterns
- X-Pitch = 7.8408280000e+03 μm (7.8408 mm)
- Y-Pitch = 1.4138693000e+04 μm (14.1387 mm)
- Die Jumps: L↔R, T↔B, UL↔LR, UR↔LL
- Full Cross-Wafer (long) Moves
- 4-Die Moves
- Single-Die Moves
Instrumentation
Fluke-199 200 MHz
ScopeMeter
Omega ACC-PS
AcceleroMeter
Power Supply
Cables To/From
AcceleroMeter
Stage-Move Profiles – 200mm Wafer
LEGEND
LONG MOVE
4-DIE MOVE
SINGLE-DIE MOVE
174.4 mm
12.7mm
50.9 mm
AVG. DISTANCE
Results & Analysis
cont.
- Max Z-Acceleration = 5.92g
- Y-Axis “Rattles” about 4-TIMES More than the
X-Axis
- Suggests inquiry into the source of the added
Settling Time
OTA-3220 Stage Transit-Time Test • Oct
t = 4.3725d + 46. R^2 = 0.
0
100
200
300
400
500
600
700
800
900
0 20 40 60 80 100 120 140 160 180 Stage Travel Distance (mm)
Stage Travel Time (mS)
Travel-Time (mS)
file = OTA3200_Stage-Settling_Time_0210.XLS
Velocity/Slope = 229 mm/S
OTA-3220 Stage Settling • Single-Die UR-Diag Move
0
50
100
150
200
250
300
350
400
-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0. Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc)
Vhi (Vdc)
file = OTA3200_Stage-Settling_Time_0210.XLS
Ramps Only
OTA-3220 Stage Settling • Single-Die +y Move
0
50
100
150
200
250
-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0. Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc) Vhi (Vdc) Lt Boundary Rt boundary
file = OTA3200_Stage-Settling_Time_0210.XLS
Settling time = ~12.8ms
OTA-3220 Stage Settling • Single-Die DIAG-LR Move
0
50
100
150
200
250
-0.04 -0.02 0.00 0.02 0.04 0.06 0.08 0.10 0.12 0.14 0. Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc) Vhi (Vdc) Lt Boundary Rt boundary
file = OTA3200_Stage-Settling_Time_0210.XLS
Settling time = ~14.4ms
OTA-3220 Stage Settling • Single-Die DIAG-LR Move
0
20
40
60
80
0.110 0.115 0.120 0.125 0.130 0.135 0. Time (s)
AcceleroMeter Output (mVdc)
Vlo (Vdc) Vhi (Vdc) Lt Boundary Rt boundary
file = OTA3200_Stage-Settling_Time_0210.XLS
Settling time = ~14.
All Done for the COURSE
See You in
Fall 2012
All Done for Today
