Steel Bolts & Welding 1Lecture 21 Architectural Structures
ARCHITECTURAL STRUCTURES: FORM, BEHAVIOR, AND DESIGN
lecture
twenty one
steel construction:
bolted & welded connections
nrmc.org
Steel Bolts & Welding 2 Lecture 21
Connections
- needed to:
- support beams by columns
- connect truss members
- splice beams or columns
- transfer load
- subjected to
- tension or compression
- shear
- bending
Steel Bolts & Welding 4Lecture 21 Architectural Structures
Welds
- welded steel connections
http://courses.civil.ualberta.ca
Steel Bolts & Welding 5Lecture 21 Architectural Structures
Bolts
- types
- materials
- high strength
- A307, A325, A
- location of threads
- included - N
- excluded - X
- friction or bearing (SC)
- always tightened
- materials
Steel Bolts & Welding 7 Lecture 21
Bolts
- rarely fail in bearing
- holes considered 1/8” larger
- shear & tension
- single shear or tension
- double shear
v 0 .7 5
R (^) n Fn Ab
R (^) n Fn 2 Ab
(^) Ru v Rn n a
R R
Bolts
Steel Bolts & Welding 8Lecture 21
Bolts
Steel Bolts & Welding 10Lecture 121
Steel Bolts & Welding 11 Lecture 21
Welded Connection Design
- considerations
- shear stress
- yielding
- rupture
Steel Bolts & Welding 13Lecture 21
Welded Connection Design
- weld process
- melting of material
- melted filler - electrode
- shielding gas / flux
- potential defects
- weld materials
- E60XX
- E70XX FEXX = 70 ksi
Steel Bolts & Welding 14Lecture 21
Welded Connection Design
- shear failure assumed
- throat
- T = 0.707 x weld size
- area
- A = T x length of weld
- weld metal generally stronger than base metal (ex. Fy = 50 ksi)
- shear
- table for S
Steel Bolts & Welding 16Lecture 21
Welded Connection Design
area
a ^ n
R R Ru R n 0 .7 5
R (^) n 0_._ 6 FE X X T l S l
Steel Bolts & Welding 17Lecture 21
Framed Beam Connections
- angles
- bolted
- welded
Steel Bolts & Welding 19Lecture 21
Framed Beam Connections
- tables for standard
bolt sizes & spacings
- # bolts
- bolt diameter, angle
leg thickness
- bearing on
beam web
Steel Bolts & Welding 20Lecture 21
Framed Beam Connections
- welded example (shear)
(AISC - Steel Structures of the Everyday)
