24.1 What Is a Process
A running application that consists of a private virtual address space, code, data, and other operating-system resources, such as files, pipes, and synchronization objects that are visible to the process. A process also contains one or more threads that run in the context of the process.
An application consists of one or more processes. A process , in the simplest terms, is an executing program. One or more threads run in the context of the process. A thread is the basic unit to which the operating system allocates processor time. A thread can execute any part of the process code, including parts currently being executed by another thread. A fiber is a unit of execution that must be manually scheduled by the application. Fibers run in the context of the threads that schedule them.
24.2 Memory Management Basics
Each process on 32-bit Microsoft® Windows® has its own virtual address space that enables addressing up to 4 gigabytes of memory. All threads of a process can access its virtual address space. However, threads cannot access memory that belongs to another process which protects a process from being corrupted by another process.
24.2.1 Virtual Address Space
The virtual addresses used by a process do not represent the actual physical location of an object in memory. Instead, the system maintains a page map for each process, which is an internal data structure used to translate virtual addresses into corresponding physical addresses. Each time a thread references an address, the system translates the virtual address to a physical address.
The virtual address space is divided into partitions as follows: The 2 GB partition in low memory (0x00000000 through 0x7FFFFFFF) is available to the process, and the 2 GB partition in high memory (0x80000000 through 0xFFFFFFFF) is reserved for the system.
24.2.2 Virtual Address Space and Physical storage
The virtual address space of each process is much larger than the total physical memory available to all processes. To increase the size of physical storage, the system uses the disk for additional storage. The total amount of storage available to all executing processes is the sum of the physical memory and the free space on disk available to the paging file , a disk file used to increase the amount of physical storage. Physical storage and the virtual address space of each process are organized into pages , units of memory, whose size depends on the host computer. For example, on x86 computers the host page size is 4 kilobytes.
To maximize its flexibility in managing memory, the system can move pages of physical memory to and from a paging file on disk. When a page is moved in physical memory, the system updates the page maps of the affected processes. When the system needs space in physical memory, it moves the least recently used pages of physical memory to the paging file. Manipulation of physical memory by the system is completely transparent to applications which operate only in their virtual address spaces.
24.2.3 Page State
The pages of a process's virtual address space can be in one of the following states.
State Description
Free
The page is neither committed nor reserved. The page is not accessible to the process. It is available to be committed, reserved, or simultaneously reserved and committed. Attempting to read from or write to a free page results in an access violation exception.
A process can use the VirtualFree or VirtualFreeEx function to release reserved or committed pages of its address space, returning them to the free state.
Reserved
The page has been reserved for future use. The range of addresses cannot be used by other allocation functions. The page is not accessible and has no physical storage associated with it. It is available to be committed.
A process can use the VirtualAlloc or VirtualAllocEx function to reserve pages of its address space and later to commit the reserved pages. It can use VirtualFree or VirtualFreeEx to decommit committed pages and return them to the reserved state.
Committed
Physical storage is allocated for the page, and access is controlled by a memory protection option. The system initializes and loads each committed page into physical memory only during the first attempt to read or write to that page. When the process terminates, the system releases the storage for committed pages.
A process can use VirtualAlloc or VirtualAllocEx to allocate committed pages. These functions can commit pages that are already committed. The GlobalAlloc and LocalAlloc functions allocate committed pages with read/write access.
24.3 Memory Protection
Memory that belongs to a process is implicitly protected by its private virtual address space. In addition, Windows provides memory protection using the virtual memory hardware. The implementation of this protection varies with the processor. For example,
When an access attempt leads the system to turn off guard page status, the underlying page protection takes over.
If a guard page exception occurs during a system service, the service typically returns a failure status indicator.
This value cannot be used with PAGE_NOACCESS.
PAGE_NOCACHE
Does not allow caching of the committed regions of pages in the CPU cache. The hardware attributes for the physical memory should be specified as "no cache." This is not recommended for general usage. It is useful for device drivers; for example, mapping a video frame buffer with no caching.
This value cannot be used with PAGE_NOACCESS.
Copy-on-Write Protection
Copy-on-write protection is an optimization that allows multiple processes to map their virtual address spaces such that they share a physical page until one of the processes modifies the page. This is part of a technique called lazy evaluation , which allows the system to conserve physical memory and time by not performing an operation until absolutely necessary.
For example, suppose two processes load pages from the same DLL into their virtual memory spaces. These virtual memory pages are mapped to the same physical memory pages for both processes. As long as neither of the processes writes to these pages, they can map to and share the same physical pages as shown in the following diagram.
If Process 1 writes to one of these pages, the contents of the physical page are copied to another physical page and the virtual memory map is updated for Process 1. Both processes now have their own instance of the page in physical memory. Therefore, it is
not possible for one process to write to a shared physical page and for the other process to see the changes.
Figure 1
Loading Applications and DLLs
When multiple instances of the same Windows-based application are loaded, each instance is run in its own protected virtual address space. However, their instance handles ( hInstance ) typically have the same value. This value represents the base address of the application in its virtual address space. If each instance can be loaded into its default base address, it can map to and share the same physical pages with the other instances, using copy-on-write protection. The system allows these instances to share the same physical pages until one of them modifies a page. If for some reason one of these instances cannot be loaded in the desired base address, it receives its own physical pages.
DLLs are created with a default base address. Every process that uses a DLL will try to load the DLL within its own address space at the default virtual address for the DLL. If multiple applications can load a DLL at its default virtual address, they can share the same physical pages for the DLL. If for some reason a process cannot load the DLL at the default address, it loads the DLL elsewhere. Copy-on-write protection forces some of the DLL's pages to be copied into different physical pages for this process, because the fixups for jump instructions are written within the DLL's pages, and they will be different for this process. If the code section contains many references to the data section, this can cause the entire code section to be copied to new physical pages.
24.4 What is a Thread
A thread is the basic unit to which the operating system allocates processor time. A thread can execute any part of the process code, including parts currently being executed by another thread.
The Windows application programming interface (API) is implemented as a set of dynamic-link libraries, so any process that uses the Windows API uses dynamic linking.
Dynamic linking allows a module to include only the information needed to locate an exported DLL function at load time or run time. Dynamic linking differs from the more familiar static linking, in which the linker copies a library function's code into each module that calls it.
Types of Dynamic Linking
There are two methods for calling a function in a DLL:
- In load-time dynamic linking , a module makes explicit calls to exported DLL functions as if they were local functions. This requires you to link the module with the import library for the DLL that contains the functions. An import library supplies the system with the information needed to load the DLL and locate the exported DLL functions when the application is loaded.
- In run-time dynamic linking , a module uses the LoadLibrary or LoadLibraryEx function to load the DLL at run time. After the DLL is loaded, the module calls the GetProcAddress function to get the addresses of the exported DLL functions. The module calls the exported DLL functions using the function pointers returned by GetProcAddress.
DLLs and Memory Management
Every process that loads the DLL maps it into its virtual address space. After the process loads the DLL into its virtual address, it can call the exported DLL functions.
The system maintains a per-thread reference count for each DLL. When a thread loads the DLL, the reference count is incremented by one. When the process terminates, or when the reference count becomes zero (run-time dynamic linking only), the DLL is unloaded from the virtual address space of the process.
Like any other function, an exported DLL function runs in the context of the thread that calls it. Therefore, the following conditions apply:
- The threads of the process that called the DLL can use handles opened by a DLL function. Similarly, handles opened by any thread of the calling process can be used in the DLL function.
- The DLL uses the stack of the calling thread and the virtual address space of the calling process.
- The DLL allocates memory from the virtual address space of the calling process.
24.7 DLL Entry Point
The DllMain function is an optional entry point into a dynamic-link library (DLL). If the function is used, it is called by the system when processes and threads are initialized and terminated, or upon calls to the LoadLibrary and FreeLibrary functions.
DllMain is a placeholder for the library-defined function name. You must specify the actual name you use when you build your DLL. For more information, see the documentation included with your development tools.
BOOL WINAPI DllMain( HINSTANCE hinstDLL , /Handle to the instance of the library/ DWORD** fdwReason , /reason of loading and unloading LPVOID* lpvReserved /future use or no use des. By Microsoft/ );
hinstDLL: Handle to the DLL module. The value is the base address of the DLL. The HINSTANCE of a DLL is the same as the HMODULE of the DLL, so hinstDLL can be used in calls to functions that require a module handle. fdwReason: Indicates why the DLL entry-point function is being called. This parameter can be one of the following values.
Value Meaning
DLL_PROCESS_ATTACH
The DLL is being loaded into the virtual address space of the current process as a result of the process starting up or as a result of a call to LoadLibrary. DLLs can use this opportunity to initialize any instance data or to use the TlsAlloc function to allocate a thread local storage (TLS) index.
DLL_THREAD_ATTACH
The current process is creating a new thread. When this occurs, the system calls the entry- point function of all DLLs currently attached to the process. The call is made in the context of the new thread. DLLs can use this opportunity to initialize a TLS slot for the thread. A thread calling the DLL entry-point function with DLL_PROCESS_ATTACH does not call the DLL entry-point function with DLL_THREAD_ATTACH.
Note that a DLL's entry-point function is called with this value only by threads created after the DLL is loaded by the process. When a DLL is loaded using LoadLibrary , existing threads do not call the entry-point function of the newly loaded DLL.
There are cases in which the entry-point function is called for a terminating thread even if the entry-point function was never called with DLL_THREAD_ATTACH for the thread:
- The thread was the initial thread in the process, so the system called the entry- point function with the DLL_PROCESS_ATTACH value.
- The thread was already running when a call to the LoadLibrary function was made, so the system never called the entry-point function for it.
When a DLL is unloaded from a process as a result of an unsuccessful load of the DLL, termination of the process, or a call to FreeLibrary , the system does not call the DLL's entry-point function with the DLL_THREAD_DETACH value for the individual threads of the process. The DLL is only sent a DLL_PROCESS_DETACH notification. DLLs can take this opportunity to clean up all resources for all threads known to the DLL. However, if the DLL does not successfully complete a DLL_PROCESS_ATTACH notification, the DLL does not receive either a DLL_THREAD_DETACH or DLL_PROCESS_DETACH notification.
Warning The entry-point function should perform only simple initialization or termination tasks. It must not call the LoadLibrary or LoadLibraryEx function (or a function that calls these functions), because this may create dependency loops in the DLL load order. This can result in a DLL being used before the system has executed its initialization code. Similarly, the entry-point function must not call the FreeLibrary function (or a function that calls FreeLibrary ), because this can result in a DLL being used after the system has executed its termination code.
It is safe to call other functions in Kernel32.dll, because this DLL is guaranteed to be loaded in the process address space when the entry-point function is called. It is common for the entry-point function to create synchronization objects such as critical sections and mutexes, and use TLS. Do not call the registry functions, because they are located in Advapi32.dll. If you are dynamically linking with the C run-time library, do not call malloc ; instead, call HeapAlloc.
Calling imported functions other than those located in Kernel32.dll may result in problems that are difficult to diagnose. For example, calling User, Shell, and COM functions can cause access violation errors, because some functions in their DLLs call LoadLibrary to load other system components. Conversely, calling those functions during termination can cause access violation errors because the corresponding component may already have been unloaded or uninitialized.
Because DLL notifications are serialized, entry-point functions should not attempt to communicate with other threads or processes. Deadlocks may occur as a result.
24.8 DLL Exports and DLL Imports
The export table How to export and import code (functions) in a DLLs __declspec( dllimport ) int i;
__declspec( dllexport ) void function(void);
24.9 DLL Function and calling function from in it
LoadLibrary loads a library in process address space.
HMODULE LoadLibrary( LPCTSTR lpFileName //file name of module );
FreeLibrary free the library that was loaded previously by LoadLibrary function.
FreeLibrary(hModule)
Now we call function from library using GetProcAddress. GetProcAddress returns the address of the function.
FARPROC GetProcAddress( HMODULE hModule, // handle to DLL module LPCSTR lpProcName // function name );
Summary
Dynamic link libraries are the windows executables but these cannot be executed by writing its name on command line or double clicking on it. These libraries contain separate modules that load and run in any process address space. Thread is the execution unit in a Process. A process can have more than one thread. There are two types of dynamic linking load time dynamic linking and run time dynamic linking. In load time dynamic linking, a module makes explicit calls to exported DLL functions as if they were local functions and in run time dynamic linking Load library function is used to load the library and Get procedure address functions are called to get the address of the function from loaded library. DLL can export functions in the form definition files. In definition file we can provide ordinal as well. Ordinal is a number that is used to locate the function instead of function name.
Exercises
- Create a dynamic link library and make a function which displays only message box.
