Chapter 5:

Errors in Chemical Analyses

Source:

 Measurements invariably involve errors and uncertainties.

 it is impossible to perform a chemical analysis that is totally free of errors or uncertainties

 We can only hope to minimize errors and estimate their size with acceptable accuracy

 Errors are caused by faulty calibrations or standardizations or by random variations and uncertainties in results.

 Frequent calibrations, standardizations, and analyses of known samples can sometimes be used to lessen all but the random errors and uncertainties.

The term error has two slightly different meanings.

1. error refers to the difference between a measured value and the “true” or “known” value.
2. error often denotes the estimated uncertainty in a measurement or experiment.

“ We can only hope to minimize errors and estimate their size with acceptable accuracy”

5A Some important terms

To improve the reliability and to obtain information about the variability of results, two to five portions (replicates) of a sample are usually carried through an entire analytical procedure.

Replicates are samples of about the same size that are carried through an analysis in exactly the same way.

 Individual results from a set of measurements are seldom the same

 Usually, the “best” estimate is considered to be the central value for the set.

 The central value of a set should be more reliable than any of the individual results.

 Usually, the mean or the median is used as the central value for a set of

replicate measurements.

An analysis of the variation in the data allows us to estimate the uncertainty associated with the central value.

The Mean and the Median

The mean, also called the arithmetic mean or the average, is obtained by dividing the sum of replicate measurements by the number of measurements in the set:

 The symbol xi means to add all of the values xi for the replicates; xi represents the individual values of x making up the set of N replicate measurements.

 The median is the middle value in a set of data that has been arranged in numerical order.

 The median is used advantageously when a set of data contain an outlier. An outlier is a result that differs significantly from others in the set.

 An outlier can have a significant effect on the mean of the set but has no effect on the median.

N

x

x

N

i

 i

 ^1

Figure 5-2 Note that we can have very precise results (upper right) with a mean that is not accurate and an accurate mean (lower left) with data points that are imprecise.

Absolute Error

• The absolute error of a measurement is the difference between the measured

value and the true value. If the measurement result is low, the sign is negative; if

the measurement result is high, the sign is positive.

E  xi  xt

Relative Error The relative error of a measurement is the absolute error divided by the true value. Relative error may be expressed in percent, parts per thousand, or parts per million, depending on the magnitude of the result.

 100 %

  t

i t r x

x x E

1. Systematic (or determinate) error, causes the mean of a data set to differ from the accepted value.
2. Random (or indeterminate) error, causes data to be scattered more or less symmetrically around a mean value.

A third type of error is gross error.  These differ from indeterminate and determinate errors.  They usually occur only occasionally, are often large, and may cause a result to be either high or low.  They are often the product of human errors.  Gross errors lead to outliers, results that appear to differ markedly from all other data in a set of replicate measurements.

Chemical analyses are affected by at least two types of errors:

5B Systematic errors

 Systematic errors

 have a definite value, an assignable cause, and are of the same magnitude for replicate measurements made in the same way.  They lead to bias in measurement results.

There are three types of systematic errors:

• Instrumental errors.
• Method errors
• Personal errors

Method Errors

 The nonideal chemical or physical behavior of the reagents and reactions

on which an analysis is based often introduce systematic method errors.

 Such sources of nonideality include the slowness of some reactions, the

incompleteness of others, the instability of some species, the lack of

specificity of most reagents, and the possible occurrence of side reactions that

interfere with the measurement process.

 Errors inherent in a method are often difficult to detect and hence, these

errors are usually the most difficult to identify and correct.

Personal Errors

 result from the carelessness, inattention, or personal limitations of the experimenter.

 Many measurements require personal judgments.

Examples include estimating the position of a pointer between two scale divisions, the

color of a solution at the end point in a titration, or the level of a liquid with respect to a

graduation in a pipet or buret.

Judgments of this type are often subject to systematic, unidirectional errors.

A universal source of personal error is prejudice, or bias.

Number bias is another source of personal error that varies considerably from person to person. The most frequent number bias encountered in estimating the position of a needle on a scale involves a preference for the digits 0 and 5.  Also common is a prejudice favoring small digits over large and even numbers over odd.  Digital and computer displays on ph meters, laboratory balances, and other electronic instruments eliminate number bias because no judgment is involved in taking a reading.

slideplayer.com/Fundamentals of Analytical Chemistry, F.J. Holler, S.R.Crouch

 Proportional Errors

 Proportional errors decrease or increase in proportion to the size of the sample.

 A common cause of proportional errors is the presence of interfering contaminants in the sample.

 For example, a widely used method for the determination of copper is based on the reaction of copper(II) ion with potassium iodide to give iodine. The quantity of iodine is then measured and is proportional to the amount of copper. Iron(III), if present, also liberates iodine from potassium iodide. Unless steps are taken to prevent this interference, high results are observed for the percentage of copper because the iodine produced will be a measure of the copper(II) and iron(III) in the sample.

 The size of this error is fixed by the fraction of iron contamination, which is independent of the size of sample taken. If the sample size is doubled, for example, the amount of iodine liberated by both the copper and the iron contaminant is also doubled. Thus, the magnitude of the reported percentage of copper is independent of sample size.

1. Periodic calibration of equipment is always desirable because the response of most instruments changes with time as a result of component aging, corrosion, or mistreatment.
2. Most personal errors can be minimized by careful, disciplined laboratory work.
3. It is a good habit to check instrument readings, notebook entries, and calculations systematically.
4. Errors due to limitations of the experimenter can usually be avoided by carefully choosing the analytical method or using an automated procedure.

Bias in an analytical method is particularly difficult to detect.  The best way to estimate the bias of an analytical method is by analyzing Standard reference materials (SRMs). 

5B-3 Detection and Elimination of Systematic (Instrumental and Personal) Errors

5B-4 Detection of Systematic (Method) Errors

Independent Analysis

• If standard samples are not available, a second independent and reliable analytical method can be used in parallel.
• The independent method should differ as much as possible from the one under study.
• This practice minimizes the possibility that some common factor in the sample has the same effect on both methods.
• Again, a statistical test must be used to determine whether any difference is a result of random errors in the two methods or due to bias in the method under study.

Blank Determinations

A blank contains the reagents and solvents used in a determination, but no analyte. Often, many of the sample constituents are added to simulate the analyte environment, which is called the sample matrix.

In a blank determination, all steps of the analysis are performed on the blank material. The results are then applied as a correction to the sample measurements.

Blank determinations reveal errors due to interfering contaminants from the reagents and vessels employed in the analysis.

Blanks are also used to correct titration data for the volume of reagent needed to cause an indicator to change color.

Variation in Sample Size

As the size of a measurement increases, the effect of a constant error decreases. Thus, constant errors can often be detected by varying the sample size.
