Cisco CCNA 2 Routing and Switching Instructor Lab Manual
Typology: Exercises
1 / 181
This page cannot be seen from the preview
Don't miss anything!
This document is exclusive property of Cisco Systems, Inc. Permission is granted to print and copy this document for non-commercial distribution and exclusive use by instructors in the CCNA Routing and Switching: Routing and Switching Essentials course as part of an official Cisco Networking Academy Program.
Instructor Note: Red font color or Gray highlights indicate text that appears in the instructor copy only.
Device Interface IP Address Subnet Mask
[[S1Name]] VLAN 1 [[S1Add]] 255.255.255. [[S2Name]] VLAN 1 [[S2Add]] 255.255.255. [[PC1Name]] NIC [[PC1Add]] 255.255.255. [[PC2Name]] NIC [[PC2Add]] 255.255.255.
Configure hostnames and IP addresses on two Cisco Internetwork Operating System (IOS) switches using the command-line interface (CLI). Use Cisco IOS commands to specify or limit access to the device configurations. Use IOS commands to save the running configuration. Configure two host devices with IP addresses. Verify connectivity between the two PC end devices.
As a recently hired LAN technician, your network manager has asked you to demonstrate your ability to configure a small LAN. Your tasks include configuring initial settings on two switches using the Cisco IOS and configuring IP address parameters on host devices to provide end-to-end connectivity. You are to use two switches and two hosts/PCs on a cabled and powered network.
Use a console connection to access each switch. Name [[S1Name]] and [[S2Name]] switches. Use the [[LinePW]] password for all lines. Use the [[SecretPW]] secret password. Encrypt all clear text passwords. Include the word warning in the message-of-the-day (MOTD) Banner. Configure addressing for all devices according to the Addressing Table. Save your configurations. Verify connectivity between all devices. Note: Click Check Results to see your progress. Click Reset Activity to generate a new set of requirements.
Instructor Notes The following information is for the Instructor version only.
Packet Tracer - Skills Integration Challenge
Topology Isomorphs
Instructor Note: Red font color or Gray highlights indicate text that appears in the instructor copy only.
Device Interface IP Address Subnet Mask
S1 VLAN 1 10.10.10.2 255.255.255. PC1 NIC 10.10.10.10 255.255.255.
Part 1: Secure Passwords Part 2: Encrypt Communications Part 3: Verify SSH Implementation
SSH should replace Telnet for management connections. Telnet uses insecure plain text communications. SSH provides security for remote connections by providing strong encryption of all transmitted data between devices. In this activity, you will secure a remote switch with password encryption and SSH.
Part 1: Secure Passwords
a. Using the command prompt on PC1 , Telnet to S1. The user EXEC and privileged EXEC password is cisco. b. Save the current configuration so that any mistakes you might make can be reversed by toggling the power for S. c. Show the current configuration and note that the passwords are in plain text. Enter the command that encrypts plain text passwords: S1(config)# service password-encryption d. Verify that the passwords are encrypted.
Part 2: Encrypt Communications
It is generally not safe to use Telnet, because data is transferred in plain text. Therefore, use SSH whenever it is available. a. Configure the domain name to be netacad.pka. S1(config)# ip domain-name netacad.pka
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Device Interface IP Address Subnet Mask
S1 VLAN 1 10.10.10.2 255.255.255. PC1 NIC 10.10.10.10 255.255.255. PC2 NIC 10.10.10.11 255.255.255. Rogue Laptop NIC 10.10.10.12 255.255.255.
Part 1: Configure Port Security Part 2: Verify Port Security
In this activity, you will configure and verify port security on a switch. Port security allows you to restrict a port’s ingress traffic by limiting the MAC addresses that are allowed to send traffic into the port.
Part 1: Configure Port Security
a. Access the command line for S1 and enable port security on Fast Ethernet ports 0/1 and 0/2. S1(config)# interface range fa0/1 - 2 S1(config-if-range)# switchport port-security b. Set the maximum so that only one device can access the Fast Ethernet ports 0/1 and 0/2. S1(config-if-range)# switchport port-security maximum 1
Packet Tracer - Configuring Switch Port Security
c. Secure the ports so that the MAC address of a device is dynamically learned and added to the running configuration. S1(config-if-range)# switchport port-security mac-address sticky d. Set the violation so that the Fast Ethernet ports 0/1 and 0/2 are not disabled when a violation occurs, but packets are dropped from an unknown source. S1(config-if-range)# switchport port-security violation restrict e. Disable all the remaining unused ports. Hint: Use the range keyword to apply this configuration to all the ports simultaneously. S1(config-if-range)# interface range fa0/3 - 24 , gi1/1 - 2 S1(config-if-range)# shutdown
Part 2: Verify Port Security
a. From PC1 , ping PC. b. Verify port security is enabled and the MAC addresses of PC1 and PC2 were added to the running configuration. c. Attach Rogue Laptop to any unused switch port and notice that the link lights are red. d. Enable the port and verify that Rogue Laptop can ping PC1 and PC2. After verification, shut down the port connected to Rogue Laptop. e. Disconnect PC2 and connect Rogue Laptop to PC2’s port. Verify that Rogue Laptop is unable to ping PC. f. Display the port security violations for the port Rogue Laptop is connected to. S1# show port-security interface fa0/ g. Disconnect Rouge Laptop and reconnect PC2. Verify PC2 can ping PC. h. Why is PC2 able to ping PC1 , but the Rouge Laptop is not? The port security that was enabled on the port only allowed the device, whose MAC was learned first, access to the port while preventing all other devices access.
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Device Interface IP Address Subnet Mask
S1 VLAN 1 10.10.10.2 255.255.255. PC1 NIC 10.10.10.10 255.255.255. PC2 NIC 10.10.10.11 255.255.255.
The network administrator asked you to configure a new switch. In this activity, you will use a list of requirements to configure the new switch with initial settings, SSH, and port security.
Configure S1 with the following initial settings:
Packet Tracer - Skills Integration Challenge
enable config t service password-encryption ! hostname S ! enable secret class ! ip ssh version 2 ip domain-name cisco.com ! username admin secret ccna ! crypto key generate rsa 1024
interface range FastEthernet0/1 - 2 switchport mode access switchport port-security switchport port-security maximum 2 switchport port-security mac-address sticky ! interface range FastEthernet0/3 - 24 , g1/1 - 2 shutdown ! interface Vlan ip address 10.10.10.2 255.255.255. no shutdown ! banner motd #Warning, unauthorized access is prohibited# ! line con 0 password cisco login ! line vty 0 15
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Part 1: Observe Broadcast Traffic in a VLAN Implementation Part 2: Complete Review Questions
In this activity, a 24-port Catalyst 2960 switch is fully populated. All ports are in use. You will observe broadcast traffic in a VLAN implementation and answer some reflection questions.
Part 1: Observe Broadcast Traffic in a VLAN Implementation
a. Click PC0 and click the Desktop tab> Command Prompt. b. Enter the ping 192.168.1.8 command. The ping should succeed. Unlike a LAN, a VLAN is a broadcast domain created by switches. Using Packet Tracer Simulation mode, ping the end devices within their own VLAN. Based on your observation, answer the questions in Step 2.
a. Switch to Simulation mode.
Packet Tracer - Who Hears the Broadcast?
b. Click Edit Filters in the Simulation Panel. Uncheck the Show All/None checkbox. Check the ICMP checkbox. c. Click the Add Complex PDU tool, this is the open envelope icon on the right toolbar. d. Float the mouse cursor over the topology and the pointer changes to an envelope with a plus (+) sign. e. Click PC0 to serve as the source for this test message and the Create Complex PDU dialog window opens. Enter the following values: Destination IP Address: 255.255.255.255 (broadcast address) Sequence Number: 1 One Shot Time: 0 Within the PDU settings, the default for Select Application: is PING. What are at least 3 other applications available for use? DNS, FINGER, FTP, HTTP, HTTPS, IMAP, NETBIOS, PING, POP3, SFTP, SMTP, SNMP, SSH, TELNET, TFTP and OTHER f. Click Create PDU. This test broadcast packet now appears in the Simulation Panel Event List. It also appears in the PDU List window. It is the first PDU for Scenario 0. g. Click Capture/Forward twice. What happened to the packet? The packet is sent to the switch and then broadcast to all of the PCs that belong to the same VLAN and in this case, VLAN 10. h. Repeat this process for PC8 and PC.
Part 2: Complete Review Questions
There are 10 questions worth 10 points each.
Packet Tracer – Investigating a VLAN Implementation
Device Interface IP Address Subnet Mask Default Gateway
S1 VLAN 99 172.17.99.3 1 255.255.255.0 N/A S2 VLAN 99 172.17.99.3 2 255.255.255.0 N/A S3 VLAN 99 172.17.99.33 255.255.255.0 N/A PC1 NIC 172.17.10.21 255.255.255.0 172.17.10. PC2 NIC 172.17.20.22 255.255.255.0 172.17.20. PC3 NIC 172.17.30.23 255.255.255.0 172.17.30. PC4 NIC 172.17.10.24 255.255.255.0 172.17.10. PC5 NIC 172.17.20.25 255.255.255.0 172.17.20. PC6 NIC 172.17.30.26 255.255.255.0 172.17.30. PC7 NIC 172.17.10.27 255.255.255.0 172.17.10. PC8 NIC 172.17.20.28 255.255.255.0 172.17.20. PC9 NIC 172.17.30.29 255.255.255.0 172.17.30.
Part 1: Observe Broadcast Traffic in a VLAN Implementation Part 2: Observe Broadcast Traffic without VLANs Part 3: Complete Reflection Questions
In this activity, you will observe how broadcast traffic is forwarded by the switches when VLANs are configured and when VLANs are not configured.
Part 1: Observe Broadcast Traffic in a VLAN Implementation
a. Wait for all the link lights to turn to green. To accelerate this process, click Fast Forward Time located in the bottom yellow tool bar. b. Click the Simulation tab and use the Add Simple PDU tool. Click on PC1 , and then click on PC. c. Click the Capture/Forward button to step through the process. Observe the ARP requests as they traverse the network. When the Buffer Full window appears, click the View Previous Events button. d. Were the pings successful? Why? No, the pings were not successful because PC1 is on a different VLAN than PC6, which won’t allow these devices to communicate with each other because they are separated logically. e. Look at the Simulation Panel, where did S3 send the packet after receiving it? S3 sent it to PC4 because it was on the same VLAN as PC1. In normal operation, when a switch receives a broadcast frame on one of its ports, it forwards the frame out all other ports. Notice that S2 only sends the ARP request out Fa0/1 to S1. Also notice that S3 only sends the
Packet Tracer – Investigating a VLAN Implementation
ARP request out F0/11 to PC4. PC1 and PC4 both belong to VLAN 10. PC6 belongs to VLAN 30. Because broadcast traffic is contained within the VLAN, PC6 never receives the ARP request from PC1. Because PC is not the destination, it discards the ARP request. The ping from PC1 fails because PC1 never receives an ARP reply.
a. Click the New button under the Scenario 0 dropdown tab. Now click on the Add Simple PDU icon on the right side of Packet Tracer and ping from PC1 to PC. b. Click the Capture/Forward button to step through the process. Observe the ARP requests as they traverse the network. When the Buffer Full window appears, click the View Previous Events button. c. Were the pings successful? Why? Yes, because PC1 and PC4 both belong to VLAN 10, so the path of the ARP request is the same as before. Because PC4 is the destination, it replies to the ARP request. PC1 is then able to send the ping with the destination MAC address for PC4. d. Examine the Simulation Panel. When the packet reached S1 , why does it also forward the packet to PC7? Because PC7 also belong to VLAN 10 and the ARP requests was for VLAN10, switches will forward to any devices that are connected to VLAN10 in their port.
Part 2: Observe Broadcasts Traffic without VLANs
a. Return to Realtime mode. b. Delete the startup configuration on all 3 switches. What command is used to delete the startup configuration of the switches? Switch# erase startup-config c. Where is the VLAN file stored in the switches? flash:vlan.dat d. Delete the VLAN file on all 3 switches. What command deletes the VLAN file stored in the switches? Switch# delete vlan.dat
Use the r eload command in privileged EXEC mode to reset all the switches. Wait for the entire link to turn green. To accelerate this process, click Fast Forward Time located in the bottom yellow tool bar.
a. After the switches reload and the link lights return to green, the network is ready to forward your ARP and ping traffic. b. Select Scenario 0 from the drop down tab to return to Scenario 0. c. From Simulation mode, click the Capture/Forward button to step through the process. Notice that the switches now forward the ARP requests out all ports, except the port on which the ARP request was received. This default action of switches is why VLANs can improve network performance. Broadcast traffic is contained within each VLAN. When the Buffer Full window appears, click the View Previous Events button.
Part 3: Complete Reflection Questions
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Device Interface IP Address Subnet Mask VLAN
PC1 NIC 172.17.10.21 255.255.255.0 10 PC2 NIC 172.17.20.22 255.255.255.0 20 PC3 NIC 172.17.30.23 255.255.255.0 30 PC4 NIC 172.17.10.24 255.255.255.0 10 PC5 NIC 172.17.20.25 255.255.255.0 20 PC6 NIC 172.17.30.26 255.255.255.0 30
Part 1: Verify the Default VLAN Configuration Part 2: Configure VLANs Part 3: Assign VLANs to Ports
VLANs are helpful in the administration of logical groups, allowing members of a group to be easily moved, changed, or added. This activity focuses on creating and naming VLANs, and assigning access ports to specific VLANs.
Packet Tracer – Configuring VLANs
Part 1: View the Default VLAN Configuration
On S1, issue the command that displays all VLANs configured. By default, all interfaces are assigned to VLAN 1.
Notice that each PC can ping the other PC that shares the same network. PC1 can ping PC PC2 can ping PC PC3 can ping PC Pings to PCs in other networks fail. What benefit will configuring VLANs provide to the current configuration? The primary benefits of using VLANs are as follows: security, cost reduction, higher performance, broadcast storm mitigation, improved IT staff efficiency, and simpler project and application management.
Part 2: Configure VLANs
Create the following VLANs. Names are case-sensitive: VLAN 10: Faculty/Staff VLAN 20: Students VLAN 30: Guest(Default) VLAN 99: Management&Native S1#(config)# vlan 10 S1#(config-vlan)# name Faculty/Staff S1#(config-vlan)# vlan 20 S1#(config-vlan)# name Students S1#(config-vlan)# vlan 30 S1#(config-vlan)# name Guest(Default) S1#(config-vlan)# vlan 99 S1#(config-vlan)# name Management&Native
Which command will only display the VLAN name, status, and associated ports on a switch? S1# show vlan brief
Using the same commands from Step 1, create and name the same VLANs on S2 and S3.
