Identify the three layers of a hierarchical network and how they are used in network design.
Instructor Note: This activity can be completed individually or in small groups.
A network administrator is tasked with designing an expanded network for the company.
After speaking with network administrators in other branches of the company, it was decided to use the Cisco three-layer hierarchical network design model to guide the expansion. This model was chosen for its simple influence upon network planning.
The three layers of the expanded network design include:
Access
Distribution
Core
World Wide Web access
Presentation software
a. Find two images that show the three-layer hierarchical design model.
b. Note the online image’s web address.
a. Notice the types of equipment in each layer of the designs you have chosen.
b. Differentiate why it is assumed the types of equipment shown in the images are located where they are on the design.
c. Notice any other differences between the chosen images.
Number of devices used within the layers
Redundancy, if any
a. The two chosen designs with hyperlinks as to their Internet site locations.
b. A statement on each slide as to why the particular image was chosen.
c. Comparison statements as to how the two images differ, but with an explanation of why they are classified as three-level hierarchical designs.
Design Hierarchy
Student or Group Notes as to why this graphic was chosen:
Access layer shows PCs, access switches, VPN gateways, printers, teleworker, home office, and wireless router. Also shown in this layer are redundant links to the distribution layer.
The distribution layer shows several multilayer switches and link connections to the core layer.
The core layer shows multilayer switches and connections to the distribution layer and the cloud.
Basic equipment types are located in the access layer, closest to the user and work with the distribution layer
above it. Most of the network devices are located at this level on both images.
The distribution layer equipment interfaces with both core and access layers in both images. This hierarchical
level seems to contain the most sophisticated and multifunctional equipment. Redundancy is clearly apparent to both core and access layers as shown in the first model. It would seem that high-powered multifunction
Design Hierarchy
switches would be located at this level of the two graphics. The number of network devices shown in both graphics at this level is smaller than the access layer, but larger than the core layer.
As shown in the two previous graphics, the core layer has the most sophisticated equipment. There are fewer
network devices at this layer, which seems to indicate that the devices are highly functioning and fast traffic processors.
Cisco hierarchical design-model levels
Cisco hierarchical design model functions
Types of equipment located in the layers of the hierarchy
Amount of equipment located in the layers of the hierarchy
Borderless Innovations - Everywhere
Note: As students listen to group presentations, they can take notes and submit them to the Instructor.
Borderless Network Service
Basic Definition Borderless Services Offered
Security – TrustSec
The Power of Cisco ISE
A comprehensive borderless network service that focuses on security for wired and wireless networks.
Centralized security management.
Choices for security management policies implementation.
Provides a log for security violations, in both live and historical formats.
It is transparent to users.
Cisco Identity Services Engine
Mobility – Motion
Cisco Data In Motion
A borderless network service that allows network administrators to gather data from sensors, mobile devices, and video cameras to help make decisions and communicate in real-time.
Connects IoE borderless data from manufacturing floors, energy grids, healthcare facilities, and transportation systems.
Consolidates data to help customers improve data operations, while saving valuable time and money.
Helps businesses share data and build a business case for change.
Data in Motion
Application performance
Application Velocity
A borderless network service that uses application-based delivery systems to enhance communications between businesses, customers, and clients.
Delivers real-time, language- translation services
Allows businesses to use network applications to share research and communicate new ideas to each other
Centralizes network applications for simplified delivery and management, reducing operational costs
Application Performance Management Service
Borderless Innovations - Everywhere
Multimedia performance
Video-ready Network with Cisco MediaNet
A borderless network service which allows for easy wired and wireless configuration, media monitoring, and low-cost multimedia operations.
Keeps track of multimedia traffic that flows on the network.
Helps reduce operating costs with fast troubleshooting of video, voice, and data errors.
Enables precise assessment of the impact that video, voice, and data have on the network.
Medianet Architecture
Energy management – EnergyWise
Lights Out - Cisco EnergyWise
A borderless network service that reduces energy costs by using wired and wireless devices.
Enables communications in real time internationally using wired and wireless device delivery systems.
Saves energy costs by delivering information quickly and efficiently.
Saves energy and time by deploying network services instead of using collective human resources efforts.
Borderless Networks video
Borderless network services
Policy strategy planning for borderless network services
Branching Out
Specifics on the requirements of your network as used for calculator input
Output information from your matrix
Additional factors you would consider before purchasing a router or ISR for your new branch office
Instructor Notes: (information will vary for each group depending on calculator information specified)
Suggested routers or ISRs for the branch and WAN office: ______________________
Return on Investment Total Cost of Ownership Energy Savings
(output notes will vary per group depending on WAN considerations and services specified)
WAN locations and sizes
Devices used on the WAN
Cost of ownership for WAN CPE devices
WAN energy savings (green technology)
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Part 1: Investigate Dedicated WAN Technologies and Providers
Part 2: Investigate a Dedicated Leased Line Service Provider in Your Area
Today’s broadband Internet services are fast, affordable, and secure using VPN technologies. However, many companies still find the need for a 24-hour dedicated connection to the Internet or a dedicated point-to- point connection from one office location to another. In this lab, you will investigate the cost and availability of purchasing a dedicated T1 Internet connection for your home or business.
Device with Internet access
Part 1: Investigate Dedicated WAN Technologies and Providers
In Part 1, you will research basic characteristics of dedicated WAN technologies, and in Step 2, you will discover providers that offer dedicated WAN services.
Use search engines and websites to research the following WAN technologies to complete the table below.
Last Mile Media
WAN Technology Dedicated Connection (yes/no)
Copper (yes/no)
Fiber (yes/no)
Wireless (yes/no)
Speed/Range
Navigate to http://www.telarus.com/carriers.html. This webpage lists the Internet service providers (also known as carriers) that partner with Telarus to provide automated real-time telecom pricing. Click the links to the various carrier partners and search for the dedicated WAN technologies that they provide. Complete the table below by identifying each service provider’s dedicated WAN services, based on the information provided on the website. Use the extra lines provided in the table to record additional service providers.
Lab – Researching WAN Technologies
Choose Internet T1 (1.5 MB) and scroll down to Step 3 on the webpage.
Lab – Researching WAN Technologies
a. In the Installation BTN field, enter your sample business telephone number. This should be a landline number.
b. Enter your address, city, state, and zip code.
a. Do not click the first radio button ( Please call me ASAP at ), but do provide your contact telephone number.
b. Click the I am just window shopping radio button.
c. Click Continue.
You should see a list of quotes showing the available pricing of a T1 connection to the location you specified. Was the pricing in the area you chose comparable to those pictured below?
Answers will vary depending on service location and availability.
What was the range of prices from your results?
Answers will vary depending on service location and availability.
Instructor Note : Red font color or Gray highlights indicate text that appears in the instructor copy only.
Select WAN access technologies to satisfy business requirements in a small-to-medium-sized business network.
Instructor Note: This activity can be completed individually or in small groups – it can then be shared and discussed with another group of students, with the entire class, or with the instructor.
Your medium-sized company is upgrading its network. To make the most of the equipment currently in use, you decide to purchase WAN modules instead of new equipment.
All branch offices use either Cisco 1900 or 2911 series ISRs. You will be updating these routers in several locations. Each branch has its own ISP requirements to consider.
To update the devices, focus on the following WAN modules access types:
World Wide Web
Word processing software
Note: If the above link is no longer valid, search the Cisco site for “Interfaces and Modules”.
Ethernet
Broadband
T1/E1 and ISDN PRI
BRI
Serial WAN
WAN Device Modules
T1 and E1Trunk Voice and WAN
Wireless LANs and WANs
Instructor Notes:
This is a good place to have students discuss the terminology. For instance, WIC2T = WAN Interface Card with 2 serial ports.
Students can also add various cards to routers in PT and use commands such as show ip interface brief to view the changes.
Please encourage students to read the datasheet information listed on the modular card graphics sites – they will become familiar with different interface types by doing so.
All graphics will vary as shown in the students’ final matrix – the graphics shown in this Activity Example Solution are representative in nature and were copied from the Cisco products sites. Each graphic is hyperlinked to the source available at the time this activity was created.
WAN Device Modules
Serial
(for use with 2900 series only) One-port clear-channel T3/E3 Service Module 4 - port clear-channel T1/E HWIC 4 - port serial HWI (for use with 2900 and 1900 series) 1 - Port 4-Wire 56/64 Kpbs CSU/DSU WAN Interface Card 1 - Port T1/Fractional T DSU/CSU High-Speed WAN Interface Card* 1 - Port Serial High-Speed WAN Interface Card 2 - Port Serial High-Speed WAN Interface Card
Trunk Voice and WAN
1 - port T1/E1 Voice / WAN w/ D&I & unstructured E (G703)^1 2 - port T1/E1 Voice / WAN w/ Drop & Insert 1 - port T1/E1 Voice / WAN w/ Drop & Insert^2 2 - port T1/E1 Voice / WAN w/ D&I & unstructured E (G703) 1 - port T1/E1 Voice / WAN w/ D&I & unstructured E (G703)
1
2
Wireless LANs and WAN
Dedicated 4G LTE EHWIC for Verizon Wireless Network, US (Verizon SKU) operates on LTE at 700MHz (band 13) with GPS 4G LTE EHWIC for AT&T, 700 MHz Band 17, 850/1900/2100 MHz UMTS/HSPA 4G LTE EHWIC for Europe, LTE 800/900/1800/ 2100/2600 MHz, 90 0/1900/2100 MHz UMTS/HSPA bands (non-US) 3.7G HSPA+ Release 7 EHWIC w/
WAN Device Modules
ATT HSPA+ R7 EHWIC with SMS/GPS based on MC 3.5G EHWIC (Non-US) HSPA/UMTS 850/900/1900/2100MHz with SMS/GPS 3G EHWIC Verizon EV-DO Rev A/0/1xRTT 800/1900MHz with SMS/GPS 3G EHWIC Sprint EV-DO Rev A/0/1xRTT 800/1900MHz with SMS/GPS 3G EHWIC BSNL EV-DO Rev A/0/1xRTT 800/1900MHz with SMS/GPS 3G (for India only) HWIC TATA EVDO Rev A/0/1xRTT 800/1900MH
WAN modular interfaces
Network card interface types
ISR module availability by model type
