Click to edit Master subtitle style Microsoft Virtual Academy

03 | Cluster Networking

Elden Christensen | Principal Program Manager Lead

| Microsoft

Symon Perriman | Vice President | 5nine Software

• (^) Cluster Network Infrastructure fundamentals
• (^) Cluster Network Design Planning
• (^) Cluster Network Configuration Options Module Overview

Health Monitoring of Nodes in the Cluster

• (^) Failover Clustering conducts health monitoring between nodes to detect when servers are no longer available
• (^) When servers are unresponsive clustering takes recovery action
• (^) Unicast in nature and uses a Request- Reply type process for reliability and security - (^) Not just a basic ping You there? Yes You there? Yes

Network Health Detection

• (^) Clustering does full mesh monitoring between all network interfaces between all nodes
• (^) Health monitoring:
  • (^) Nodes exchange heartbeats every 1 second

(configurable)

• (^) Nodes are considered down if they do not

respond to 5 heartbeats (configurable)

• (^) Nodes are removed from cluster membership if they exceed thresholds
• (^) Communication over port 3343

Viewing NetFT Virtual Adapter

• (^) NetFT is a virtual network adapter
  • (^) Visible in Device Manager and with IPConfig /all
• (^) Completely self configuring
  • (^) Media Access Control (MAC) address is self-generated based on a hash of MAC address of the first enumerated (by NDIS) physical NIC in the cluster node
  • (^) NetFT self-configures an APIPA (Automatic Private Internet Protocol Addressing) address
  • (^) No manual user configuration required

NetFT Architecture

• (^) NDIS 6.2 miniport virtual adapter
• (^) Supports Receive Side Scaling (RSS)
• (^) Network fault tolerance for TCP and UDP across routed network connections - Each link independently monitored
• (^) Supports IPv4 and IPv
• (^) Built in route failure detection
• (^) IP over UDP/IP Tunneling
  • Virtual adapter tunnels over physical adapters
• (^) Clustering leverages port 3343
  • (^) NetFT uses UDP 3343
  • (^) ClusSvc uses TCP 3343

NDIS

IP

TCP UDP UDP

NetFT NIC1 NIC

ClusSvc

Cluster Network Discovery

• (^) Cluster uses exactly one IP per Subnet per NIC
  • (^) Cluster ignores other IPs from the same subnet configured on the NIC
  • (^) Cluster ignores other NICs & associated IPs from the same subnet
• (^) Each NIC per Node will be part of exactly one Cluster Network - (^) Cluster will use prefix matching to determine the set of Cluster Networks - (^) Cluster has built-in resilience to use IPv4 or IPv6 per NIC (prefix must match)
• (^) Cluster will use an IP from different Subnet from another NIC
  • (^) Cluster will ignore other IPs configured on that NIC for subnets already discovered

Cluster Network Discovery: Example Same Subnet NIC 2 Same Subnet NIC 2

Cluster Network 1 Cluster Network 1 NIC 2 Ignored By Cluster NIC 2 Ignored By Cluster Same Subnet NIC 1 Same Subnet NIC 1

Cluster Communication

• (^) Clusters exchange three types of communication: Network Health Monitoring
• (^) Heartbeats are sent to monitor health status of network interfaces
• (^) Are sent over all cluster enabled networks Intra-cluster Communication
• (^) Database updates and state synchronization that are sent between the nodes in the cluster
• (^) Example: When creating a new resource the cluster database must be updated on all nodes
• (^) Are over a single interface CSV I/O Redirection
• (^) Metadata updates to files
• (^) All I/O in failure scenarios
• (^) Over same network as intra-cluster communication
• (^) Over a single interface
• (^) Can leverage SMB multi- channel to stream over multiple interfaces

DEMO

Microsoft Virtual Academy

Manage Cluster Networking

Network Bandwidth Planning

• (^) Lightweight (only 134 bytes)
• (^) Sensitive to latency
  • (^) If cluster heartbeats become blocked by a saturated NIC, this could cause nodes to be removed from cluster membership
• (^) Bandwidth not important, but quality of service is Heartbeats
• (^) Lightweight
  • (^) Traffic varies by workload, in general infrequent on running stable File / Hyper-V clusters. Heavier on SQL / Exchange clusters
• (^) Clustering is a distributed synchronous system, latency will slow down cluster state changes (such as failover)
• (^) Bandwidth not important, but quality of service is Intra-Cluster Communication
• (^) Metadata updates
  • (^) Lightweight and Infrequent
  • (^) Latency will slow down I/O performance
    • (^) Yes, network performance will impact storage I/O performance!
  • (^) Quality of service most important
• (^) Failure scenarios / asymmetric storage configurations
  • (^) All I/O is forwarded via SMB over the network
  • (^) Network bandwidth is most important CSV I/O Redirection Key Take-away: Primary design consideration for cluster communication is ensuring quality of service

Traditional Network Configuration Guidance

What we have recommended for the last decade…

• (^) At least 2 independent networks
  • (^) Public / Client Network
    • (^) IPv4 - Static or DHCP assigned address » APIPA (aka. autonet) 169.254.x.x addresses not supported
    • (^) IPv6 Stateless address autoconfiguration (SLAAC) » (^) Note: DHCPv6 not supported for cluster IP Address resources
    • (^) Default gateway (routable)
  • (^) Intra-Node Communication
    • (^) IPv6 (preferred) or IPv » (^) IPv6 Linklocal (fe80) works great
    • (^) No default gateway (non-routable)
    • (^) Separate physical network

This still applies, but we also support converged networking

Are Separate Networks Really Needed? Required?

• (^) No – It is not required to have 2 separate networks
  • (^) Clustering does support a converged networking model
  • (^) Validate will generate a Warning to alert you of a potential single point of failure
    • (^) Validate is not NIC Teaming aware Recommended?
• (^) Yes – It is recommended to have redundant network communication between nodes
• (^) Sort of… let’s talk about what really matters and converged networking (next slide)

Resiliency

• (^) In a highly available system you want to avoid any single points of failure
• (^) Many ways to accomplish network redundancy - (^) Multiple independent

networks

Quality of Service

• (^) Cluster heartbeats are lightweight, but sensitive to latency - (^) If cluster heartbeats can’t get

through… this can be falsely

interpreted that nodes are

down

• (^) Many ways to accomplish network quality of service - (^) Multiple network cards Converged Network Considerations
