IMPACT
Case Study: 026.compress
while ( (c = getchar()) != EOF ) { in_count++; fcode = (long) (((long) c << maxbits) + ent); i = ((c << hshift) ^ ent); /* xor hashing / if ( htabof (i) == fcode ) { ent = codetabof (i); continue; } else if ( (long)htabof (i) < 0 ) / empty slot/ goto nomatch; disp = hsize_reg - i; / secondary hash */ if ( i == 0 ) disp = 1; probe: if ( (i -= disp) < 0 ) i += hsize_reg; if ( htabof (i) == fcode ) { ent = codetabof (i);
continue; } if ( (long)htabof (i) > 0 ) goto probe; nomatch: output ( (code_int) ent ); out_count++; ent = c; if ( free_ent < maxmaxcode ) { codetabof (i) = free_ent++; /* code -> hashtable */ htabof (i) = fcode; } else if ( (count_int)in_count >= checkpoint && block_compress ) cl_block (); }
- Inner loop of compress(): most of execution time!
- The hash table accesses have little reuse in current caches
- htab ~ 270K; codetab ~ 135K
- Even in a 4-way set associative cache there are many conflicts
Htab Memory Access Distribution
Cycle
Address (offset from 1G)
htab load hits htab load misses
IMPACT
Compress Cache Bypass
data should bypass cache
with more frequently
accessed data
- Less cache pollution
- Increase cache reuse of
frequently accessed
addresses
ratio
track of usage patterns
Data Cache
Main Memory
Infrequently Accessed RegFile Frequently Accessed
Memory Macroblocks
accessing behavior
- Combine groups of adjacent
cache blocks into larger
regions called macroblocks
- Macroblock size should be:
- large enough so the total number
of macroblocks is not
unreasonable to track
- small enough so accessing
frequency within each is
relatively uniform
Main Memory
IMPACT
MAT Bypassing Operation
lookup counter in MAT
address
- increment counter
- Save updated counter
value
Data Cache
Main Memory
A
A
B
B ctr
++ctr ctr
MAT
Reg File
Infrequently Accessed Frequently Accessed
MAT Bypassing Operation (cont.)
- If access hit in cache, execute
normally
- If access missed , lookup MAT
counter for cache block that
would be replaced
- Compare counter values
- if ctr1 is lower then bypass cache
- Place bypassing data in a small
set-associative bypass buffer
- Holds bypassed data for a short
time to exploit some temporal
locality
Data Cache
Main Memory
A
A
B
B ctr2- -
ctr ctr CMP
MAT
Buffer
Reg File
bypass?
Infrequently Accessed Frequently Accessed
IMPACT
026.compress
072.sc099.go 147.vortex
Pcode
lmdes2_customizer
085.cc
130.li 134.perl 124.m88ksim
wordexcelphoto
Benchmark
% Improvement over Base
Sampling No Sampling
Performance Improvement
L1 Hit Ratios
026.compress
072.sc099.go 147.vortex
Pcode
lmdes2_customizer
085.cc
130.li 134.perl 124.m88ksim
wordexcelphoto
Benchmark
L1 Hit Ratio
Base Simulator (1024-byte macroblocks) Upper Bound
IMPACT
Example: 085.gcc Routine
int rtx_renumbered_equal_p (rtx x, rtx y)
rtx_code code = x->code;
if (code != y->code) return 0; /* Exits here 448 times (1%) */
/* A: 8 bytes sufficient */
switch (code) {
[...]
case CONST_INT:
return x->fld[0].rtint == y->fld[0].rtint; /* Exits here 29096 times (46%) */
/* A: 8 bytes sufficient */
fmt = GET_RTX_FORMAT (code);
for (i = GET_RTX_LENGTH (code) - 1; i >= 0; i--) {
switch (fmt[i]) {
[...]
case 'e':
if (! rtx_renumbered_equal_p (x->fld[i].rtx, y->fld[i].rtx)) /* Executed 33030 times */
return 0; /* A: More than 8 bytes needed! */
break;
Q: How much data
to fetch on a miss
to y->code?
Cache Organization Alternative:
Variable Fetch: 8-byte lines & 32-byte
virtual lines
ld A
ld B
ld C
ld A
ld C
ld B+
8 bytes
.. .
A
B
.. .
miss C
8 bytes
.. .
A
C
B
.. .
hit B+
hit C
hit A
B+
cache cache
IMPACT
SLDT Hardware
(Spatial Locality Detection Table)
L1 Data Cache
8-byte blocks
... sctr
MAT
SLDT
fetch size?
hit? (^) spatial reuse?
update sctr with hit and spatial reuse results
Memory Address
tag sz vc sr SLDT entry format
(^01) 00
fi bit
SLDT Actions
- When max fetch size block is fetched into data cache
- sz = 1; vc = max_fetch_size/min_fetch_size - 1; sr = 0
- When min fetch size block is fetched into data cache
- no prior SLDT entry: sz = 0; vc = 0; sr = 0
- existing SLDT entry: vc ++
Cache Access SLDT Access fi sz vc Result Result Value Value Value Action miss hit - 0 sr = 1; sctr++
- 1 sr = 1 hit hit 0 sr = 1 0 >0 sr = 1 hit miss 0 - - allocate SLDT entry; sz = 1; sr = 1 1 - - allocate SLDT entry Cache entry vc > 0 vc-- replaced vc == 0 invalidate SLDT entry SLDT entry replaced sr == 0 sctr-- or invalidated sr == 1 no action
tag sz vc sr
SLDT entry:
IMPACT
compress
072.sc
go
147.vortex
Pcode
lmdes2_customizer
gcc 130.li 134.perl 124.m88ksim
word excelphoto
Benchmark
% Improvement over 64-byte L2 Lines with L1 Varying Fetches
32-byte L2 lines (L1 vary fetch) 128-byte L2 lines (L1 vary fetch) 256-byte L2 lines (L1 vary fetch) L2 vary fetch (1-bit sctr) L2 vary fetch (4-bit sctr)
L2 Varying Fetch Sizes
compress
072.sc
go
147.vortex
Pcode
lmdes2_customizer
gcc 130.li 134.perl 124.m88ksim
wordexcelphoto
Benchmark
% Improvement over Base
(sampling) L1/L2 varying fetch (4-bit sctrs) (no sampling) L1/L2 varying fetch (4-bit sctrs)
Performance Improvements
IMPACT
085.gcc Example Revisited
- Access y->code missed 11,223 times
- Fetched 32 bytes 47% of misses
- Fetched 8 bytes 53% of misses
- On average:
- 0.99 spatial hits to the resulting data per miss
- 0.02 spatial misses to the resulting data per miss
- Illustrates that the run-time scheme is doing a good job of
selecting the correct fetch size for the example
Related Work
- A large body of work has examined prefetching
techniques for numeric codes
- Prefetching techniques for integer codes often focus on
prefetching of pointer targets [MeHa95][LuMo96]
[LiSKR95]
- orthogonal to my techniques
- [DuLe92] proposed variable blocksizes to reduce cache
coherence traffic in multiprocessors
- mechanism not geared to exploiting temporal-only data
- used subblocking to support multiple blocksizes
- Split caches provide one cache with short lines and one
with long lines for spatial data [GoAV95][MiMTT96]
- ratio between temporal and spatial data determined at design time
