TVL-ICT (Computer System Servicing)
Activity Sheet Quarter 2 – Lesson 3
Install operating system and drivers for
peripherals/ devices
(Install Operating System – Windows 7)
REGION VI – WESTERN VISAYAS
Development Team of TVL 11- ICT (Computer System Servicing) Activity Sheet Writer : Mario Meynard I. Mutia Illustrators: Editors: Allan Montenegro Layout Artist: Schools Division Quality Assurance Team: Schubert Anthony C. Sialongo Edward E. Baña Allan B. Montenegro Michelle P. Jordan Division of Antique Management Team: Felisa B. Beriong, CESO VI Corazon C. Tingson Gaudencio C. Riego, PhD Schubert Anthony C. Sialongo Edward E. Baña Regional Management Team Ma. Gemma M. Ledesma, Dr. Josilyn S. Solana, Dr. Elena P. Gonzaga, Mr. Donald T. Genine, April C. Velez Abraham P. Imas TVL 11– ICT (Computer System Servicing) Activity Sheet No. 2 First Edition, 2020 Published in the Philippines By the Department of Education Region 6 – Western Visayas Republic Act 8293, section 176 states that: No copyright shall subsist in any work of the Government of the Philippines. However, prior approval of the government agency or office wherein the work is created shall be necessary for exploitation of such work for profit. Such agency or office may, among other things, impose as a condition the payment of royalties. This Learning Activity Sheet is developed by DepEd Region 6 – Western Visayas. ALL RIGHTS RESERVED. No part of this learning resource may be reproduced or transmitted in any form or by any means electronic or mechanical without written permission from the DepEd Regional Office 6 – Western Visayas.
Learning Activity Sheets (LAS) No. 1 Name of Learner:__________________________________________________________ Grade and Section:_____________________________________ Date: ______________ TVL 11- ICT (COMPUTER SYSTEM SERVICING) ACTIVITY SHEET Install Operating System – Windows 10 I. Learning Competency with Code TLE_IACSS9-12ICCS-IIa-j- 30 3.1 Install Operating System (OS) in accordance with established installation procedures and to comply with end-user requirements II. Background Information for Learners Previously, we have learned about Operating System and the development of Windows Operating System. We have also learned about how to install Windows 7 OS. This time, we learn how to reformat our computer using Windows 10. But first let us learn the said OS. Windows 10 Operating System Windows 10 Desktop and Start Menu.
Quarter 2, Week 2
Sometimes abbreviated as Win10, Microsoft Windows 10 is the latest version of Microsoft Windows and was released on July 29, 2015. Windows 10 is an upgrade to Windows 8.1. New Windows 10 features Windows 10 shares many of the features first introduced with Windows 8, in addition to the major features mentioned below. Start menu - Brought back the Windows Start menu, with the tiles introduced in Windows 8 also capable of being displayed in the Start menu. Microsoft Edge - Microsoft has kept Internet Explorer, but also introduced and included the new Microsoft Edge browser for Windows 10 users, and recommends using it as the default browser. Cortana - The new voice assistant Cortana is now part of Windows and the Windows search bar. Action Center - A pop-out window with notifications for Windows and software on the computer and quick access to several features, like Bluetooth, or tablet mode and battery saver options if using a laptop. Action Center replaces the Charms feature available in Windows 8. Tip As of May 2020, the latest version of Windows 10 is version 1909, released on November 12, 2019, and available as a free upgrade through Windows Update. One of the largest updates to Windows 10 was the Fall Creators Update, released on October 17, 2017. What Windows version came before Windows 10? For the end user, Windows 8 came before Windows 10. Note Microsoft skipped from Windows 8 (Windows 8.1) to Windows 10, and there was never a version of Microsoft Windows called "Windows 9." What version of Windows comes after Windows 10? Microsoft has stated that Windows 10 is the last "version" of Windows. In a 2015 blog post, Terry Myerson of Microsoft explained that Windows is transitioning to a service model. Rather than moving towards "Windows 11," Microsoft is focusing on updating Windows 10 on the second Tuesday of every month, with major updates planned for release around April and October of each year. For instance, in 2017, Microsoft released the Creators Update in April, and the Fall Creators Update in October. System requirements To upgrade your Windows 7 or 8.1 machine to Windows 10, you will need to meet system hardware requirements. Remember that these are just the minimum
b. Click Boot Menu in the right bottom corner or Press F c. Select your bootable flash drive then press enter key. How do I know if I have UEFI or BIOS Setup?
Press Win + R > type msinfo32 and press Enter. Look for the BIOS Mode entry. If the value listed is Legacy, then the Boot Environment is BIOS, otherwise the respective Boot Environment will be listed.
After a few moments. A “Press any key to boot from USB…” phrase will appear then press any key.
- On windows setup click next to begin. Note: If you are using UEFI boot “Press any key to boot from USB…” is not necessarily.
- (If applicable) Select the edition of Windows 10. This selection must match the edition your product key activates.
- Click the Next button.
- Select the I accept the license terms to agree option to continue.
- Click the Next button. Click on the Custom: Install Windows only (Advanced) option.
- Select the partition with the current installation of Windows (usually "Drive 0") and click the Delete button to remove it from the hard drive. Partition size requirements. If you are installing the 32-bit version of Windows 10 you will need at least 16GB, while the 64-bit version will require 20GB of free space. Quick Tip: If you have multiple partitions, on the primary hard drive (Drive 0), you can select and delete each of the partitions to allow the setup to use the entire drive for the installation. Windows 10 will create the required partitions automatically during the installation. If you have multiple hard drives, you don't need to delete those partitions. Why do we need partitions? Partitioning a disk can make it easier to organize files, such as video and photo libraries, especially if you have a large hard drive. Creating a separate partition for your system files (the startup disk) can also help protect system data from corruption since each partition has its own file system
3. Select your keyboard layout. Click the Yes button. 4. Click the Skip button, unless you need to add a second keyboard layout.
14 | P a g e
5. Click the Set up for personal use option. 6. Type your Microsoft account information. Quick Tip: If you don't want to use a Microsoft account, click the Offline account option at the bottom left corner to create a traditional local account.
11. Create your new four-digit PIN. (If you want to create a complex PIN, you can check the Include letters and symbols option.) 12. Click the OK button.
- (Optional) You can enter your phone number and then click the Send button to link your phone with your device, but this is a feature that you can set up some other time. If you want to skip this option (recommended), click the Do it later button in the bottom left corner of the screen.
- Click the Next button to set up OneDrive. If you're not interested in using this cloud storage service, click the Only save files to this PC option in the bottom left corner of the screen. 15.(Optional) Select the Let Cortana respond to "Hey Cortana" option.
- Click the Accept option to allow Cortana personalized your experience. (If you click the Decline button, Cortana will still be available on the taskbar, but it won't collect information about you.)
III. Accompanying DepEd Textbook and Educational Sites
1. Balana, Ismael Manic, Install and configure computer systems Learning Outcome 3 Windows 10 2. Computer Hope. “Windows 8”. October 24, 2020. https://www.microsoft.com/en-us/windows, Retrieved 3. AvoidErrors. 2015. “How to Install Windows10 from a USB Flash Drive”. August 1 2015. https://www.youtube.com/watch?v=SKbR6XT7fcA **IV. Activity Proper
- Exercises / Activities A. Watch YouTube Video (In your browser, type the URL given)
- Watch this YouTube video about Windows 10 Installation Process** bit.ly/win_10inst OPTIONAL ACTIVITY The following activity may be done if there are available resources at home. 1. You can practice reformatting your Desktop PC/ Laptop using the steps mentioned above. It is preferred to use a computer that is bound for reformat or to be used for this specific activity. WARNING: Do not perform windows installation on computers used for productivity as you may accidentally delete all files. B. Windows 10 OS Installation video observation
- Why is there a need to enter the “Product Key”? Why?
- What is the importance of having difficult “password”? C. Web search
- List down at least 5 the differences between Windows 7 and Windows 10.
- Is it okay to install applications downloaded from torrent sites? Why?
2. Guide Questions If you have performed the OPTIONAL ACTIVITY , here are some processing question for you. 1. What should you do after installing Windows? List them here. 3. Rubric for Scoring Needs Improvement 1Pt Approaching standards 2Pts Good 3Pts Excellent 4Pts Ideas and Content There is no clear or specific explanation in answer to the question. You put thought into this, but there is no real evidence of learning. More specific information is needed or you need to follow the directions more closely. What you are writing about is clear. You answered the question. Some support may be lacking, or your sentences may be a bit awkward. Overall, a decent job. What you are writing about is clear and well- expressed, including specific examples to demonstrate what you learned. Well done! Use of terms (^) No terms from the lesson are used. Only one term from the lesson is used in the answer. Try for a few more, next time. Your answer included several terms from the lesson, demonstrating adequate understanding of the material. Your answer included all the terms from the lesson that applied to the question asked. All terms are fully defined and used in the proper context. Sentence Fluency Sentences are incomplete or too long. It makes reading them difficult. Some sentences are complete and easy to understand. Others require some work. Sentences are complete and able to be understood. Sentences are complete and they connect to one another easily when they are read out loud. Your writing 'flows.' Conventions Few end marks or capital letters. Answers contain numerous spelling or structural errors. Mistakes using end marks or capitals as well as spelling mistakes make the writing hard to read. Use of punctuation marks and capitals, as well as spelling, is mostly correct. Few errors exist in your answer. No punctuation or structural mistakes. No spelling errors. Your writing shows full
