Computer Networks

Chapter 2: Protocols and the

TCP/IP Protocol Suite

Protocols

• Cooperative action is necessary — computer networking is not only to exchange bytes — huge system with several utilities and functions. For examples - error detection - Encryption - Routing - etc.
• For proper communication, entities in different systems must speak the same language — there must be mutually acceptable conventions and rules about the content, timing and underlying mechanisms
• Those conventions and associated rules are referred as “PROTOCOLS”

A Real World Example to Protocol Architecture philosopher-translator-secretary architecture Issues:

• peer-to-peer protocols are independent of each other —for example, secretaries may change the comm. medium to email —or the translators may agree on using another common language
• Each layer adds a header

Simplified File Transfer

Architecture

File Transfer Application Layer: Application specific commands, passwords and the actual file(s) – high level data Communications Service Module: reliable transfer of those data – error detection, ordered delivery of data packets, etc. Network Module: actual transfer of data and dealing with the network – if the network changes, only this module is affected, not the whole system

A General Three Layer Model

• Generalize the previous example for a generic application — we can have different applications (e-mail, file transfer, …)
• Network Access Layer
• Transport Layer
• Application Layer

Network Access Layer

• Exchange of data between the computer and the network
• Sending computer provides address of destination — so that network can route
• Different switching and networking techniques — Circuit switching — Packet switching — LANs — etc.
• This layer may need specific drivers and interface equipment depending on type of network used.
• But upper layers do not see these details — independence property

Application Layer

• Support for different user applications

• e.g. e-mail, file transfer

Addressing Requirements

• Two levels of addressing required

• Each computer needs unique network address

• Each application on a (multi-tasking) computer

needs a unique address within the computer

— The service access point or SAP

— The port number in TCP/IP protocol stack

Protocol Data Units (PDU)

• User data is passed from layer to layer

• Control information is added/removed to/from

user data at each layer

—Header (and sometimes trailer) —each layer has a different header/trailer

• Data + header + trailer = PDU (Protocol Data

Unit)

—This is basically what we call packet

—each layer has a different PDU

Transport PDU

• Transport layer may fragment user data

• Each fragment has a transport header added

—Destination port —Sequence number

• since the transport layer may split application data into smaller packets —Error detection code (generally at trailer)

Operation of a Protocol

Architecture

Transport Header Network Header Network Header Transport Header (Network PDU)

Standard Protocol

Architectures

• Common set of conventions

• Nonstandard vs. standard protocols

—Nonstandard: K sources and L receivers lead to K*L different protocols —If common protocol used, we design only once

• Products from different vendors interoperate

—Customers do not stick to a specific vendor —If a common standard is not implemented in a product, then that product’s market is limited; customers like standard products

OSI Reference Model

• Open Systems Interconnection (OSI)

• Reference model

—provides a general framework for standardization —defines a set of layers and services provided by each layer —one or more protocols can be developed for each layer

• Developed by the International Organization for

Standardization (ISO)

—also published by ITU-T (International Telecommunications Union)

OSI Reference Model

• A layered model

—Seven layers – seven has been presented as the optimal number of layer

• Delivered too late (published in 1984)!

—by that time TCP/IP started to become the de facto standard

• Although no OSI-based protocol survived, the

model is still valid (in the textbooks)

—For Data Link Layer (that we will see later) OSI protocols are still valid
