Reconstruction

“It All Adds Up” Puzzle

www.education-world.com/a_lesson/italladdsup

This is what your CT Scanner must

solve!

Reconstruction:

Solve for m’s

m 11 m 12 m 13 m 14

m 21 m 22 m 23 m 24

m 31 m 32 m 33 m 34

m 41 m 42 m 43 m 44

Real Reconstruction Problem

Intensity (transmission) measured  Rays transmitted through multiple pixels  Find individual pixel values (question marks) from transmission data

 Raw DataIntensity

(transmission)

measurements^534

Algorithm

 Set of rules for getting a specific output (answer) from

a specific input

 Reconstruction algorithm examples

 Fourier Transform  Interpolation  Convolution (filtered back projection)

Fourier Transform

 converts data from spatial domain to frequency

domain

 breaks any signal into frequency component parts

C-major chord consists of C, E, & G notes

Fourier Transform

 Sin(x) + 1/3Sin(3x)

-1.

-1.

-0.

0.000 5.000 10.000 15.000 20.

Fourier Transform

 Sin(x) + 1/3 Sin (3x) + 1/5 sin (5x)

-1.

-0.

-0.

-0.

-0.

0.000 5.000 10.000 15.000 20.

Fourier Transform Reconstruction

 Each set of projection data transformed to its

frequency domain

 combinations of sines & cosines at various frequencies

 Frequency domain image created

 Frequency domain image transformed back to spatial

domain

 inverse Fourier Transform

Frequency Domain Image

Lends itself to computer calculation

Easily manipulated (filtered)

 edge enhancement

 emphasize higher frequencies

 smoothing

 de-emphasize higher frequencies

Provides image quality data directly

Back Projection Reconstruction

 Back Projection

 for given projection, assume equal attenuation for each pixel  repeat for each projection adding results

Back Projection Reconstruction

 Assume actual image has 1 hot spot

(attenuator)

 Each ray passing through spot will have

attenuation back-projected along entire

line

 Each ray missing spot will have 0’s back-

projected along entire line

Hot Spot
