CSE 543 - Computer Security
(Fall 2006)
Lecture 16 - Network Security
October 31, 2006
URL: http://www.cse.psu.edu/~tjaeger/cse543-f
Midterm
Grades
85-100 -- A (4)
76-81 -- B+/A- (8)
66-73 -- B+/B (14)
59-63 -- B/B- (4)
53-56 -- C (2)
45-50 -- D (5)
Impact
15% of grade (less than presentations and homeworks)
Much less than project; much less than final
Need over 50% on one test to get B-
Question 20
Given a trusted authority, use public key crypto to
send a key to another party
Just what X needs to send
X is sender; Y is receiver; M is authority
Y needs X’s public key: X+, X, {H(X+, X)}M-
X needs to ensure authenticity, secrecy, and integrity of key
{K, X, {H(K, X)}X-}Y+
How about with a secret group key
Need authenticity, secrecy, and integrity
{K, X}Kg, HMAC(Kg, {K, X})
Project Meetings
Meet with groups
Discuss experiment
Try to propose experiment
Th, Fr, M
Will send an email to schedule
Project slides are not due until 11/
Network security: the high bits
The network is …
… a collection of interconnected computers
… with resources that must be protected
… from unwanted inspection or modification
… while maintaining adequate quality of service.
Another way of seeing network security is
Securing the network infrastructure such that the integrity,
confidentiality, and availability of the resources is
maintained.
Q: How do we do this?
The network …
Internet
LAN
(perimeter)
(hosts/desktops)
(edge)
(server) (remote hosts/servers)
Network security – the tools …
Filtering
Firewalls
Communication Security and Services
DNSsec, IPsec, SSH, ...
Isolation
VPNs, VLANs
Detection and mitigation
intrusion detection
DDOS tools
Filtering: the threats
- Adversary 1: some external
network entity attempting to gain access to
internal resources
- Adversary 2: some internal, but malicious entity
(or software) trying to expose sensitive data
- Adversary 3: some internal or external entity that
is preventing access to internal resource (DOS)
Firewall Policy
Specifies what traffic is (not) allowed
Maps attributes to address and ports
Example: HTTP should be allowed to any external host, but inbound
only to web-server
xListing
- Blacklisting - specifying specific connectivity that is
explicitly disallowed
E.g., prevent connections from badguys.com
- Whitelisting - specifying specific connectivity that
explicitly allowed
E.g., allow connections from goodguys.com
These is useful for IP filtering, SPAM mitigation, …
Q: What access control policies do these represent?
DMZ (De-militarized Zone)
(servers)
LAN
Internet
LAN
Practical Issues and Limitations
Network layer firewalls are dominant
DMZs allow multi-tiered fire-walling
Tools are widely available and mature
Personal firewalls gaining popularity
Issues
Network perimeters not quite as clear as before
E.g., telecommuters, VPNs, wireless, …
Every access point must be protected
E.g., this is why war-dialing is effective
Hard to debug, maintain consistency and correctness
Often seen by non-security personnel as impediment
E.g., Just open port X so I can use my wonder widget …
SOAP - why is this protocol an issue?
Interesting tid-bits from the Wool study
12 error classes
No default policy, automatic broad tools
NetBIOS (the very use of the Win protocol deemed error)
Portmapper protocols
Use of “any wildcards”
Lack of egress rules
Interesting questions:
Is the violation of Wool’s errors really a problem?
“DNS attack” comment?
Why do you think more expensive firewalls had a higher
occurrence of errors?
Take away: configurations are bad
