CSE543 Computer (and Network) Security - Fall 2007 - Professor Jaeger

CSE 543 - Computer Security

Lecture 13 - Capability Systems

October 9, 2007

URL: http://www.cse.psu.edu/~tjaeger/cse543-f07/ 1

Process-specific Permissions

• Design the permissions of a process specific to its use
• How do we change the permissions of a process in an ACL system?

Capabilities

• A capability is the tuple (object, rights)
• A capability system implements access control by checking if the process has an appropriate capability - Simple, right? - This is a little like a ticket in the Kerberos system
• Q: Does this eliminate the need for authentication?

Capabilities

• A: Well, yes and no …
• Capabilities remove the overhead of managing per object rights, but add the overhead of managing capabilities
• Moreover, to get any real security, they have to be unforgeable - Hardware tags (to protect capabilities) - Protected address space/registers - Language based techniques - Enforce access restrictions on caps. - Cryptography - Make them unforgeable

User space capability?

• Well, what are the requirements?
  • Authenticity/integrity - do not want malicious process to forge capabilities
• Start with the data itself: [object, rights]
  • Object is typically encoded with identifier, or by some other tag (capabilities are sometimes known as tags)
  • Rights are often fixed (read, modify, write, execute, etc.)
• Now, do what you with any other data (assume the kernel has a secret key k) E(k, [O i , r 1 , r 2 , … r n

])

• What’s wrong with this construction (I got it from the website of one of the experts in the area)?

The right construction

• Encryption does not provide authenticity/integrity, it provides confidentiality [O i , r 1 , r 2 , … r n ],HMAC(k, [O i , r 1 , r 2 , … r n

])

• So how would you attack the preceding construction?

Procedure-Level Protection Domains

• HYDRA
  • Each procedure defines a new protection domain
• Procedure
  • Code
  • Data
  • Capabilities to other objects
    • Caller-independent
    • Caller-dependent templates
• Local Name Space
  • Capabilities are bound here
  • Record of a procedure invocation (procedure instance)
• Process
  • Stack of LNSs

How HYDRA works

• Q: Which object defines the protection domain? Caller LNS Callee LNS Kernel Call Callee

• Capabilities Create Callee LNS Caller Proc Callee Proc Capabilities Capabilities Data Data Template Template Caller-Dep Capabilities Caller-Dep Capabilities

Linden’s Capability View

• Achieve flexible, effective security by
  • Small protection domains
  • Extensible set of types
• Implies a capability system
  • Small protection domains with least privilege permissions
  • Extensible types enable composition of systems reliably
  • Capabilities can be passed among protection domains and into new subsystems
• Protected Procedures
  • Like HYDRA
  • Change domain with each procedure invocation
  • New procedure is a new instance
• Protection Domain switch time is key (high in modern processors)

Correctness Claim

• “It is far more difficult to build a 50,000 line program than 1,000 programs that are each 50 lines long.” - What is your opinion of this? - Is it just the procedure development that is important?
• Two problems
  • Decomposition results in inefficiencies
  • Interactions between procedures are not captured

Secure Capability Systems

• SCAP
  • Karger’s extension of the Cambridge CAP system
• EROS
  • Shapiro’s reimplementation of the KeyKOS system

Capabilities and the *-Property

• Capabilities and Lattice Models Don’t Mix
• Suppose A is higher secrecy than B
  • A can read B’s capabilities
• Q: Can a Trojan horse running as A write to Obj? B’s capabilities Read-Write Obj

EROS *-security

• Define weak capabilities
  • If a weak capability is used to fetch a capability (transitively), then the fetched capability becomes read- only and weak
• Assign weak capabilities to higher-secrecy subjects for accessing a lower-secrecy write capability - becomes read-only and weak
• No need to test against a policy at runtime
  • Faster performance is possible
• For general confinement use an confined processes or authorized capability sets - Not clear these really worked for general confinement

Capability Management

• How’d you get those capabilities?
  • Stored with program, user
  • Compare with getting permissions by a process label
• How do I get them back?
  • Once granted, nearly impossible to revoke
