Parallel Algorithm & Sorting in Parallel

Programming

Contents:

1.1 Parallel algorithm

1.2 A Network for sorting

1.3 Sorting on a linear array

1.4 Sorting on the CRCW Model

1.5 Sorting on the CREW Model

1.6 Sorting on the EREW Model

Parallel Sorting:-



The fundamental operation of comparison-

based sorting is compare-exchange.



The lower bound on any comparison-based

sort of n numbers is Θ (nn log n).



The sorted list is partitioned with the

property that each partitioned list is sorted

and each element in processor P

i

's list is less

than that in P

j

's list if i < j

Sorting: Parallel Compare Exchange Operation

A parallel compare-exchange operation. Processes P

i

and P

j

send their elements to each other. Process P

i

keeps min{a

i

,a

j

}, and P

j

keeps max{a

i

, a

j

Cont…



Average optimal sequential complexity: O(n log n)



Parallel efficiency limitations



Partitions are unbalanced



A single processor performs the initial

partitioning

Example of quicksort



Let S = (6,5 ,9,2,4,3,5 , 1, 7,5,8 ).

T he first call to procedure Q U I C K S O R T

produces 5 as the median element of S, and hence

S1 = {2,4,3,1,5,5} and

S2 = {6,9,7,8,5}.

Note that S1 = 6 and S2= 5. A recursive call to Q U I

C K S O R T with S, as input produces the two

subsequences {2,1,3} and {4,5,5}. The second call

with S, as input produces {6,5,7}an d {9,8}. Further

recursive calls complete the sorting of these

sequences.

COMPLEXITY OF QUICKSORT

For some constant c, we can express the running

time of procedure

QUICKSORT as

= O(n log n),

1.2 A NETWORK FOR SORTING



It is rather straightforward to use a collection of

merging networks



to build a sorting network for the sequence S = {s1,

s2,... , sn), where n is a power of 2. The idea is the

following.



In a first stage, a rank of n/2 comparators is used to

create n/2 sorted sequences each of length 2.



In a second stage, pairs of these are now merged into

sorted sequences of length 4 using a rank of (2,2)-

merging networks. Again, in a

FI G : ODD EVEN SORTI NG NE TWO RK FO R SEQ UENCE OF EI GHT E LEM ENTS

The odd-even sorting network is impractical for large input

sequences :

(i) The network is extremely fast. It can sort a sequence of

length 2^20 within, on the order of, (20)2 time units.

This is to be contrasted with the time required by

procedure QUICKSORT, which would be in excess of

20 million time units.[(log n)^2]

(ii) The number of comparators is too high. Again for n =

2^20, the network would need on the order of 400 million

comparators.[n (log n)^2]

(iii) The architecture is highly irregular and the wires linking

the comparators have lengths that vary with n.

Odd-Even Transposition Sort



Variation of bubble sort.



Operates in two alternating phases, even phase

and odd phase.



Even phase

Even-numbered processes exchange numbers

with their right neighbour.



Odd phase

Odd-numbered processes exchange numbers with

their right neighbour.



Odd-Even Transposition Sort -

example

Parallel time complexity: T

par

= O( n ) (for P=n)

MERGE SPLIT:-

Now consider the second approach. If N processors,

where N < n,

Assume that each of the N processors in the linear array

holds a subsequence of S of length n/N.

The comparison-exchange operations of procedure

ODD-EVEN TRANSPOSITION are now replaced with

merge-split operations on subsequences.

Let Si denote the subsequence held by processor Pi.

Initially, the Si are random subsequences of S.

Sorting sequence of twelve elements using procedure

MERGE SPILIT:-
