Introduction 1Lecture 1 Architectural Structures F2012abn

ARCHITECTURAL STRUCTURES: FORM, BEHAVIOR, AND DESIGN

one

structural behavior

and design

lecture

www.greatbuildings.com

Introduction 2 Lecture 1

Syllabus & Student Understandings

Introduction 4 Lecture 1

Course Description

• mechanics of materials
  • external loads and effect on deformable bodies
  • use it to answer question if structure meets requirements of - stability and equilibrium - strength and stiffness
  • other principle building requirements
    • economy, functionality and aesthetics

Introduction 5 Lecture 1

Structure Requirements

• stability & equilibrium - STATICS

Introduction 7Lecture 1

Structural System Selection

• kind & size of loads
• building function
• soil & topology of site
• systems integration
• fire rating
• construction ($$, schedule)
• architectural form

Introduction 8Lecture 1

Knowledge Required

• external forces
• internal forces
• material properties
• member cross sections
• ability of a material to resist breaking
• structural elements that resist excessive
  • deflection
  • deformation

Introduction 10Lecture 1

Relation to Architecture

“The geometry and arrangement of the load-bearing members, the use of materials, and the crafting of joints all represent opportunities for buildings to express themselves. The best buildings are not designed by architects who after resolving the formal and spatial issues, simply ask the structural engineer to make sure it doesn’t fall down.” - Onouye & Kane Statics and Strength of Materials for Architecture and Building Construction

Introduction 11Lecture 1

• evolution traced to developments in structural engineering and material technology
• stone & masonry
• timber
• concrete
• cast iron, steel
• tensile fabrics, pneumatic structures......

Architectural Space and Form

Introduction 13Lecture 1

Stone + Masonry

• columns
• walls
• lintels
• beams
• arches
• footings

Introduction 14Lecture 1

Wood

• columns
• beams
• trusses

Introduction 16 Lecture 1

Concrete

• columns
• beams
• slabs
• domes
• footings

http:// nisee.berkeley.edu/godden

Introduction 17Lecture 1

Structural Action

• axial tension
• axial compression
  • bending

Introduction 19 Lecture 1

Structural Action

• stabilization

Introduction 20Lecture 1

Structural Action

• shear & bracing
