two
structural systems,
planning and design
Systems & Planning 1 Lecture 2
Architectural Structures
ARCHITECTURAL STRUCTURES:
FORM, BEHAVIOR, AND DESIGN
lecture
AISC teaching aids: Courtesy of John Hooper, MKA Seattle
Project
Systems & Planning 2 Lecture 2
Architectural Structures
Systems & Planning 4 Lecture 2
Architectural Structures
Structural Components
- bearing walls
- columns
- beams
- flat plates
- trusses
- arches
- shells
- cables
Systems & Planning 5 Lecture 2
Architectural Structures
Bearing Walls
Systems & Planning 7 Lecture 2
Architectural Structures
Columns & Walls
Systems & Planning 8 Lecture 2
Architectural Structures
Beams & Plates
Systems & Planning 10 Lecture 2
Architectural Structures
Trusses and Shells
Systems & Planning 11 Lecture 2
Arches and Cables
Systems & Planning 14 Lecture 2
Architectural Structures
System Selection
- evaluation of alternatives
Systems & Planning 16 Lecture 2
Architectural Structures
Structural Design Criteria
- components stay together
- structure acts as whole to be stable
- resist sliding
- resist overturning
- resist twisting and distortion
- internal stability
- interconnectedness
- strength & stiffness
Systems & Planning 18 Lecture 2
Architectural Structures
Systems by Materials
- Wood
- Steel
- Concrete
- Masonry
- Composite
Systems & Planning 19 Lecture 2
- all-wood framing systems
- studs, beams, floor
diaphragms, shearwalls
- glulam arches & frames
- post & beams
- trusses
- composite construction
- masonry shear walls
- concrete
- steel
Timber Construction
Systems & Planning 21 Lecture 2
Timber Construction
- glulam arches & frames
- manufactured or custom shapes
- glue laminated
- bigger members
Systems & Planning 22 Lecture 2
Timber Construction
- post & beam
- trusses
