Computer Architecture

Lecture 32: Heterogeneous Systems

Prof. Onur Mutlu Carnegie Mellon University Spring 2014, 4/20/ 2015

Where We Are in Lecture Schedule

 The memory hierarchy  Caches, caches, more caches  Virtualizing the memory hierarchy: Virtual Memory  Main memory: DRAM  Main memory control, scheduling  Memory latency tolerance techniques  Non-volatile memory  Multiprocessors  Coherence and consistency  In-memory computation and predictable performance  Multi-core issues (e.g., heterogeneous multi-core)  Interconnection networks

Midterm II and Midterm II Review

 Midterm II is this Friday (April 24, 2015)  12:30-2:30pm, CIC Panther Hollow Room ( th floor)  Please arrive 5 minutes early and sit with 1-seat separation  Same rules as Midterm I except you get to have 2 cheat sheets  Covers all topics we have examined so far, with more focus on Lectures 17-32 (Memory Hierarchy and Multiprocessors)  Midterm II Review is Wednesday (April 22)  Come prepared with questions on concepts and lectures  Detailed homework and exam questions and solutions  study on your own and ask TAs during office hours

Suggestions for Midterm II

 Solve past midterms (and finals) on your own…  And, check your solutions vs. the online solutions  Questions will be similar in spirit  http://www.ece.cmu.edu/~ece447/s15/doku.php?id=exams  Do Homework 7 and go over past homeworks.  Study and internalize the lecture material well.  Buzzwords can help you. Ditto for slides and videos.  Understand how to solve all homework & exam questions.  Study hard.  Also read: https://piazza.com/class/i3540xiz8ku40a?cid= 335

Reminder on Collaboration on 447 Labs

 Reminder of 447 policy:  Absolutely no form of collaboration allowed  No discussions, no code sharing, no code reviews with fellow students, no brainstorming, …  All labs and all portions of each lab has to be your own work  Just focus on doing the lab yourself, alone

We Have Another Course for Collaboration

 740 is the next course in sequence  Tentative Time: Lect. MW 7:30-9:20pm, (Rect. T 7:30pm)  Content:  Lectures: More advanced, with a different perspective  Recitations: Delving deeper into papers, advanced topics  Readings: Many fundamental and research readings; will do many reviews  Project: More open ended research project. Proposal  milestones  final poster and presentation  Done in groups of 1- 3  Focus of the course is the project (and papers)  Exams: lighter and fewer  Homeworks: None

Lab 6 Grade Distribution

Lab 6 Extra Credit Recognitions

 Stay tuned…

Where We Are in Lecture Schedule

 The memory hierarchy  Caches, caches, more caches  Virtualizing the memory hierarchy: Virtual Memory  Main memory: DRAM  Main memory control, scheduling  Memory latency tolerance techniques  Non-volatile memory  Multiprocessors  Coherence and consistency  In-memory computation and predictable performance  Multi-core issues (e.g., heterogeneous multi-core)  Interconnection networks

Today

 Heterogeneity (asymmetry) in system design  Evolution of multi-core systems  Handling serial and parallel bottlenecks better  Heterogeneous multi-core systems

Heterogeneity (Asymmetry)  Specialization

 Heterogeneity and asymmetry have the same meaning  Contrast with homogeneity and symmetry  Heterogeneity is a very general system design concept (and

life concept, as well)

 Idea: Instead of having multiple instances of the same “resource” to be the same (i.e., homogeneous or symmetric), design some instances to be different (i.e., heterogeneous or asymmetric)  Different instances can be optimized to be more efficient in executing different types of workloads or satisfying different requirements/goals  Heterogeneity enables specialization/customization

Why Asymmetry in Design? (I)

 Different workloads executing in a system can have different behavior  Different applications can have different behavior  Different execution phases of an application can have different behavior  The same application executing at different times can have different behavior (due to input set changes and dynamic events)  E.g., locality, predictability of branches, instruction-level parallelism, data dependencies, serial fraction, bottlenecks in parallel portion, interference characteristics, …  Systems are designed to satisfy different metrics at the same time  There is almost never a single goal in design, depending on design point  E.g., Performance, energy efficiency, fairness, predictability, reliability, availability, cost, memory capacity, latency, bandwidth, …

Asymmetry Enables Customization

 Symmetric: One size fits all  Energy and performance suboptimal for different “workload” behaviors  Asymmetric: Enables customization and adaptation  Processing requirements vary across workloads (applications and phases)  Execute code on best-fit resources (minimal energy, adequate perf.) C4 C C5 C C4 C C5 C C C C Asymmetric C C C C C C C C C C C C C C C C Symmetric

We Have Already Seen Examples Before (in 447)  CRAY-1 design: scalar + vector pipelines  Modern processors: scalar instructions + SIMD extensions  Decoupled Access Execute: access + execute processors  Thread Cluster Memory Scheduling: different memory scheduling policies for different thread clusters  RAIDR: Heterogeneous refresh rate  Hybrid memory systems  DRAM + Phase Change Memory  Fast, Costly DRAM + Slow, Cheap DRAM  Reliable, Costly DRAM + Unreliable, Cheap DRAM  …
