CSE 543 - Computer Security

Lecture 11 - Access Control

October 10, 2006

URL: http://www.cse.psu.edu/~tjaeger/cse543-f06/

Access Control System

• Protection Domain
  • What can be accessed by a process
    • Default access: memory
    • Mediated access: E.g., files
• Access Control Enforcement
  • Mediates Access
    • Reference Monitor
  • Processes a Query
    • Can Subject S perform Operation OP on Object OBJ?
• What should the answer to the query be?

In class exercise …

• Find a partner: pick an interviewer and a responder, do 5 minute interview asking them what, with whom, and what they do with personal information they share with third parities. - Example: what do you share with phone telemarketers, departmental secretaries, the university, your advisor, your significant other, … - Don’t be exhaustive about all the information, but definitely identify the broad classes of information you share (sensitive, highly sensitive, etc) .. do the same for the entities you share with. - What are you allowing them to do with this information: e.g., share, alter, record, unknown? - Discuss and formulate a subject, object matrix for each right defined by this process. The interviewer should lead the process, I.e., the responder answers questions only.

Access Policy Goals

• Rights assignment is the process of describing a security goal
• “ Principle of least privilege ”
  • You should provide the minimal set or rights necessary to perform the needed function
  • Implication 1 : you want to reduce the protection domain to the smallest possible set of objects
  • Implication 2 : you want to assign the minimal set of rights to each subject
  • Caveat : of course, you need to provide enough rights and a large enough protection domain to get the job done.
• What other kinds of policy goals are there?

Access Control Model

• What language should I use to express policy?
  • Access Control Model
• Oodles of these
  • Some specialize in secrecy
    • Bell-LaPadula
  • Some specialize in integrity
    • Clark-Wilson
  • Some focus on jobs
    • RBAC
  • Some specialize in least privilege
    • SELinux Type Enforcement
• Q: Why are there so many different models?

Groups

• Groups are collections of identities who are assigned rights as a collective
• Important in that it allows permissions to be assigned in aggregates of users …
• This is really about membership
• Standard DAC
• Permissions are transient Alice Bob Trent Ivan Group Users^ Permissions

• A role is a collection of privileges/permissions associated with some function or affiliation
• NIST studied the way permissions are assigned and used in the real world, and this is it …
• Important: the permissions are static, the user-role membership is transient
• This is not standard DAC Role Read Delete Modify Write Role Users^ Permissions

RBAC

• Role based access control is a class of access control not direct MAC and DAC, but may one or either of these. - A lot of literature deals with RBAC models - Most formulations are of the type - U : users -- these are the subjects in the system - R : roles -- these are the different roles users may assume - P : permissions --- these are the rights which can be assumed - There is a many-to-many relation between: - Users and roles - Roles and permissions - Relations define the role-based access control policy

Multilevel Security

• A multi-level security system tags all object and subject with security tags classifying them in terms of sensitivity/access level. - We formulate an access control policy based on these levels - We can also add other dimensions, called categories which horizontally partition the rights space (in a way similar to that as was done by roles) security levels categories

Lattice Model

• Used by the US military (and many others), the Lattice model uses MLS to define policy
• Levels: unclassified < confidential < secret < top secret
• Categories (actually unbounded set) NUC(lear), INTEL(igence), CRYPTO(graphy)
• Note that these levels are used for physical documents in the US government as well.

Evaluating Policy Access is allowed if subject clearance level >= object sensitivity level and object categories ⊇ subject categories ( read down ) Q: What would write-up be? Hence, Bob: CONF., {INTEL}) Charlie: TS, {CRYPTO, NUC, INTEL}) Alice: (SEC., {CRYTPO, NUC}) DocA: (CONFIDENTIAL, {INTEL}) DocB: (SECRET, {CRYPTO}) DocC: (UNCLASSIFIED , {NUC})

How about integrity?

• Biba defined a dual of secrecy for integrity
  • Lattice policy with
    • No read down
    • No write up
  • Q: Why would this work?
• The lattice model for secrecy matched the paper world, does this integrity model? - Consider an Oracle
• What is a realistic view of integrity?

Clark-Wilson Integrity Model

• Associate Code with Objects
  • For each TP a list of CDIs that it can access
• Associate Users with TPs and Objects
  • For each user, she can access some CDIs using some TPs
• What are the subjects and objects? What happened to operations?
• Result
  • The rights of a user are “constrained” by the rights of the TP
  • Further, we are restricted by “separation of duty”
    • more later

Clark-Wilson Issues

• Correct Function
  • Certify IVPs, TPs to be ‘valid’ (i.e., correct) (C1,C2)
  • Such certification is impossible in general (Halting Problem)
• Is there a general way of defining correctness?
• Handle Low Integrity Data
  • A TP must upgrade or discard any UDI (low integrity data) it receives (C5)
• What modern problems are instances of this?
