3YSTEMS AND )NTERNET
)NFRASTRUCTURE 3ECURITY
I I .ETWORK AND 3ECURITY 2ESEARCH #ENTER $EPARTMENT OF #OMPUTER 3CIENCE AND %NGINEERING 0ENNSYLVANIA 3TATE 5NIVERSITY 5NIVERSITY 0ARK 0! CSE543 - Introduction to Computer and Network Security Module:Access Control Professor Patrick McDaniel Fall 2009 1
Trusted Computing Base (TCB)
- (^) The trusted computing base is the infrastructure that you assume will behave correctly ‣ Hardware (keyboard, monitor, …) ‣ Operating Systems ‣ Implementations ‣ Local networks ‣ Administrators ‣ Other users on the same system
- (^) Axiom: the larger the TCB, the more assumptions you must make (and hence, the more opportunity to have your assumptions violated). 2
Computer Security Policy Goals
- (^) Secrecy ‣ (^) Don’t allow reading by unauthorized subjects ‣ Control where data can be written by authorized subjects - (^) Why is this important?
- (^) Integrity ‣ (^) Don’t permit dependence on lower integrity data/code - (^) Why is this important? ‣ What is “dependence”?
- (^) Availability ‣ The necessary function must run ‣ Doesn’t this conflict with above? 4
… when policy goes wrong
- (^) Driving license test: take until you pass ‣ Mrs. Miriam Hargrave of Yorkshire, UK failed her driving
test 39 times between 1962 and 1970!!!!
‣ … she had 212 driving lessons …. ‣ (^) She finally got it on the 40th try. ‣ Some years later, she was quoted as saying, “sometimes I still have trouble turning right ” 5 “A policy is a set of acceptable behaviors.”
Access Policy Enforcement
- (^) A protection state defines what each subject can do ‣ E.g., in an access bits --- the policy
- (^) A reference monitor enforces the protection state ‣ A service that responds to the query...
- (^) A correct reference monitor implementation meets the following guarantees ‣ Tamperproof ‣ Complete Mediation ‣ Simple enough to verify
- (^) A protection system consists of a protection state, operations to modify that state, and a reference monitor to enforce that state 7
Access Control/Authorization
- (^) An access control system determines what rights a particular entity has for a set of objects
- (^) It answers the question ‣ E.g., do you have the right to read /etc/passwd ‣ (^) Does Alice have the right to view the EECS website? ‣ Do students have the right to share project data? ‣ (^) Does Dr. McDaniel have the right to change your grades?
- (^) An Access Control Policy answers these questions 8
The Access Matrix
- (^) An access matrix is one way to
represent policy.
‣ (^) Frequently used mechanism for describing policy
- (^) Columns are objects, subjects are
rows.
‣ To determine if Si has right to access object O j , find the appropriate entry. ‣ There is a matrix for each right.
- (^) The access matrix is a succinct
descriptor for O(|S|*|O|) rules
O
1
O
2
O
3 S 1 Y^ Y^ N S 2 N^ Y^ N S 3 N^ Y^ Y 10
Access Control
- (^) Suppose the private key file for J is object O 1 ‣ Only J can read
- Suppose the public key file for J is object O 2 ‣ (^) All can read, only J can modify
- (^) Suppose all can read and write from object O 3
- (^) What’s the access matrix? O 1 O 2 O 3 J??? S 2?^?^? S 3?^?^? 11
Secrecy
- (^) Does the following protection state ensure the secrecy of J’s private key in O 1? O 1 O 2 O 3 J R RW RW S 2 N^ R^ RW S 3 N^ R^ RW 13
Integrity
- (^) Does the following access matrix protect the integrity of J’s public key file O 2? O 1 O 2 O 3 J R RW RW S 2 N^ R^ RW S 3 N^ R^ RW 14
Least Privilege
- (^) Limit permissions to those required and no more
- Consider three processes for user J ‣ Restrict privilege of the process J 1 to prevent leaks O 1 O 2 O 3 J 1 R R N J 2 N RW N J 3 N R RW 16
Access Control Administration There are two central ways to specify a policy
1. Discretionary - object “owners” define policy ‣ Users have discretion over who has access to what objects and when (trusted users) ‣ Canonical example, the UNIX filesystem - (^) RWX assigned by file owners 2. Mandatory - Environment enforces static policy ‣ Access control policy defined by environment, user has no control control over access control (untrusted users) ‣ Canonical example, process labeling - (^) System assigns labels for processes, objects, and a dominance calculus is used to evaluate rights 17
Administrative Operations
- (^) An access matrix defines a protection state
- (^) A protection system also includes a set of operations for modifying that state
- (^) Examples ‣ Add right (UNIX): If the user is the owner of the object, then the user can add an operation to set of operations of another user ‣ (^) Add right: If domain has the copy flag set for that right in its access matrix row, then it can add that right to any other domain’s access row 19
DAC vs. MAC in Access Matrix
- (^) Subjects: ‣ DAC: users ‣ MAC: labels
- (^) Objects: ‣ DAC: files, sockets, etc. ‣ MAC: labels
- (^) Operations: ‣ Same
- (^) Administration: ‣ DAC: owner, copy flag, ... ‣ MAC: external
- (^) MAC: largely static matrix; DAC: all can change
O
1
O
2
O
3 S 1 Y^ Y^ N S 2 N^ Y^ N S 3 N^ Y^ Y 20
