2
Addressing Modes
zRegister Direct
zmovff reg1, reg2
zImmediate Mode
zmovlw 0x15
zInherent Mode
zmovlw 0x20
zBit-Direct Addressing Mode
zBCF PORTB,3,A
zIndirect Mode
docsity.com
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Guidelines and tips
Prepare for your exams
Study with the several resources on Docsity
Earn points to download
Earn points by helping other students or get them with a premium plan
Addressing Modes-Embedded System Control-Lecture Slides, Slides of Embedded Control Systems
This lecture was delivered by Mr. Rohit Kohli at National Institute of Industrial Engineering for Embedded System Control course. It includes: Mitochondrial, Introns, Sarcolemma, Photoreceptors, Respiration, Mitochondrial, Mitochondrial, Oxidative, Heterogeneity, Organs
Typology: Slides
2011/2012
Uploaded on 07/26/2012
unknown user 🇮🇳
1 / 6
This page cannot be seen from the preview
Don't miss anything!
Related documents
Partial preview of the text
Download Addressing Modes-Embedded System Control-Lecture Slides and more Slides Embedded Control Systems in PDF only on Docsity!
Addressing Modes z
Register Direct z
movff reg1, reg
z
Immediate Mode z
movlw 0x
z
Inherent Mode z
movlw 0x
z
Bit-Direct Addressing Mode z
BCF PORTB,3,A
z
Indirect Mode
docsity.com
Indirect Addressing z
Three Indirect Registers FSRO, FSR1, andFSR2.
z
After placing the address of the data in one ofthe FSR registers, one needs to read from orwrite into one of the three registers that arenot physically implemented in order toactivate indirect addressing. These threeregisters are INDFO, INDF1, and INDF2.
docsity.com
Indirect Addressing (Cont) z
Each FSR register has an INDF register associated with it plus fouradditional register addresses 1. Do nothing to FSRn after an indirect access. This access is specified by using
the register INDFn (n = 0... 2).
- Auto-decrement FSRn after an indirect access (postdecrement). This access is specified by using the register POSTDECn (n = 0.. .2). 3. Auto-increment FSRn after an indirect access (postincrement). This access is specified by using the register POSTINCn (n = 0.. .2). 4. Auto-increment FSRn before an indirect access (preincrement). This access specified by using the register PREINCn (n = 0.. .2). 5. Use the value in the WREG register as an offset to FSRn. The signed value in WREG is added to the value in FSR to form an address before performingan indirect access. Neither the WREG nor the FSRn is modified after theaccess. This access is specified by using the register PLUSWn z movwf INDFO z movwf POSTDECO z movwf PREINCO z clrf PLUSWO docsity.com
Special Function Registers
docsity.com
