EECS 583 – Lecture 4 Regions, Predicated execution

University of Michigan January 15, 2003

• 1 -

Reading Material^ Y^

All these on the course webpage Y Useful reference^ »^ “HPL-PD Architecture Specification Version 1.0”, Kathail,Schlansker, Rau, HPL Technical Report, 1993. Y Material for the next lecture^ »^ “On Predicated Execution”, Park and Schlansker, HPL TechnicalReport, 1991.^ »^ “Effective Compiler Support for Predicated Execution using theHyperblock”, Mahlke, Lin, Chen, Hank, Bringmann, MICRO-25,1992.

• 3 -

Regions^ Y^

Region

: A collection of operations that are treated as a

single unit by the compiler^ »^ Examples

y^ Basic block y^ Procedure y^ Body of a loop » Properties y^ Connected subgraph of operations y^ Control flow is the key parameter that defines regions y^ Hierarchically organized

Y^ Problem^ »

Basic blocks are too small (3-5 operations)^ y^

Hard to extract sufficient parallelism

»^ Procedure control flow too complex for many compiler xforms^ y

Plus only parts of a procedure are important (90/10 rule)

• 4 -

Regions (2)^ Y^

Want^ »^ Intermediate sized regions with simple control flow^ »^ Bigger basic blocks would be ideal !!^ »^ Separate important code from less important^ »^ Optimize frequently executed code at the expense of the rest Y Solution^ »^ Define new region types that consist of multiple BBs^ »^ Profile information used in the identification^ »^ Sequential control flow (sorta)^ »^ Pretend the regions are basic blocks

• 6 -

Linearizing a Trace

10 (entry count) BB1 BB2 BB4 BB 80

20 (side exit) 10 (side exit) 80 90

20 (side entrance)10 (side entrance)

BB

90 (entry/ exit count)

BB

10 (exit count)

• 7 -

Intelligent Trace Layout for Icache Performance

BB1^ BB2 BB4 BB

Intraprocedural code placement Procedure positioning Procedure splitting

trace

BB3 BB

trace 2 trace 3 The rest Procedure view

Trace view

• 9 -

Trace Selection Algorithm^ i = 0;^ mark all BBs unvisited^ while

(there are unvisited nodes) do seed = unvisited BB with largest execution freq trace[i] += seed mark seed visited current = seed /* Grow trace forward */ while^ (1) do^ next = best_successor_of(current)^ if^ (next == 0) then

break

trace[i] += next mark next visited current = next endwhile /* Grow trace backward analogously */ i++ endwhile

• 10 -

Best Successor/Predecessor^ Y^

Node weight vs edge weight^ »^ edge more accurate Y THRESHOLD^ »^ controls off-trace probability^ »^ 60-70% found best Y Notes on this algorithm^ »^ BB only allowed in 1 trace^ »^ Cumulative probabilityignored^ »^ Min weight for seed to bechose (ie executed 100 times)

best_successor_of(BB)e = control flow edge with highest

probability leaving BBif (e is a backedge) then return 0endif if (probability(e) <= THRESHOLD) then return 0endif d = destination of eif (d is visited) then return 0endif return d endprocedure

• 12 -

Class Problem 2

Find the traces. Assume a threshold probability of 60%.

(^100) BB (^60) BB^

BB BB^

BB

BB

BB7 BB (^25 )

(^403515) 50

10 5

135 100 (^75100)

• 13 -

Traces are Nice, But …^ Y^

Treat trace as a big BB^ »^ Transform trace ignoring sideentrance/exits^ »^ Insert fixup code

y^ aka bookkeeping » Side entrance fixup is morepainful » Sometimes not possible sotransform not allowed

Y^ Solution^ »

Eliminate side entrances » The superblock

is born

BB

BB4 BB

BB

BB

BB

• 15 -

Tail Duplication^ Y^

To eliminate all side entrancesreplicate the “tail” portion ofthe trace^ »^ Identify first side entrance^ »^ Replicate all BB from thetarget to the bottom^ »^ Redirect all side entrances tothe duplicated BBs^ »^ Copy each BB only once^ »^ Max code expansion = 2x-1where x is the number of BBin the trace^ »^ Adjust profile information

BB

BB4 BB

BB

BB

BB

• 16 -

Superblock Formation

BB1 80 BB2 BB4 BB

BB4’^20 2.

BB2^80 BB4^10 BB5^ BB

BB

BB

BB

20 BB5’

28 BB6’^ 25.

• 18 -

Class Problem 3

BB

BB

49

10 10

41

BB

20 BB

100 80

Create the superblocks, trace threshold is 60%

BB1 20

80 BB

51

49 BB

41 BB

450

BB

• 19 -

Predicated Execution^ Y^

Hardware mechanism that allows operations to beconditionally executed Y Add an additional boolean source operand (predicate)^ »^ ADD r1, r2, r3 if p

y^ if (p1 is True), r1 = r2 + r3 y^ else if (p1 is False), do nothing (Add treated like a NOP) y^ p1 referred to as the guarding predicate y^ Predicated on True means always executed y^ Omitted predicated also means always executed

Y^ Provides compiler with an alternative to using branches toselectively execute operations^ »

If statements in the source » Realize with branches in the assembly code » Could also realize with conditional instructions » Or use a combination of both
