1

V.Siva Krishna

2 Chap. 1: Digital Logic Circuits

  • Logic Gates, • Boolean Algebra
  • Map Simplification, • Combinational Circuits
  • Filp-Flops, • Sequential Circuits Chap. 2: Digital Components
  • Integrated Circuits, • Decoders, • Multiplexers
  • Registers, • Shift Registers, • Binary Counters
  • Memory Unit Chap. 3: Data Representation
  • Data Types, • Complements
  • Fixed Point Representation
  • Floating Point Representation
  • Other Binary Codes, • Error Detection Codes

4 Chap. 6: Programming the Basic Computer

  • Machine Language, • Assembly Language
  • Assembler, • Program Loops
  • Programming Arithmetic and Logic Operations
  • Subroutines, • Input-Output Programming Chap. 7: Microprogrammed Control
  • Control Memory, • Sequencing Microinstructions
  • Microprogram Example, • Design of Control Unit
  • Microinstruction Format Chap. 8: Central Processing Unit
  • General Register Organization
  • Stack Organization, • Instruction Formats
  • Addressing Modes
  • Data Transfer and Manipulation
  • Program Control
  • Reduced Instruction Set Computer

5 Chap. 9: Pipeline and Vector Processing

  • Parallel Processing, • Pipelining
  • Arithmetic Pipeline, • Instruction Pipeline
  • RISC Pipeline, • Vector Processing Chap. 10: Computer Arithmetic
  • Arithmetic with Signed-2's Complement Numbers
  • Multiplication and Division Algorithms
  • Floating-Point Arithmetic Operations
  • Decimal Arithmetic Unit
  • Decimal Arithmetic Operations Chap. 11: Input-Output Organization
  • Peripheral Devices, • Input-Output Interface
  • Asynchronous Data Transfer, • Modes of Transfer
  • Priority Interrupt, • Direct Memory Access

7 SIMPLE DIGITAL SYSTEMS

  • (^) Combinational and sequential circuits (learned in Chapters 1 and 2) can be used to create simple digital systems.
  • (^) These are the low-level building blocks of a digital computer.
  • Simple digital systems are frequently characterized in terms of
    • (^) the registers they contain, and
    • (^) the operations that they perform.
  • (^) Typically,
    • (^) What operations are performed on the data in the registers
    • (^) What information is passed between registers Register Transfer &-operationsoperations

8 REGISTER TRANSFER AND MICROOPERATIONS

  • Register Transfer Language
  • Register Transfer
  • Bus and Memory Transfers
  • Arithmetic Microoperations
  • Logic Microoperations
  • Shift Microoperations
  • Arithmetic Logic Shift Unit Register Transfer &-operationsoperations

10 MICROOPERATION (2) An elementary operation performed (during one clock pulse), on the information stored in one or more registers R  f(R, R) f: shift, load, clear, increment, add, subtract, complement, and, or, xor, … ALU (f) Registers (R) 1 clock cycle Register Transfer &-operationsoperations Register Transfer Language

11 ORGANIZATION OF A DIGITAL SYSTEM

  • Set of registers and their functions
  • Microoperations set Set of allowable microoperations provided by the organization of the computer
  • Control signals that initiate the sequence of microoperations (to perform the functions)
  • (^) Definition of the (internal) organization of a computer Register Transfer &-operationsoperations Register Transfer Language

13 REGISTER TRANSFER LANGUAGE Register Transfer Language

  • (^) Rather than specifying a digital system in words, a specific notation is used, register transfer language
  • (^) For any function of the computer, the register transfer language can be used to describe the (sequence of) microoperations
  • (^) Register transfer language
    • A symbolic language
    • A convenient tool for describing the internal organization of digital computers
    • (^) Can also be used to facilitate the design process of digital systems. Register Transfer &-operationsoperations

14 DESIGNATION OF REGISTERS Register Transfer Language

  • (^) Registers are designated by capital letters, sometimes followed by numbers (e.g., A, R13, IR)
  • (^) Often the names indicate function:
    • MAR - memory address register
    • PC - program counter
    • (^) IR - instruction register
  • (^) Registers and their contents can be viewed and represented in various ways - A register can be viewed as a single entity: - (^) Registers may also be represented showing the bits of data they contain MAR Register Transfer &-operationsoperations

16 REGISTER TRANSFER Register Transfer

  • Copying the contents of one register to another is a register transfer
  • (^) A register transfer is indicated as R2  R
    • (^) In this case the contents of register R2 are copied (loaded) into register R
    • (^) A simultaneous transfer of all bits from the source R1 to the destination register R2, during one clock pulse
    • Note that this is a non-destructive; i.e. the contents of R1 are not altered by copying (loading) them to R Register Transfer &-operationsoperations

17 REGISTER TRANSFER Register Transfer

  • A register transfer such as R3  R Implies that the digital system has
    • (^) the data lines from the source register (R5) to the destination register (R3)
    • (^) Parallel load in the destination register (R3)
    • (^) Control lines to perform the action Register Transfer &-operationsoperations

19 HARDWARE IMPLEMENTATION OF CONTROLLED TRANSFERS Implementation of controlled transfer P: R2 R Block diagram Timing diagram Clock Register Transfer Transfer occurs here R R Control Circuit P^ Load n Clock Load t (^) t+

  • The same clock controls the circuits that generate the control function and the destination register
  • (^) Registers are assumed to use positive-operationsedge-operationstriggered flip-flops Register Transfer &-operationsoperations

20 SIMULTANEOUS OPERATIONS Register Transfer

  • (^) If two or more operations are to occur simultaneously, they are separated with commas P: R3  R5, MAR  IR
  • Here, if the control function P = 1, load the contents of R5 into R3, and at the same time (clock), load the contents of register IR into register MAR Register Transfer &-operationsoperations
