1

Computer Architecture

Dr Roninn Maxx Semester: 7

2

Dr.Chao Tan,

Carnegie Mellon University

4

Chap. 4: Register Transfer and Microoperations

**- Register Transfer Language, • Register Transfer

  • Bus and Memory Transfers
  • Arithmetic Microoperations
  • Logic Microoperations, • Shift Microoperations
  • Arithmetic Logic Shift Unit**

Chap. 5: Basic Computer Organization and Design

**- Instruction Codes, • Computer Registers

  • Computer Instructions, • Timing and Control
  • Instruction Cycle,
  • Memory Reference Instructions
  • Input** - Output and Interrupt **- Complete Computer Description
  • Design of Basic Computer
  • Design of Accumulator Logic**

5 Chap. 6: Programming the Basic Computer

**- Machine Language, • Assembly Language

  • Assembler, • Program Loops
  • Programming Arithmetic and Logic Operations
  • Subroutines, • Input** - Output Programming Chap. 7: Microprogrammed Control **- Control Memory, • Sequencing Microinstructions
  • Microprogram Example, • Design of Control Unit
  • Microinstruction Format** Chap. 8: Central Processing Unit **- General Register Organization
  • Stack Organization, • Instruction Formats
  • Addressing Modes
  • Data Transfer and Manipulation
  • Program Control
  • Reduced Instruction Set Computer**

7

Chap. 12: Memory Organization

**- Memory Hierarchy, • Main Memory

  • Auxiliary Memory. • Associative Memory
  • Cache Memory, • Virtual Memory**

Chap. 13: Multiprocessors ()

**- Characteristics of Multiprocessors

  • Interconnection Structures
  • Interprocessor Arbitration
  • Interprocessor Communication/Synchronization
  • Cache Coherence**

8 SIMPLE DIGITAL SYSTEMS

  • Combinational and sequential circuits (learned in Chapters 1 and 2) can be used to create simple digital systems.
  • These are the low-level building blocks of a digital computer.
  • Simple digital systems are frequently characterized in terms of
    • the registers they contain, and
    • the operations that they perform.
  • Typically,
    • What operations are performed on the data in the registers
    • What information is passed between registers Register Transfer &- operations

10 MICROOPERATIONS (1) Register Transfer Language

  • The operations on the data in registers are called microoperations.
  • The functions built into registers are examples of microoperations - Shift - Load - Clear - Increment - Register Transfer &- operations

11 MICROOPERATION (2) An elementary operation performed (during one clock pulse), on the information stored in one or more registers R  f(R, R) f: shift, load, clear, increment, add, subtract, complement, and, or, xor, … ALU (f) Registers (R) 1 clock cycle Register Transfer &- operations Register Transfer Language

13 REGISTER TRANSFER LEVEL Register Transfer Language

  • Viewing a computer, or any digital system, in this way is called the register transfer level
  • This is because we’re focusing on
    • The system’s registers
    • The data transformations in them, and
    • The data transfers between them. Register Transfer &- operations

14 REGISTER TRANSFER LANGUAGE Register Transfer Language

  • Rather than specifying a digital system in words, a specific notation is used, register transfer language
  • For any function of the computer, the register transfer language can be used to describe the (sequence of) microoperations
  • Register transfer language
    • A symbolic language
    • A convenient tool for describing the internal organization of digital computers
    • Can also be used to facilitate the design process of digital systems. Register Transfer &- operations

16 DESIGNATION OF REGISTERS Register Transfer Language R Register Numbering of bits Showing individual bits Subfields PC(H) PC(L) 15 8 7 0

  • a register
  • portion of a register
  • a bit of a register
  • Common ways of drawing the block diagram of a register 7 6 5 4 3 2 1 0 R 15 0
  • Designation of a register Register Transfer &- operations

17 REGISTER TRANSFER Register Transfer

  • Copying the contents of one register to another is a register transfer
  • A register transfer is indicated as R2  R
    • In this case the contents of register R1 are copied (loaded) into register R
    • A simultaneous transfer of all bits from the source R1 to the destination register R2, during one clock pulse
    • Note that this is a non-destructive; i.e. the contents of R1 are not altered by copying (loading) them to R Register Transfer &- operations

19 CONTROL FUNCTIONS Register Transfer

  • Often actions need to only occur if a certain condition is true
  • This is similar to an “if” statement in a programming language
  • In digital systems, this is often done via a control signal , called a control function - If the signal is 1, the action takes place
  • This is represented as: P: R2  R Which means “if P = 1, then load the contents of register R1 into register R2”, i.e., if (P = 1) then (R2  R1) Register Transfer &- operations

20 HARDWARE IMPLEMENTATION OF CONTROLLED TRANSFERS Implementation of controlled transfer P: R2 R Block diagram Timing diagram Clock Register Transfer Transfer occurs here R R Control Circuit P^ Load n Clock Load t (^) t+

  • The same clock controls the circuits that generate the control function and the destination register
  • Registers are assumed to use edge-triggered flip-flops Register Transfer &- operations
