NETWORK PLAN FOR
OFFICE OF THE BARANGAY PANIQUE
PANIQUE, ODIONGAN, ROMBLON
I. NETWORK PROTOCOL Ethernet – It serves as a link between the components of the network plan and Ethernet uses TPC or Fiber Optic Cable to connect each components II. NETWORK MEDIUM Twisted Pair Cable (Category 6) III. INTERNET ACCESS (Discussion): The small office of the Barangay Panique is recommended to use PLDT Home Prepaid Wifi (powered by Smart Communication: LTE simcard). Due to network data received in this area, the internet connection is not typically as fast as expected. Using this device, a better and faster connection will be experience. With a speed of 100mbps, sending important documents and communicating will be sent without a hassle.
SPECIFICATION OF SOFTWARE AND
HARDWARE
Switch
TPLINK, 12 Ports, 10/100 MBPS, Desktop Switch, Hardware Features 5x10/ 100mbps RJ45port Auto/Auto MID/MDX Dimensions (WxDxH) 4.1 x 2.8 x 0.9 in.
PLDT HOME WIFI
AC1200 2x2 MU-MIMO Wave Two 1Gigabyte Ethernet Port per Unit 1 USB type-C port 512mb Ram, 4GB EMMC Flash 15W power Adopter
Scanner Size 455x304x70mm Weight 2.89kg Scanning Element Charge Coupled device Interface USB 2.0 High Speed
HARDWARE NEEDED
- 1pc PLDT Home Prepaid Wifi P 1,995. QUANTITY ITEM DESCRIPTION UNIT PRICE TOTAL PRICE - 1pc TP-LINK 12-Port Gigabit Switch TLsg1016D P 2,975. - 8pcs RJ45 Plugs P 5.00 P 40. - 40meters UTP Cable P 13.00/meter P 520.
- Size 455x304x70mm SCANNER P3, - TOTAL: P 9,230. - ESTIMATED BUDGET: P 9,230.
LOGICAL AND PHYSICAL LAYOUT DISCUSSION The 3 computers, will be connected through the switch which will also provide connection to the Broadband. The Printer and Scanner are connected also to the switch.
