Motion illusion, rotating snakes
Docsity.com
Image Filtering Computer Vision
Docsity.com
Image filtering
- Image filtering: compute function of local neighborhood at each position
- Really important!
- Enhance images
- Denoise, resize, increase contrast, etc.
- Extract information from images
- Texture, edges, distinctive points, etc.
- Detect patterns
- Template matching
- Enhance images
Docsity.com
1 1 1 1 1 1 1 1 1 Slide credit: David Lowe (UBC) g[ ,] Example: box filter
Docsity.com
f [.,.] h [.,.] Image filtering
g[ ,]
Credit: S. Seitz
[ , ] [ , ] [ , ] , h m n g k l f m k n l k l
Docsity.com
f [.,.] h [.,.] Image filtering
g[ ,]
Credit: S. Seitz
[ , ] [ , ] [ , ] , h m n g k l f m k n l k l
Docsity.com
f [.,.] h [.,.] Image filtering
g[ ,]
Credit: S. Seitz
[ , ] [ , ] [ , ] , h m n g k l f m k n l k l
Docsity.com
f [.,.] h [.,.] Image filtering
g[ ,]
Credit: S. Seitz
? [ , ] [ , ] [ , ] , h m n g k l f m k n l k l
Docsity.com
f [.,.] h [.,.] Image filtering
g[ , ]
Credit: S. Seitz
[ , ] [ , ] [ , ] , h m n g k l f m k n l k l
Docsity.com
What does it do?
- Replaces each pixel with an average of its neighborhood
- Achieve smoothing effect (remove sharp features) 1 1 1 1 1 1 1 1 1 Slide credit: David Lowe (UBC) g[ ,] Box Filter
Docsity.com
Practice with linear filters
0 0 0 0 1 0 0 0 0 Original
Source: D. LoweDocsity.com
Practice with linear filters 0 0 0 0 1 0 0 0 0 Original (^) Filtered (no change)
Source: D. LoweDocsity.com
Practice with linear filters 0 0 0 0 0 1 0 0 0 Original (^) Shifted left By 1 pixel
Source: D. LoweDocsity.com
Practice with linear filters
Original 1 1 1 1 1 1 1 1 1 0 0 0 0 2 0 0 0 0
(Note that filter sums to 1)
