AN No.SIG-CHMO9805A

Liquid Crystal Displays Liquid Crystal Displays

Application Notes Application Notes

Seiko Instruments GmbH Seiko Instruments GmbH

Standard Character Modules Standard Character Modules

AN No.SIG-CHMO9805A

Notice

This manual describes the technical information, the functions, and the instructions of Liquid Crystal

Display Modules from Seiko Instruments GmbH. Please read this instruction manual carefully to

familiarise yourself with the functions and make the best use of them. The descriptions here are

subject to change without notice.

Revision Record

Edition Revision Date

1 Original May 29,

Seiko Instruments GmbH 1998

Printed in Germany

Product Selection Guide AN No.SIG-CHMO9805A

Character Format (character x line) 16 x 1 16 x 2 16 x 2 16 x 2 16 x 4 20 x 2 Model M1641 M1632 L1642 L1652 L1614 L Ref lective M16410AS M16320AS L164200J000S L165200J200S L161400J000S L201200J000S EL backlight M16419DWS M16329DWS L164221J000S L165221J200S L161421J000S L201221J000S LED backlight M16417DYS M16327DYS L1642B1J000S L1652B1J200S L1614B1J000S L2012B1J000S Ref lective (w ide temp) M16410CS M16320CS L164200L000S L165200L200S L161400L000S L201200L000S LED backlight (w ide temp) M16417JYS M16327JYS L1642B1L000S L1652B1L200S L1614B1L000S L2012B1L000S Character font 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor Module Ref lective 80,0 x 36,0 x 11,3 85,0 x 30,0 x 10,1 80,0 x 36,0 x 11,3 122,0 x 44,0 x 11,3 87,0 x 60,0 x 11,6 116,0 x 37,0 x 11, size EL backlight 80,0 x 36,0 x 11,3 85,0 x 30,0 x 10,1 80,0 x 36,0 x 11,3 122,0 x 44,0 x 11,3 87,0 x 60,0 x 11,6 116,0 x 37,0 x 11, (HxVxT) mm LED backlight 80,0 x 36,0 x 15,8 80,0 x 30,0 x 15,8 80,0 x 36,0 x 15,8 122,0 x 44,0 x 15,8 87,0 x 60,0 x 15,8 116,0 x 37,0 x 15, View ing area (HxV) mm 64,5 x 13,8 62,0 x 16,0 64,5 x 13,8 99,0 x 24,0 61,8 x 25,2 83,0 x 18, Character size (HxV) mm 3,07 x 5,73 2,78 x 4,27 2,95 x 3,80 4,84 x 8,06 2,95 x 4,15 3,20 x 4, Dot size (HxV) mm 0,55 x 0,75 0,50 x 0,55 0,50 x 0,55 0,92 x 1,10 0,55 x 0,55 0,60 x 0, Pow er supply voltage (VDD-VSS) + 5 V + 5 V + 5 V + 5 V + 5 V + 5 V Current consumption IDD 1,5 2,0 1,6 2,0 2,7 2, (mA,typ) ILC 0,2 0,2 0,3 0,4 1,1 0, Driving method (duty) 1/16 1/16 1/16 1/16 1/16 1/ KS0066 KS0066 KS0066 KS0066 KS0066 KS Built-in LSI or equivalent MSM5839 MSM5839 MSM5839 KS0063 KS or equivalent or equivalent or equivalent or equivalent or equivalent Operating normal temp. 0 to + 50 0 to + 50 0 to + 50 0 to + 50 0 to + 50 0 to + 50 temperature ( ºC) w ide temp. - 20 to + 70 - 20 to + 70 - 20 to + 70 - 20 to + 70 - 20 to + 70 - 20 to + 70 Storage normal temp. - 20 to + 60 - 20 to + 60 - 20 to + 60 - 20 to + 60 - 20 to + 60 - 20 to + 60 temperature ( ºC) w ide temp. - 30 to + 80 - 30 to + 80 - 30 to + 80 - 30 to + 80 - 30 to + 80 - 30 to + 80 Weight Ref lective 25 25 25 50 50 40 (g, typ.) EL backlight 30 30 30 55 55 45 LED backlight 35 40 35 65 65 60 Model 5S 5S 5S 5C 5A 5A Inverters Pow er supply (V) + 5.0 + 5,0 + 5.0 + 5.0 + 5.0 + 5. for EL current consumption (mA) 10 10 10 35 45 45 Forw ard current LED consumption (mA) 100 112 100 240 200 154 backlight Forw ard input voltage (V,typ.) + 4,1 + 4,1 + 4,1 + 4,1 + 4,1 + 4, Page 9 12 15 18 21 24

Dot Matrix Liquid Crystal Display Module

Character Type

• Slim, light-weight and low power consumption
• High contrast and wide viewing angle
• Built-in controller for easy interface
• Available EL and LED backlight type
• Available in wide temperature type

FEATURES

The table below shows a quick reference guide of the character LCD modules. You can see the standard

specifications and other optical specifications on the reference page of each model shown in the table below.

Product Selection Guide AN No.SIG-CHMO9805A

Character Format (character x line) 20 x 2 20 x 4 24 x 2 40 x 2 40 x 4 Model L2022 L2014 L2432 L4042 M Reflective - L201400J000S L243200J000S L404200J000S M40240AS EL backlight - L201421J000S L243221J000S L404221J000S M40249DWS LED backlight - L2014B1J000S L2432B1J000S L4042B1J000S M40247DYS Reflective (w ide temp) L202200P000S L201400L000S L243200L000S L404200L000S M40240CS LED backlight (w ide temp) L2022B1P000S L2014B1L000S L2432B1L000S L4042B1L000S M40247JYS Character font 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor 5x7 dots + cursor Module Reflective 180,0 x 40,0 x 10,5 98,0 x 60,0 x 11,6 118,0 x 36,0 x 11,3 182,0 x 33,5 x 11,3 190,0 x 54,0 x 10, size EL backlight 180,0 x 40,0 x 10,5 98,0 x 60,0 x 11,6 118,0 x 36,0 x 11,3 182,0 x 33,5 x 11,3 190,0 x 54,0 x 10, (HxVxT) mm LED backlight 180,0 x 40,0 x 14,8 98,0 x 60,0 x 15,8 118,0 x 36,0 x 15,8 182,0 x 33,5 x 16,3 190,0 x 54,0 x 16, View ing area (HxV) mm 149,0 x 23,0 76,0 x 25,2 94,5 x 17,8 154,4 x 15,8 147,0 x 29, Character size (HxV) mm 6,00 x 9,66 2,95 x 4,15 3,20 x 4,85 3,20 x 4,85 2,78 x 4, Dot size (HxV) mm 1,12 x 1,12 0,55 x 0,55 0,60 x 0,65 0,60 x 0,65 0,50 x 0, Pow er supply voltage (VDD-VSS) + 5 V + 5 V + 5 V + 5 V + 5 V Current consumption IDD 4,2 2,9 2,5 3,0 8, (mA,typ) ILC 2,6 1,2 0,5 1,0 3, Driving method (duty) 1/16 1/16 1/16 1/16 1/ KS0066 KS0066 KS0066 KS0066 KS Built-in LSI KS0063 MSM5839 KS0063 KS0063 MSM or equivalent or equivalent or equivalent or equivalent or equivalent Operating normal temp. - 0 to + 50 0 to + 50 0 to + 50 0 to + 50 temperature ( ºC) w ide temp. - 20 to + 70 - 20 to + 70 - 20 to + 70 - 20 to + 70 - 20 to + 70 Storage normal temp. - - 20 to + 60 - 20 to + 60 - 20 to + 60 - 20 to + 60 temperature ( ºC) w ide temp. - 30 to + 80 - 30 to + 80 - 30 to + 80 - 30 to + 80 - 30 to + 80 Weight Reflective 80 55 40 70 90 (g, typ.) EL backlight - 60 45 75 105 LED backlight 110 70 60 95 140 Model - 5A 5A 5C 5D Inverters Pow er supply (V) + 5.0 + 5.0 + 5.0 + 5.0 + 5. for EL current consumption (mA) - 45 45 25 80 Forw ard current LED consumption (mA) 320 240 150 260 480 backlight Forw ard input voltage (V,typ.) + 4,1 + 4,1 + 4,1 + 4,1 + 4, Page 27 29 32 35 38

Dot Matrix Liquid Crystal Display Module

Character Type

• Slim, light-weight and low power consumption
• High contrast and wide viewing angle
• Built-in controller for easy interface
• Available EL and LED backlight type
• Available in wide temperature type

FEATURES

The table below shows a quick reference guide of the character LCD modules. You can see the standard

specifications and other optical specifications on the reference page of each model shown in the table below.

Reliability AN No.SIG-CHMO9805A

Test Item Test Conditions result Operation at 40 ºC ± 2 ºC No abnormalities high temperature 90% RH for 500 hours in functions* and and humidity appearance** Operation at 60 ºC ± 2 ºC for 500hrs No abnormalities high temperature in functions* and appearance** Heat shock -20 ºC (^) ⇔ +60 ºC Left for 1 hour at No abnormalities each temperature, in functions* and transition time 5 minutes appearance** repeated 10 times Low Temperature -20 ºC ± 2 ºC for 500hrs No abnormalities in functions* and appearance** Vibration Sweep for 1 min. at 10Hz, 55Hz, 10Hz No abnormalities amplitude 1.5mm 2 hours in functions* and each in the X,Y and Z appearance** directions Drop shock Dropped onto a board No abnormalities from a height of 30cm in functions* and appearance**

• Dissipation current, contrast and display functions ** Ploarizer deterioration, other appearance defect

Test Item Test Conditions result Operation at 60 ºC ± 2 ºC No abnormalities high temperature 90% RH for 500 hours in functions* and and humidity appearance** Operation at 80 ºC ± 2 ºC for 500hrs No abnormalities high temperature in functions* and appearance** Heat shock -30 ºC ⇔ +80 ºC Left for 1 hour at No abnormalities each temperature, in functions* and transition time 5 minutes appearance** repeated 10 times Low Temperature -30 ºC ± 2 º C for 500hrs No abnormalities in functions* and appearance** Vibration Sw eep for 1 min. at 10Hz, 55Hz, 10Hz No abnormalities amplitude 1.5mm 2 hours in functions* and each in the X,Y and Z appearance** directions Drop shock Dropped onto a board No abnormalities from a height of 30cm in functions* and appearance**

• Dissipation current, contrast and display functions ** Polarizer deterioration, other appearance defect

1. Reliability Test

1.1 Normal Temperature type

1.2 Wide Temperature type

Item Conditions Standard Unit Life time 25 ºC ± 10 ºC 100,000 or more hours < 65 %RH

**2. LCD Life Time

3. Definition of LCD service life**
   • Contrast becomes 30% of initial value
   • Current consumption becomes three times higher than

initial value

• Remarkable alignment deterioration occurs in LCD

cell layer

• Unusual operation occurs in display functions

How To Use LCD Module AN No.SIG-CHMO9805A

1. Safety

• If the LCD panel is damaged, be careful not to get the liquid crystal in your mouth and not to be injured by crushed glass.
• If you should swallow the liquid crystal , first wash your mouth thoroughly with water, then drink a lot of water induce vomiting and then consult a physician.
• If the liquid crystal should get in your eyes, flush your eyes with running water for at least fifteen minutes.
• If the liquid crystal touches your skin or clothes, remove it and wash the affected part of your skin or clothes with soap and running water.
• High voltage is applied to the lead terminals of the EL lamp. Do not touch any part of the lead terminals. (For LCD module with EL backlight)
• Do not use EL inverters without a load or in the short-circuit mode.
• Use the LCD module within the rated voltage to prevent overheating and/or damage. Also, take steps to ensure that the connector does not come off.

2. LCD Handling

• Please keep the temperature within the specified range for use and storage. Polarization degradation, bubble generation or polarizer peel-off may occur with high temperature and high humidity.
• Do not touch, push or rub the exposed polarizers with anything harder than hardness of 3B (glass, tweezers, etc..).
• When the display surface becomes dusty, wipe gently with absorbent cotton or other soft material like chamois soaked in petroleum benzene. Do not scrub hard to avoid damaging the display surface.
• Wipe off saliva or water drops immediately. Contact with water over a long period of time may cause deformation or color fading.
• Avoid contact with oil and fats.
• Condensation on the surface and contact terminals due to cold will damage, stain or dirty the polarizers. After products are tested at low temperatures they must be warmed up in a container before coming in contact with room temperature air.
• Do not put or attach anything on the display area to avoid leaving marks on.
• Do not touch the display area with bare hands, damage the display area and degrade insulation between terminals. (some cosmetics are detrimental to the polarizers)
• As glass is fragile, it tends to become cracked or chipped during handling especially on the edges, Please avoid dropping or jarring.

3. LCD Module

3.1 Mounting LCD module

• Use the specified mounting parts and holes to mount the module.
• Connect a 10 μF capacitor between the power supply terminals to eliminate noise.

Module

Screw

Fitting plate Transparent plate

Small gap

• Make sure that no stress is applied on the module when it is mounted. The application of stress for a long time may damage the LCD panel and the ICs substrates.
• To protect the polarizer and the LCD panel, cover the display surface with a transparent plate, for example, acrylic or glass, with a small gap between the transparent plate and the LCD surface.
• Do not apply input signals when power supply voltage isn't applied. 3.2 Precaution for handling LCD module Since the module has been assembled and adjusted with a high degree of precision, avoid applying excessive shocks to the module or making any modifications to it.
• Do not alter, modify or change the shape of the tab on the metal frame.
• Do not make extra holes on the PCB, modify its shape or change the positions of components attached.
• Do not damage or modify the pattern wiring on the PCB
• Do not modify the zebra rubber or touch it with another materials.
• Do not make any modifications with a soldering iron except indicating area.
• Do not drop, bend or twist the module. 3.3 Electro-static discharge Since CMOS ICs are mounted on the module, special attention has to be paid to the electric-static discharge.
• Make sure that you are connected to the ground during handling of the module.
• Before removing the module from packing unit make sure that the module and yourself have the same electric potential.
• When soldering the terminal of the module, make sure that the AC power source for the soldering iron does not leak.
• When using an electric screwdriver to attach the module, the screwdriver should be grounded to minimise as much as possible any transmission of electro-magnetic waves produced by sparks coming from the accumulator of the motor.
• Make your clothes and working bench the ground potential as much as possible.
• Avoid to generate static electricity, relative humidity should be 50 ~ 60 %RH. 3.4 Precaution for operation
• Proper operating voltage for LCD gives optimum viewing angle.
• If LCD surface is pressed harder during operation, the display becomes abnormal and then will return to normal after the pressure is released. However, it may generate bubbles and cause permanent damage to the LCD.
• Condensation may generate electrochemical reaction and then it may cause open or short circuit on the terminal. 3.5 Cleaning
• Do not wipe the polarizer with a dry cloth, as it may scratch the surface.
• Wipe the module gently with a soft cloth soaked with a petroleum benzene.
• Do not use ketonic solvents (ketone, acetone etc.) or aromatic solvents (toluene and xylenen) as they may damage the polarizing plate.

4. Storage

• Store the module in the dark place. Keep the temperature between 15 ºC and 35 ºC and the humidity below 65%RH.
• Do not store the module near organic solvents or corrosive gases.
• Make sure that no stress or vibration is applied to the module when it is stored.
• Use the products with EL backlight within 6 months after receiving them.

Character LCD Module AN No.SIG-CHMO9805A

Angles ∅∅ and θθ

Z

X’ X

Y’(∅=180 ° )

Y (∅=180 ° )

Viewing Angle θθ 11 and θθ 22

C max.

Contrast C

Viewing Angle

C=

Brightness (reflection) of non-selected segment (B 2 )

Brightness (reflection) of selected segment (B 1 )

B 2

B 1

Brightness (reflection)

of selected segment

Brightness

(reflection)

of non-selected

segment

(Dark)

Brightness

(reflection)

(bright)

Operating Voltage (V)

Contrast C

1/fFRM

Vopr

Unselected state

Selected state (display ON)

Unselected state (display OFF)

100% 90%

ton toff

10%

Brightness (transmissin)

(Bright)

(Dark)

Voltage

(V)

Vopr : Operating Voltage fFRM : Frame Frequency ton : Response time (rise) toff : Response time (fall)

Definition of Optical Characteristics Term

Response Time

AN No.SIG-CHMO9805A

16 Characters x 1 line 5 x 7 Dot Matrix + Cursor 1/16 Duty 5V single Power Supply Available in EL and LED Backlight type

M1641 (16 x 1)

Note : Only dimension changes between Reflective/EL and LED backlight is the thickness

Absolute Maximum Ratings

Electrical Characteristics

Mechanical Characteristics

Pin Function

Dimensions

VSS=0V, Ta=25º C Item Symbol Conditions Min. Max. Unit Pow er supply VDD -0.3 6.0 V voltage VLC -0.3 VDD V Input voltage Vin -0.3 V (^) DD +0.3 V Operating temperature Normal Topr 0 +50 ºC Wide Topr -20 +70 ºC Storage temperature Normal Tstg -20 +60 ºC Wide Tstg -30 +80 ºC Storage < 48 hrs +20 +85 %RH humidity <1000 hrs +20 +65 %RH

No. Name Function 1 VSS GND 2 VDD Pow er supply voltage +5V 3 VLC Liquid crystal driving voltage 4 RS L : Instruction code input H: Data input 5 R/W L : Data w rite from MPU to LCM H : Data read from LCM to MPU 6 E Enable 7 DB0 Data bus line 8 DB1 Data bus line 9 DB2 Data bus line 10 DB3 Data bus line 11 DB4 Data bus line 12 DB5 Data bus line 13 DB6 Data bus line 14 DB7 Data bus line

Item Specifications Unit Module size (H x V) 80.0 x 36.0 mm Thickness Reflective/EL 11.3 mm LED 15.8 mm View ing area (H x V) 64.5 x 13.8 mm Character size w ith cursor (H x V) 3.07 x 6.56 mm Mounting hole distance (H x V) 75.0 x 31.0 mm Reflective 25 g Weight EL backlight 30 g LED backlight 35 g H : Horizontal, V : Vertical

VDD=5V± 5%, VSS=0V, Ta=0 ~ 50ºC Item Symbol Conditions Min. Typ. Max. Unit Pow er supply VDD 4.75 5.00 5.25 V voltage VDD - VLC 3.0 - 6.3 V Input High VIH1 2.2 - VDD V voltage Low VIL1 0 - 0.6 V Output High VOH1 -IOH=0.205mA 2.4 - - V voltage Low VLH1 -IOL=1.2mA - - 0.4 V Current consumption * Normal Temp IDD Ta=25º C - 1.3 2.0 mA type ILC VLC=0.25V - 0.2 0.6 mA Wide Temp. IDD Ta=25º C - 1.6 2.5 mA type ILC VLC=-0.6V - 0.3 1.0 mA

• test pattern : check board pattern

M1641 (1x16) Unit: mm. General tolerance ±0,5 mm

LED Backlight

Reflective/EL Backlight

M1641 (16 x 1) AN No.SIG-CHMO9805A

1.Absolute Maximum Ratings

2. Brightness, Current, Life Characteristics

3.4 Inverter Dimensions (unit : mm)

Pin No. Function 1 Input : 5V DC 2 Common : GND 3 Output

EL Backlight

3.1 Electrical Characteristics

(When combined with EL lamp)

3.2 Tolerance (Inverter only)

3.3 Maximum Ratings (Inverter only)

3. Suitable Inverter 5S

Item Symbol Standard Unit Operating Vopr AC 150V, 1KHz V voltage Sinew ave Operating Topr 0 ~ +50 ºC temperature Storage Tstg -20 ~ + 60 ºC temperature Storage 0 ~ 10 % RH (60 ºC) humidity 0 ~ 30 % RH (40 ºC)

Item Conditions Specifications Unit Brightness 100V, 400Hz 40 min. cd/m² Sinew ave Current 100V, 400Hz 1.5 max. mA Sinew ave Lif e 100V, 400Hz, Sinew ave 3, 25ºC,50%RH hrs Using 5S Inverter 6, 25ºC,50%RH

Ta=25º C Item Symbol Conditions Specifications Unit Oscillating fINV VIN=5VDC 550 typ. Hz frequency Output voltage VOUT VIN=5VDC 100 typ. V Output current IOUT VIN=5VDC 1.5 typ. mA Input current VIN 10 Vrms Voltage IIN VIN=5VDC 5 typ VDC

Item Specifications Unit Input voltage 3.0 to 6.0 V Load range 25 to 40 cm²

Item Specifications Unit Input voltage 7.0 V Load range 50 cm² Operating temperature -10 to +60 ºC Storage temperature -20 to +70 ºC

2 min.

AN No.SIG-CHMO9805A

16 Characters x 2 line 5 x 7 Dot Matrix + Cursor 1/16 Duty 5V single Power Supply Available in EL and LED Backlight type

M1632 (16 x 2)

Note : Only dimension changes between Reflective/EL and LED backlight is the thickness.

Absolute Maximum Ratings

Electrical Characteristics

Mechanical Characteristics

Pin Function

Dimensions

VSS=0V, Ta=25º C Item Symbol Conditions Min. Max. Unit Pow er supply VDD -0.3 6.0 V voltage VLC -0.3 VDD V Input voltage Vin -0.3 V (^) DD +0.3 V Operating temperature Normal Topr 0 +50 ºC Wide Topr -20 +70 ºC Storage temperature Normal Tstg -20 +60 ºC Wide Tstg -30 +80 ºC Storage < 48 hrs +20 +85 %RH humidity <1000 hrs +20 +65 %RH

No. Name Function 1 VSS GND 2 VDD Pow er supply voltage +5V 3 VLC Liquid crystal driving voltage 4 RS L : Instruction code input H: Data input 5 R/W L : Data w rite from MPU to LCM H : Data read from LCM to MPU 6 E Enable 7 DB0 Data bus line 8 DB1 Data bus line 9 DB2 Data bus line 10 DB3 Data bus line 11 DB4 Data bus line 12 DB5 Data bus line 13 DB6 Data bus line 14 DB7 Data bus line ( 15 ) A Anode (+) for LED backlight ( 16 ) K Cathode (-) for LED backlight

Item Specifications Unit Module size (H x V) 85.0 x 30.0 mm Thickness Reflective/EL 10.1 mm LED 15.8 mm View ing area (H x V) 62.0 x 16.0 mm Character size w ith cursor (H x V) 2.78 x 4.89 mm Mounting hole distance (H x V) 82.0 x 24.0 mm Reflective 25 g Weight EL backlight 30 g LED backlight 40 g H : Horizontal, V : Vertical

VDD=5V± 5%, VSS=0V, Ta=0 ~ 50ºC Item Symbol Conditions Min. Typ. Max. Unit Pow er supply VDD 4.75 5.00 5.25 V voltage VDD - VLC 3.0 - 6.3 V Input High VIH1 2.2 - VDD V voltage Low VIL1 0 - 0.6 V Output High VOH1 -IOH=0.205mA 2.4 - - V voltage Low VLH1 -IOL=1.2mA - - 0.4 V Current consumption * Normal Temp IDD Ta=25º C - 1.6 2.5 mA type ILC VLC=0.25V - 0.2 1.0 mA Wide Temp. IDD Ta=25º C - 1.6 2.5 mA type ILC VLC=-0.6V - 0.3 1.0 mA

• test pattern : check board pattern

M1632 (2x16) Unit: mm, General tolerance ±0.5 mm

Reflective/EL Backlight LED Backlight

M1632 (16 x 2) AN No.SIG-CHMO9805A

1.Absolute Maximum Ratings

2. Brightness, Current, Life Characteristics

3.4 Inverter Dimensions (unit : mm)

Pin No. Function 1 Input : 5V DC 2 Common : GND 3 Output

EL Backlight

3.1 Electrical Characteristics

(When combined with EL lamp)

3.2 Tolerance (Inverter only)

3.3 Maximum Ratings (Inverter only)

3. Suitable Inverter 5S

Item Symbol Standard Unit Operating Vopr AC 150V, 1KHz V voltage Sinew ave Operating Topr -10 ~ +50 ºC temperature Storage Tstg -20 ~ + 60 ºC temperature Storage 0 ~ 10 % RH (60 ºC) humidity 0 ~ 30 % RH (40 ºC)

Item Conditions Specifications Unit Brightness 100V, 400Hz 30 min. cd/m² Sinew ave 35 typ. Current 100V, 400Hz 1.2 typ. mA Sinew ave 1.7 max Lif e * 100V, 400Hz, Sinew ave 1, 25ºC,50%RH hrs Using 5S Inverter 4, 25ºC,50%RH

• Def inition of Life : Used continuously dow n to 10 cd/m²

Ta=25º C Item Symbol Conditions Specifications Unit Oscillating f (^) INV VIN=5VDC 550 typ. Hz frequency Output voltage VOUT VIN=5VDC 100 typ. V Output current IOUT VIN=5VDC 1.5 typ. mA Input current VIN 5 typ VDC voltage IIN VIN=5VDC 10 typ mA Initial brightness B VIN=5VDC 35 typ. cd/m² Surface brightness BP VIN=5VDC 7 typ. cd/m² (panel upper side) Vopr=0V

Item Specifications Unit Input voltage 3.0 to 6.0 V Load range 5 to 15 cm²

Item Specifications Unit Input voltage 7.0 V Load range 50 cm² Operating temperature -10 to +60 ºC Storage temperature -20 to +70 ºC

2 min.

AN No.SIG-CHMO9805A

16 Characters x 2 line 5 x 7 Dot Matrix + Cursor 1/16 Duty 5V single Power Supply Available in EL and LED Backlight type

L1642 (16 x 2)

Note : Only dimension changes between Reflective/EL and LED backlight is thickness.

Absolute Maximum Ratings

Electrical Characteristics

Mechanical Characteristics

Pin Function

Dimensions

VSS=0V, Ta=25º C Item Symbol Conditions Min. Max. Unit Pow er supply VDD -0.3 6.0 V voltage VLC -0.3 VDD V Input voltage Vin -0.3 V (^) DD +0.3 V Operating temperature Normal Topr 0 +50 ºC Wide Topr -20 +70 ºC Storage temperature Normal Tstg -20 +60 ºC Wide Tstg -30 +80 ºC Storage < 48 hrs +20 +85 %RH humidity <1000 hrs +20 +65 %RH

No. Name Function 1 VSS GND 2 VDD Pow er supply voltage +5V 3 VLC Liquid crystal driving voltage 4 RS L : Instruction code input H: Data input 5 R/W L : Data w rite from MPU to LCM H : Data read from LCM to MPU 6 E Enable 7 DB0 Data bus line 8 DB1 Data bus line 9 DB2 Data bus line 10 DB3 Data bus line 11 DB4 Data bus line 12 DB5 Data bus line 13 DB6 Data bus line 14 DB7 Data bus line ( 15 ) A Anode (+) for LED backlight ( 16 ) K Cathode (-) for LED backlight

Item Specifications Unit Module size (H x V) 80.0 x 36.0 mm Thickness Reflective/EL 11.3 mm LED 15.8 mm View ing area (H x V) 64.5 x 13.8 mm Character size w ith cursor (H x V) 2.95 x 4.35 mm Mounting hole distance (H x V) 75.0 x 31.0 mm Reflective 25 g Weight EL backlight 30 g LED backlight 35 g H : Horizontal, V : Vertical

VDD=5V± 5%, VSS=0V, Ta=0 ~ 50ºC Item Symbol Conditions Min. Typ. Max. Unit Pow er supply VDD 4.75 5.00 5.25 V voltage VDD - VLC 3.0 - 6.3 V Input High VIH1 2.2 - VDD V voltage Low VIL1 0 - 0.6 V Output High VOH1 -IOH=0.205mA 2.4 - - V voltage Low VLH1 -IOL=1.2mA - - 0.4 V Current consumption * Normal Temp IDD Ta=25º C - 1.6 3.0 mA type ILC VLC=0.25V - 0.3 1.0 mA Wide Temp. IDD Ta=25º C - 1.6 3.0 mA type ILC VLC=-0.6V - 0.4 1.0 mA

• test pattern : check board pattern

L1642 (2x16) Unit: mm, General tolerance ±0.5 mm

Reflective/EL Backlight LED Backlight

L1642 (16 x 2) AN No.SIG-CHMO9805A

1.Absolute Maximum Ratings

2. Brightness, Current, Life Characteristics

3.4 Inverter Dimensions (unit : mm)

Pin No. Function 1 Input : 5V DC 2 Common : GND 3 Output

EL Backlight

3.1 Electrical Characteristics

(When combined with EL lamp)

3.2 Tolerance (Inverter only)

3.3 Maximum Ratings (Inverter only)

3. Suitable Inverter 5S

Item Symbol Standard Unit Operating Vopr AC 150V, 1KHz V voltage Sinew ave Operating Topr 0 ~ +50 ºC temperature Storage Tstg -20 ~ + 60 ºC temperature Storage 0 ~ 10 % RH (60 ºC) humidity 0 ~ 30 % RH (40 ºC)

Item Conditions Specifications Unit Brightness 100V, 400Hz 30 min. cd/m² Sinew ave 35 typ. Current 100V, 400Hz 1.2 typ. mA Sinew ave 1.7 max Lif e 100V, 400Hz, Sinew ave 1, 25ºC,50%RH hrs Using 5S Inverter 4, 25ºC,50%RH

Item Specifications Unit Input voltage 3.0 to 6.0 V Load range 25 to 40 cm²

Item Specifications Unit Input voltage 7.0 V Load range 50 cm² Operating temperature -10 to +60 ºC Storage temperature -20 to +70 ºC

2 min.

Ta=25º C Item Symbol Conditions Specifications Unit Oscillating fINV VIN=5VDC 550 typ. Hz frequency Output voltage VOUT VIN=5VDC 100 typ. V Output current IOUT VIN=5VDC 1.5 typ. mA Input current VIN 10 Vrms voltage IIN VIN=5VDC 5 typ VDC

AN No.SIG-CHMO9805A

16 Characters x 2 line 5 x 7 Dot Matrix + Cursor 1/16 Duty 5V single Power Supply Available in EL and LED Backlight type

L1652 (16 x 2)

Note : Only dimension changes between Reflective/EL and LED backlight is thickness.

Absolute Maximum Ratings

Electrical Characteristics

Mechanical Characteristics

Pin Function

Dimensions

VSS=0V, Ta=25º C Item Symbol Conditions Min. Max. Unit Pow er supply VDD -0.3 6.0 V voltage VLC -0.3 VDD V Input voltage Vin -0.3 V (^) DD +0.3 V Operating temperature Normal Topr 0 +50 ºC Wide Topr -20 +70 ºC Storage temperature Normal Tstg -20 +60 ºC Wide Tstg -30 +80 ºC Storage < 48 hrs +20 +85 %RH humidity <1000 hrs +20 +65 %RH

No. Name Function 1 VSS GND 2 VDD Pow er supply voltage +5V 3 VLC Liquid crystal driving voltage 4 RS L : Instruction code input H: Data input 5 R/W L : Data w rite from MPU to LCM H : Data read from LCM to MPU 6 E Enable 7 DB0 Data bus line 8 DB1 Data bus line 9 DB2 Data bus line 10 DB3 Data bus line 11 DB4 Data bus line 12 DB5 Data bus line 13 DB6 Data bus line 14 DB7 Data bus line ( 15 ) A Anode (+) for LED backlight ( 16 ) K Cathode (-) for LED backlight

Item Specifications Unit Module size (H x V) 122.0 x 44.0 mm Thickness Reflective/EL 11.3 mm LED 15.8 mm View ing area (H x V) 99.0 x 24.0 mm Character size w ith cursor (H x V) 4.84 x 9.66 mm Mounting hole distance (H x V) 115.0 x 37.0 mm Reflective 50 g Weight EL backlight 55 g LED backlight 65 g H : Horizontal, V : Vertical

VDD=5V± 5%, VSS=0V, Ta=0 ~ 50ºC Item Symbol Conditions Min. Typ. Max. Unit Pow er supply VDD 4.75 5.00 5.25 V voltage VDD - VLC 3.0 - 6.3 V Input High VIH1 2.2 - VDD V voltage Low VIL1 0 - 0.6 V Output High VOH1 -IOH=0.205mA 2.4 - - V voltage Low VLH1 -IOL=1.2mA - - 0.4 V Current consumption * Normal Temp IDD Ta=25º C - 1.8 3.0 mA type ILC VLC=0.25V - 0.4 1.0 mA Wide Temp. IDD Ta=25º C - 2.0 3.0 mA type ILC VLC=-0.6V - 0.5 1.0 mA

• test pattern : check board pattern

L1652 (2x16) Unit: mm, General tolerance ±0.5 mm

Reflective/EL Backlight LED Backlight
