NI Multisim (EWB)
Making Project
-^
File / New Project
(Project Name,
Location and Back up Files)
- Add files by right clicking the folder to
Schematic, PCB, Report
etc
- Open from the manu bar
Edit /
Properties
to set the sheet properties.
Sheet Properties
To wire the circuit
-^
Click
on
a
pin
on
a
component
to
start
the
connection.
-^
Click on a pin on the second component to finishthe
connection.
Multisim
automatically
places
the
wire,
which
conveniently
snaps
to
an
appropriate configuration, as shown below. Thisfeature saves a great deal of time when wiringlarge circuits.
Virtual Wiring
Simulation
-^
Simulate/Instruments/Oscilloscope
to place the
oscilloscope on the workspace. Wire the instrument as shownbelow.
-^
You can adjust the Time base and Channel A's Scale torequired V/Div. You will see the displayed on the scope.
The Grapher
-^
The Grapher is a multi-purpose display toolthat lets you view, adjust, save and exportgraphs and charts. It is used to display theresults of all Multisim analyses in graphs andcharts and a graph of traces for someinstruments (for example the results of theoscilloscope).
-^
