Chapter 5.1 - Processor Design 1
Outline of These Slides
•^ Overview •^ Design a processor: step-by-step •^ Requirements of the instruction set •^ Components and clocking •^ Assembling an adequate Data path •^ Controlling the data path
Chapter 5.1 - Processor Design 1
The Big Picture: Where Are We Now?
-^ The five classic components of a computer •^ Today’s topic: design a single cycle processor
ControlDatapath
Memory
Processor
Input Output
inst. set design
technology
machinedesign
Arithmetic
Chapter 5.1 - Processor Design 1
Big Picture: The Performance Perspective•^
Performance of a machine is determined by:
- Instruction count– Clock cycle time– Clock cycles per instruction -^ Processor design (datapath and control) will determine: - Clock cycle time– Clock cycles per instruction -^ What we will do Today: - Single cycle processor: -^
Advantage: One clock cycle per instruction
-^
Disadvantage: long cycle time
CPI
Inst. Count
Cycle Time
Chapter 5.1 - Processor Design 1
How to Design a Processor: Step-by-step
-^ 1. Analyze instruction set
datapath requirements
- the meaning of each instruction is given by the
register transfers
- datapath must include storage element for ISA registers -^
possibly more
- datapath must support each register transfer -^ 2. Select set of datapath components and establish clockingmethodology •^ 3. Assemble datapath meeting the requirements •^ 4. Analyze implementation of each instruction to determine setting ofcontrol points that effects the register transfer. •^ 5. Assemble the control logic
Chapter 5.1 - Processor Design 1
Step 1a: The MIPS-lite Subset for Today•^
ADD and SUB
- addU rd, rs, rt– subU rd, rs, rt -^ OR Immediate: - ori
rt, rs, imm
-^ LOAD / STORE Word - lw rt, rs, imm16– sw rt, rs, imm -^ BRANCH: - beq rs, rt, imm
op^
rs^
rt^
rd^
shamt
funct
0
6
11
16
21
26
31
6 bits
6 bits
5 bits
5 bits
5 bits
5 bits
op^
rs^
rt^
immediate
0
16
21
26
31
6 bits
16 bits
5 bits
5 bits
op^
rs^
rt^
immediate
0
16
21
26
31
6 bits
16 bits
5 bits
5 bits
op^
rs^
rt^
immediate
0
16
21
26
31
6 bits
16 bits
5 bits
5 bits
docsity.com
Chapter 5.1 - Processor Design 1
Logical Register Transfers
-^ Register Transfer Logic gives the meaning of the instructions •^ All start by fetching the instruction op | rs | rt | rd | shamt | funct = MEM[ PC ]op | rs | rt |
Imm
= MEM[ PC ]
inst
Register Transfers
ADDU
R[rd]
R[rs] + R[rt];
PC
PC + 4
SUBU
R[rd]
R[rs] – R[rt];
PC
PC + 4
ORi
R[rt]
R[rs] | zero_ext(Imm16);
PC
PC + 4
LOAD
R[rt]
MEM[ R[rs] + sign_ext(Imm16)];
PC
PC + 4
STORE
MEM[ R[rs] + sign_ext(Imm16) ]
R[rt];
PC
PC + 4
BEQ
if ( R[rs] == R[rt] ) then PC
PC + 4 + sign_ext(Imm16)] || 00
else PC
PC + 4
Chapter 5.1 - Processor Design 1
Step 2: Components of the Datapath•^
Combinational Elements • Storage Elements
- Clocking methodology
Chapter 5.1 - Processor Design 1
Combinational Logic Elements (Basic Building Blocks)
-^ Adder •^ MUX •^ ALU
A B
SumCarry
A B
Result
OP
A B^
Y
Select
CarryInAdder MUX ALU
Chapter 5.1 - Processor Design 1
Storage Element: Idealized Memory
-^ Memory (idealized) - One input bus: Data In– One output bus: Data Out -^ Memory word is selected by: - Address selects the word to put on Data Out– Write Enable = 1: address selects the memoryword to be written via the Data In bus -^ Clock input (CLK) - The CLK input is a factor ONLY during write operation– During read operation, behaves as a combinational logic block:
•^
Address valid
Data Out valid after “access time.”
Clk
Write EnableData In
DataOut
Address
Chapter 5.1 - Processor Design 1
Memory Hierarchy (Ch. 7)
•^ Want a single main memory, both large and fast •^ Problem 1: large memories are slow while fastmemories are small
-^ Example: MIPS registers (fast, but few)
•^ Solution
: mix of memories provides illusion of single
large, fast memory
-^ Cache: a small, fast memory; Holds a copy of part of a larger,slower memory •^ Imem, Dmem are really separate caches memories
Chapter 5.1 - Processor Design 1
Adding a Clock to a Circuit
•^ Clock: free running signal with fixed
cycle time
( clock
period
period
rising edge
falling edge
high (1)low (0)^ °^ Clock determines
when
to write memory element
-^ level-triggered - store clock high (low) •^ edge-triggered - store only on clock edge °^ We will use negative (falling) edge-triggered methodology
Chapter 5.1 - Processor Design 1
Role of Clock in MIPS Processors• single-cycle machine: does everything in oneclock cycle^ •^
instruction execution = up to 5 steps • must complete 5th step
before
cycle ends
clocksignal
instruction execution
step 1/step 2/step 3/step 4/step 5
datapathstable
falling clock edge register(s)written
rising clock edge
Chapter 5.1 - Processor Design 1
SR-Latches
-^ SR-latch with NAND Gates, also known as
S ´
R ´^
-latch
-^ S = 0 and R = 0 not allowed^ °^
Symbol for SR-Latch with NAND gates
Chapter 5.1 - Processor Design 1
SR-Latches with Control Input
-^ SR-latch with NAND Gates and control input
C
°^ C
= 0, no change of state;
°^ C
= 1, change is allowed;^ •^
If^
S^ = 1 and
R
= 1,
Q
and
Q
