1
SRC Exception Processing Mechanism
Interrupt Request
ireq:
Interrupt
Acknowldge
iack:
Disable
Interrupt
Flag IE:
Save PC
in IPC<31...0>
Load PC with
Exception Vector
Ivect<31…0>
Get interrupt
Info.
Isrc-info
<15…0>
Docsity.com
pf3
pf4
pf5
pf8
pf9
pfa

Partial preview of the text

Download Exception Processing Mechanism: RTL, Instruction Interpretation, and Extra Instructions and more Slides Computer Architecture and Organization in PDF only on Docsity!

1

SRC Exception Processing Mechanism

Interrupt Request ireq:

Interrupt Acknowldge iack:

Disable Interrupt Flag IE :

Save PC in IPC<31...0>

Load PC with Exception Vector Ivect<31…0>

Get interrupt Info. Isrc-info <15…0>

2

Behavioral RTL

for Exception Processing

Instruction_interpretation:=

(!Run&Strt: Run ← 1:

Run & !(ireq&IE):(IR ←M[PC],

PC ← PC + 4;

Instruction_execution),

Run&(ireq&IE): (IPC ← PC<31..0>,

II<15..0> ← Isrc_info<15..0>,

IE ← 0: PC ← Ivect<31..0>,

Iack ← 1; Iack ← 0) ,

Instruction_interpretation);

Meaning Start Normal Fetch

Interrupt, PC copied II is loaded with the info. PC loaded with new address

4

Step Concrete RTN

TO (^) (!(ireq&IE): (MA ← PC, C ← PC + 4);

(ireq&IE): (IPC ← PC,II← Isrc_info, IE ← 0,PC ← 22 α 0©Isrc_vect<7..0> © 00,iack ← 1;iack ← 0,End);

T1 MD ← M[MA],PC ← C;
T2 IR ← MD;

T3 Instruction_execution;

Structural RTL for Exception Processing

5

Combining the RTL for

reset and exception

Instruction interpretation:= Events

Run&!Rst&!(ireq&IE):(IR ← M[PC],

PC ← PC+4;

Normal Fetch

Run&Rst:( Rst ←0 , IE ← 0, PC ← 0 Soft Reset

!Run&Strt:(Run ←1, PC ← 0, R[0..31] ← 0; Hard Reset

Run&!Rst&(ireq&IE):(IPC ← PC<31..0>,

II<15..0> ← Isrc_info<15..0>,IE ← 0,

PC ← Ivect<31..0>,iack ← 1; iack ← 0;

Interrupt

7

Pipeline Stages

  • 5 pipeline stages are shown

1. Fetch instruction

2. Fetch operands

3. ALU operation

4. Memory access

5. Register write

  • 5 instructions are executing

1. ld r1, a ; memory access

2. st r2, b ; idle

3. add r4, r2, r3 ; ALU op

4. sub r6, r7, r5 ; idle

5. shr r1, r2, 4 ; write back

Fetch Inst.

Fetch Operand

ALU Operation

Memory Access

Register shr r1, r2, 4 Write

sub r6, r7, r

add r4, r2, r

st r2, b

ld r1, a

8

•Ifetch: Instruction Fetch

•Reg/Dec: Operand Fetch and Instruction Decode

•Exec: ALU operation

•Mem: Memory access stage

•Wr: Write the data back to the register file

Cycle 1 Cycle 2 Cycle 3 Cycle 4 Cycle 5

lw^ Ifetch^ Reg/Dec^ Exec^ Mem^ Wr

Pipeline Stages: alternate notation

10

Branch Delay brzr r2, r add r6, r7, r8 ;This instruction is always executed st r6, addr1 ;Only done if r2 ≠ 0

Load Delay ld r2,addr add r5, r1, r2 ;This instruction gets “old”value of r shr r1,r1, sub r6, r8, r2 ;This instruction gets r2 value loaded from addr

Branch and Load Delay example
