e-Design Curves
Release Notes
Release 3.4.0.1 – 13/02/
Fixed Bugs Fixed open file when double clicking on curves file
Thanks everyone who reported at [email protected].
Release 3.4.0 – 14/10/
What’s new New look and feel harmonized with e-Design tile Curves database merged with DOC database for easier maintenance Curves standalone module depends on DOC, so DOC installation is required starting from version 3. New navigation tree for low voltage circuit breakers New color palette
Fixed Bugs Bug fix in showing Russian characters Fixed bug showing coordinates in German version
Printed copies are uncontrolled copies. This version is current as of February 13, 2017February 13, 2017. For latest version check www.abb.com
Doc name: Dep: CCP No.: Date: Page:
DOC Release Notes Marketing Software Tools 9AKK106103A February 13, 2017
G function highlighting was returning strange form, fixed now
Thanks everyone who reported at [email protected].
Release 3.3.3 – 07/07/
Fixed Bugs Bug fix in color change of a Curve
Thanks everyone who reported at [email protected].
Release 3.2.5 – 19/01/
Fixed Bugs Fixed scale factor of Fuse Links peak curves
Thanks everyone who reported at [email protected].
Release 3.2.3 – 18/12/
Bug Fixes Irep label changed to Iinst following the standard Iinst shown using kA unit of measure Fixed Tmax XT MA settings, were not adjustable Fixed User manual broken link non it / en languages Copy paste of the diagram will keep reference voltage
Thanks everyone who reported at [email protected].
Release 3.2.1 – 6/11/
Bug Fixes Fixed bug of missing curve after double clicking on a curves file
Thanks everyone who reported at [email protected].
Release 3.2.0 – 21/10/
Printed copies are uncontrolled copies. This version is current as of February 13, 2017February 13, 2017. For latest version check www.abb.com
Doc name: Dep: CCP No.: Date: Page:
DOC Release Notes Marketing Software Tools 9AKK106103A February 13, 2017
Figure 3 - Magnetic cursor shows the chart coordinates on the chart
Curves highlighting on mouse over: curve is highlighted whenever users will move the mouse pointer on the curve.
Figure 4 - Curve Function is highlighted and details are on chart
Renewed print report graphics. Used vector graphics to drastically improve Curve resolution. Updated translations
Printed copies are uncontrolled copies. This version is current as of February 13, 2017February 13, 2017. For latest version check www.abb.com
Doc name: Dep: CCP No.: Date: Page:
DOC Release Notes Marketing Software Tools 9AKK106103A February 13, 2017
Bug Fixes Fixed unsuccessful query during selecting Residual current devices
Thanks everyone who reported at [email protected].
Known Bugs When double clicking on a Curves file to open it, curves are not displayed. Workaround is to click FILE -> OPEN and select the file you want to open.
Release 3.1.1 – 07/09/
Bug Fixes Fixed abnormal representation of Tmax LTE Curve in some particular cases
Thanks everyone who reported at [email protected].
Release 3.1.
What’s new User manuals and technical articles moved online Curves now supports import of custom curves from Excel files (xlsx, xls, csv) Implemented Dual Settings for Emax2 Breakers. Dual settings can be enabled from the settings mask and placed in the chart for a comparison with the main settings.
