3D Printer User Manual

V1.

Create reality，achieve dreams

K1C

K1C

Dear Users

Thank you for choosing our products. For the best experience, please read this User Manual carefully and strictly follow the instructions to operate the printer. Our teams will always be ready to provide you with the best services. Please contact us via the phone number or e-mail address provided at the end of this User Manual when you encounter any problem with the printer. For a better experience in using our products, you can also learn how to use the printer in the following ways:Accompanied instructions: you can find the relevant instructions and videos in the USB flash disk. You can also visit our official website (https://www.creality.com) to find information regarding software, hardware, contact information, device instructions, device warranty information, and more.

(^2) Do not place the printer near any heat source or flammable or explosive objects. We suggest placing it in a well-ventilated, cool and dustless environment;

(^3) Do not expose the printer to a violent vibration or any other unstable environment, as this may cause poor print quality;

(^4) Please use recommended filaments to avoid clogging of the extrusion head and causing damage to the machine;

5 Do not use the power cable of other products during installation. Always use a grounded three-prong power outlet, which accompanies the printer;

6 Do not touch the nozzle and the heated bed during operation to avoid burns or personal injury;

(^7) Do not wear gloves or wraps while operating the machine to prevent entrapment of movable parts that could cause crushing and cutting injuries to bodily parts;

Use the provided tools to clean the filament from the extruder in time taking advantage of the residual temperature after printing. Do not touch the extruder directly when cleaning, otherwise it may cause burns;

9 Clean the printer frequently. Clean the printer body with a dry cloth regularly after powering off the printer, wipe away dust, bonded print filament and foreign objects on the guide rails;

10 Children under 10 years old should not use the printer without supervision, otherwise it may cause personal injury;

11 Users should comply with the laws and regulations of the corresponding countries and regions where the equipment is located (used), abide by professional ethics, pay attention to safety obligations, and strictly prohibit the use of our products or equipment for any illegal purposes; Creality will not be responsible for any violators' legal liability under any circumstance;

12 Tip: Do not plug in or unplug wires on a charged basis.

(^1) Do not use the printer in any way other than described herein in order to avoid personal injury or property damage;

NOTES

Top cover

Nozzle assembly

camera

Side Fan

Printing platform

Touch screen

Front door

USB flash disk port

1. About the Device

1.1 About the Printer

Material barrel

Toggle Switch

Power outlet

Switch

Air filter element assembly

Filament detection

Basic Parameters

camera

K1C

355355482mm

12.4kg

220220250mm

100-120V~/200-240V~，50/60Hz

350W

10℃-35℃ / 50°F-86°F

Sprite Direct Drive

PLA/TPU/PETG/ASA/ABS/PET/Carbon/PLA-CF/PA-CF

100℃

300℃

4.3 inch touch screen

USB Flash Disk/LAN Printing/Creality Cloud Printing

Yes

Yes

Yes

Yes

FDM

1.2 Device Specifications

1. About the Device

Ambient temperature

Extruder

Product Model

Machine Weight

Dimensions

Max. Build Dimensions

Print Technology

Rated Voltage

Rated Power

Supported Filament

Max. Nozzle Temperature

Max. Heated Bed Temperature

User Interface

Print lnterface

Auto leveling

Power Loss Recovery

Filament Detection

Remove the power cord and air filter cartridge assembly;.

Move the chain to one side in the direction indicated by the arrow;

Finally, take the grey foam as shown.

a

b

c

a

c

b

2. Unboxing

2.1 Unpacking Steps

2. Unboxing

Push the extruder in the direction indicatedby the arrow and remove the foam.

2. Unboxing

⑧ Install the top cover.

1. When printing with low-melting-point filaments such as PLA and flexible filaments, if the chamber temperature exceeds 35°C, please remove the transparent cover.
2. When printing high melting-point filaments such as non-PLA and non-flexible filaments, be sure to keep the forming chamber temperature with the clear top cover closed to avoid cracking of the mould.

⑥ Load filaments. (Insert the filaments into the deepest part of Teflon tube until it cannot be moved.)

⑦ Attach the buffer strip to the inner edge of the top cover.

⑤ Connection and power on. ④ Install the material barrel.

NOTE: For a different user experience in loading resin, you can use the supplied G-code file to print the material barrel holder and then install it on the side of the machine as shown in the figure above (use the 3 material rack screws to lock it in place, and screw holes have been pre-drilled on the side).

Use M3*12 screws

2. Unboxing

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website.

⑩ Keep the blue cube in the figure clean of debris and then click“OK".

⑨ Select a language and click “Next", Remove three screws a, b and c according to position

indicated by the yellow arrow. click “OK" on the screen.

c

a b

3. About the User Interface

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website.

Print interface

Prepare

Parameters can be manually set

Main

3.1 Tune、Prepare

Cooling inlet

LED switch

Print Time

Remain

This screen allows you to reduce the machine's working volume by selecting the Mute Mode

Hotbed Temperature

Nozzle Temperature

Chamber temperature

3. About the User Interface

① Local model ② Press and hold on the model to multi-select and copy it to a USB flash drive

③ USB flash drive model ④ History

Tips: Choosing print calibration can improve print quality

3.2 Files

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website.

4. First Printing

4.1 USB flash disk Printing

① Insert the storage device

③ Select to print ④ Printing

② USB flash drive model

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest firmware UI published on the official website.

Note: Keep the Extrusion switch lock

before printing.

4. First Printing

② Choose a language and region ③ Choose a Printer

Creality Print

⑤ Open the model and click on “Slice”

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website.

④ Import model files

4.2 LAN Printing

① Download at (www.crealitycloud.com) or find the software on a USB flash drive and install it.

Tips: the computer must be in the same local area network as the printer

4. First Printing

4.3 Creality Cloud printing

① Search for “Creality Cloud" in the App Store, download and install it

② Sign up ③ Log in

Creality Cloud

4. First Printing

⑥ Select model on the homepage

④ Add a new device ⑤ Added successfully ⑦ Slice

Note: The current interface is for reference only. Due to the continuous upgrading of functions, it shall be subject to the latest software UI published on the official website.

⑧ Print ⑨ Select a device ⑩ Printing...

Scan the QR code

Select Settings → Bind the Creality Cloud
