Lecture 9: Group Communication

Operations

Topic Overview

• One-to-All Broadcast and All-to-One Reduction
• All-to-All Broadcast and Reduction
• All-Reduce and Prefix-Sum Operations
• Scatter and Gather
• All-to-All Personalized Communication
• Circular Shift
• Improving the Speed of Some Communication Operations

Basic Communication Operations:

Introduction

• Group communication operations are built using point-to-point messaging primitives.
• Recall from our discussion of architectures that communicating a message of size m over an uncongested network takes time t (^) s +mt (^) w.
• We use this as the basis for our analyses. Where necessary, we take congestion into account explicitly by scaling the t (^) w term.
• We assume that the network is bidirectional and that communication is single-ported.

One-to-All Broadcast and All-to-One

Reduction

• One processor has a piece of data (of size m ) it needs to send to everyone.
• The dual of one-to-all broadcast is all-to-one reduction.
• In all-to-one reduction, each processor has m units of data. These data items must be combined piece-wise (using some associative operator, such as addition or min), and the result made available at a target processor.

One-to-All Broadcast and All-to-One

Reduction on Rings

• Simplest way is to send p-1 messages from the source to the other p-1 processors - this is not very efficient.
• Use recursive doubling: source sends a message to a selected processor. We now have two independent problems derined over halves of machines.
• Reduction can be performed in an identical fashion by inverting the process.

One-to-All Broadcast

• One-to-all broadcast on an eight-node ring. Node 0 is the source of the broadcast.Each message transfer step is shown by a numbered, dotted arrow from the source of the message to its destination. The number on an arrow indicates thetime step during which the message is transferred
• Algorithmic Approach:having the data doubles every iteration/round and the processor getting the data Recursive doubling w/ recursive splitting : # of processors from another processor is the “mirror processor” in the other half of the currentprocessor space (thus splitting this space in two). The current processor space halves every round.
• Time = Theta(P-1)
• An easier algorithm: Send to neighbor, and then neighbor and source take care ofeach half of the ring (now a linear array) w/ either above algo. or just sequentially sending the data according to the linear connections. Time = Theta(1 + P/2 – 1) =Theta(P/2) Docsity.com

Broadcast and Reduction: Example

Consider the problem of multiplying a matrix with a vector.

• The n x n matrix is assigned to an n x n (virtual) processor grid. The vector is assumed to be on the first row of processors.
• The first step of the product requires a one-to-all broadcast of the vector element along the corresponding column of processors. This can be done concurrently for all n columns.
• The processors compute local product of the vector element and the local matrix entry.
• In the final step, the results of these products are accumulated to the first row using n concurrent all-to-one reduction operations along the rows (using the sum operation).

Broadcast and Reduction: Matrix-Vector Multiplication Example

One-to-all broadcast and all-to-one reduction in the multiplication of a 4 x 4 matrix with a 4 x 1 vector.

Broadcast and Reduction on a Mesh:

Example

One-to-all broadcast on a 16-node mesh.

Broadcast and Reduction on a

Hypercube

• A hypercube with 2 d^ nodes can be regarded as a d -dimensional mesh with two nodes in each dimension.
• The mesh algorithm can be generalized to a hypercube and the operation is carried out in d ( = log p ) steps.

Broadcast and Reduction on a

Balanced Binary Tree

• Consider a binary tree in which processors are (logically) at the leaves and internal nodes are routing nodes.
• Assume that source processor is the root of this tree. In the first step, the source sends the data to the right child (assuming the source is also the left child). The problem has now been decomposed into two problems with half the number of processors.

Broadcast and Reduction on a

Balanced Indirect Binary Tree

• One-to-all broadcast on an eight-node indirect tree
• Algorithm: Recursive doubling w/ recursive splitting
• Time = Sum_{i=1 to log P} (2logP/2i-1^ )) = 2logP [1 – (1/2)log P^ ]/[1-1/2] = 4logP (P-1)/P = Theta(4 log P).

Broadcast and Reduction Algorithms

One-to-all broadcast of a message X from source on a hypercube.

/* I am or will be the source inmy current proc. space */

Broadcast and Reduction Algorithms

Single-node accumulation on a d -dimensional hypercube. Each node contributes a messagethe destination. X containing m words, and node 0 is
