CIS 600 Advanced Computer

Architecture

Lecture 4 – Memory Hierarchy

Review

Docsity.com

Outline

• Memory hierarchy
• Locality
• Cache design
• Virtual address spaces
• Page table layout
• TLB design options
• Conclusion

Docsity.com

1977: DRAM faster than

microprocessors

Apple ][ (1977)

Steve Wozniak^ Steve Jobs

CPU: 1000 ns DRAM: 400 ns

Docsity.com

Levels of the Memory Hierarchy

CPU Registers 100s Bytes <10s ns Cache K Bytes 10-100 ns 1-0.1 cents/bit

Main Memory M Bytes 200ns- 500ns$.0001-.00001 cents /bit Disk G Bytes, 10 ms (10,000,000 ns) 10 -5 - 10-6 cents/bit

Capacity Access Time Cost

Tape infinite sec-min 10 -

Registers

Cache

Memory

Disk

Tape

Instr. Operands

Blocks

Pages

Files

StagingXfer Unit

prog./compiler 1-8 bytes

cache cntl 8-128 bytes

OS512-4K bytes

user/operator Mbytes

Upper Level

Lower Level

faster

Larger

Docsity.com

iMac’s PowerPC 970: All caches on-

chip

(1K)

R eg ist er s 512KL

L1 (64K Instruction)

L1 (32K Data) Docsity.com

The Principle of Locality

• The Principle of Locality:
  • Program access a relatively small portion of the address space at any instant of time.
• Two Different Types of Locality:
  • Temporal Locality (Locality in Time): If an item is referenced, it will tend to be referenced againsoon (e.g., loops, reuse)
  • Spatial Locality (Locality in Space): If an item is referenced, items whose addresses are close bytend to be referenced soon (e.g., straightline code, array access)
• Last 15 years, HW relied on locality for speed

It is a property of programs which is exploited in machine design.

Docsity.com

Memory Hierarchy: Terminology

• Hit: data appears in some block in the upper level (example: Block X) - Hit Rate: the fraction of memory access found in the upper level - Hit Time: Time to access the upper level which consists of RAM access time + Time to determine hit/miss
• Miss: data needs to be retrieve from a block in the lower level (Block Y) - Miss Rate = 1 - (Hit Rate) - Miss Penalty: Time to replace a block in the upper level + Time to deliver the block the processor
• Hit Time << Miss Penalty (500 instructions on 21264!)

Lower Level To Processor Upper Level Memory^ Memory

From Processor^ Blk X Blk Y Docsity.com

Cache Measures

• Hit rate : fraction found in that level
  • So high that usually talk about Miss rate
  • Miss rate fallacy: as MIPS to CPU performance, miss rate to average memory access time in memory
• Average memory-access time = Hit time + Miss rate x Miss penalty (ns or clocks)
• Miss penalty : time to replace a block from lower level, including time to Docsity.com

Q1: Where can a block be

placed in the upper level?

• Block 12 placed in 8 block cache:
  • Fully associative, direct mapped, 2-way set associative
  • S.A. Mapping = Block Number Modulo Number Sets Cache

01234567 01234567 01234567

Memory

012345678901234567890123456789011111111111222222222233

Full Mapped Direct Mapped(12 mod 8) = 4 (12 mod 4) = 0^ 2-Way Assoc

Docsity.com

Q2: How is a block found if it is

in the upper level?

• Tag on each block
  • No need to check index or block offset
• Increasing associativity shrinks index, expands tag

Block Offset

Block Address Tag Index

Docsity.com

Q3: After a cache read miss, if there are no empty cache blocks, which block should be removed from the cache?

A randomly chosen block? Easy to implement, how well does it work?

The Least Recently Used (LRU) block? Appealing, but hard to implement for high associativity

Miss Rate for 2-way Set Associative Cache Also, try other LRU approx.

Size Random LRU 16 KB (^) 5.7% 5.2% 64 KB 2.0% 1.9% 256 KB (^) 1.17% 1.15%

Docsity.com

Q4: What happens on a write?

Write-Through Write-Back

Policy

Data written to cache block also written to lower- level memory

Write data only to the cache Update lower level when a block falls out of the cache Debug Easy Hard Do read misses produce writes? No^ Yes Do repeated writes make it to lower level?

Yes No

Additional option -- let writes to an un-cached address allocate a new cache line (“write-allocate”). Docsity.com

5 Basic Cache Optimizations

• Reducing Miss Rate

1. Larger Block size (compulsory misses)
2. Larger Cache size (capacity misses)
3. Higher Associativity (conflict misses)

• Reducing Miss Penalty

4. Multilevel Caches

• Reducing hit time Docsity.com

The Limits of Physical Addressing

CPU (^) Memory

A0-A31 A0-A

D0-D31 D0-D

“Physical addresses” of memory locations

Data All programs share one address space: The physical address space

No way to prevent a program from accessing any machine resource

Machine language programs must be aware of the machine organization

Docsity.com
