Department of Computer Engineering

Sharif University of Technology

Object-Oriented Design

Lecturer: Raman Ramsin

Lecture 15 :

Object-Oriented Principles

Department of Computer Engineering

Sharif University of Technology

Open Closed Principle (OCP)  Classes should be open for extension but closed for modification.  OCP states that we should be able to add new features to our system without having to modify our set of preexisting classes.  One of the tenets of OCP is to reduce the coupling between classes to the abstract level.  Instead of creating relationships between two concrete classes, we create relationships between a concrete class and an abstract class or an interface.

Department of Computer Engineering

Sharif University of Technology

Dependency Inversion Principle (DIP)  Depend upon abstractions. Do not depend upon concretions.  The Dependency Inversion Principle (DIP) formalizes the concept of abstract coupling and clearly states that we should couple at the abstract level, not at the concrete level.  DIP tells us how we can adhere to OCP.

Department of Computer Engineering

Sharif University of Technology

Interface Segregation Principle (ISP)  Many specific interfaces are better than a single, general interface.  Any interface we define should be highly cohesive.

Department of Computer Engineering

Sharif University of Technology

Principle of Least Knowledge (PLK)  For an operation O on a class C, only operations on the following objects should be called: itself, its parameters, objects it creates, or its contained instance objects.  Also called the Law of Demeter.  The basic idea is to avoid calling any methods on an object where the reference to that object is obtained by calling a method on another object ( Transitive Visibility).  The primary benefit is that the calling method doesn’t need to understand the structural makeup of the object it’s invoking methods upon.

Department of Computer Engineering

Sharif University of Technology

GRASP  Acronym stands for General Responsibility Assignment Software Patterns.  A set of 9 Patterns introduced as a learning aid by Craig Larman.  Describe fundamental principles for object-oriented design and responsibility assignment, expressed as patterns.  The skillful assignment of responsibilities is extremely important in object design.  Determining the assignment of responsibilities often occurs during the creation of interaction diagrams, and certainly during programming.

Department of Computer Engineering

Sharif University of Technology

GRASP: Information Expert  As a general principle of assigning responsibilities to objects, assign a responsibility to the information expert:  i.e. the class that has the information necessary to fulfill the responsibility.

Department of Computer Engineering

Sharif University of Technology

GRASP: Creator  Assign class B the responsibility to create an instance of class A if one or more of the following is true:  B aggregates A objects.  B contains A objects.  B records instances of A objects.  B closely uses A objects.  B has the initializing data that will be passed to A when it is created (thus B is an Expert with respect to creating A).  B is a creator of A objects.  If more than one option applies, prefer a class B which aggregates or contains class A.

Department of Computer Engineering

Sharif University of Technology

GRASP: High Cohesion  Assign a responsibility so that cohesion remains high.  A class with low cohesion does many unrelated things, or does too much work.  Such classes are undesirable; they suffer from the following problems:  hard to comprehend  hard to reuse  hard to maintain  Delicate: constantly affected by change

Department of Computer Engineering

Sharif University of Technology

GRASP: Controller  Assign the responsibility for receiving or handling a system event message to a class representing one of the following choices:  Represents the overall system, device, or subsystem (facade controller).  Represents a use case scenario within which the system event occurs (a use-case- or session-controller).  Use the same controller class for all system events in the same use case scenario.  Informally, a session is an instance of a conversation with an actor.  Note that "window," "applet," "widget," "view," and "document" classes are not on this list.  Such classes should not fulfill the tasks associated with system events, they typically delegate these events to a controller.

Department of Computer Engineering

Sharif University of Technology

GRASP: Indirection  Assign the responsibility to an intermediate object to mediate between other components or services so that they are not directly coupled.  The intermediary creates an indirection between the other components.  Beware of transitive visibility.

Department of Computer Engineering

Sharif University of Technology

GRASP: Pure Fabrication  Assign a highly cohesive set of responsibilities to an artificial or convenience class that does not represent a problem domain concept — something made up, to support high cohesion, low coupling, and reuse.  Example: a class that is solely responsible for saving objects in some kind of persistent storage medium, such as a relational database; call it the PersistentStorage.  This class is a Pure Fabrication — a figment of the imagination.

Department of Computer Engineering

Sharif University of Technology

Design by Contract (DBC)  A discipline of analysis, design, implementation, and management.  Bertrand Meyer introduced Design by Contract in Eiffel as a powerful technique for producing reliable software.  Its key elements are assertions: boolean expressions that define correct program states at arbitrary locations in the code.

Department of Computer Engineering

Sharif University of Technology

Design by Contract (DBC): Assertions  Simple assertions belong to individual statements in a program, yet important DBC assertions are defined on classes:  Per- method assertions:  Precondition: A condition that must be true of the parameters of a method and/or data members – if the method is to behave correctly – PRIOR to running the code in the method.  Postcondition: A condition that is true AFTER running the code in a method.  Per-class assertions:  Class Invariant: A condition that is true BEFORE and AFTER running the code in a method (except constructors and destructors).
